- Page 1 HDD Extension Unit INSTALLATION AND OPERATION MANUAL MODEL DX-ZD5UE(Z) THIS INSTRUCTION MANUAL IS IMPORTANT TO YOU. PLEASE READ IT BEFORE USING YOUR HDD EXTENSION UNIT.
- Page 2 WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
- Page 3 AVERTISSEMENT DANGER D’ÉLECTROCUTION NE PAS OUVRIR AVERTISSEMENT: POUR ÉLIMINER TOUT RISQUE D’ÉLECTRO- CUTION, NE PAS OUVRIR LE COUVERCLE (OU LA PARTIE ARRIÈRE). AUCUNE PIECE RÉPARABLE PAR L’UTILISATEUR NE SE TROUVE À L’INTÉRIEUR. POUR TOUTE INTERVENTION D’ENTRETIEN OU DE RÉPARATION SE CONFIER AUX TECH- NICIENS QUALIFIÉS.
-
Page 4: Important Safeguards
Important safeguards PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR HDD EXTENSION UNIT AND RETAIN FOR FU- TURE REFERENCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE HDD EXTENSION UNIT. 1. Read Instructions 9. Ventilation All the safety and operating instructions should be Slots and openings in the cabinet are provided for read before the appliance is operated. - Page 5 16.Servicing 18.Replacement Parts Do not attempt to service this product yourself as When replacement parts are required, be sure the opening or removing covers may expose you to dan- service technician has used replacement parts gerous voltage or other hazards. Refer all servicing specified by the manufacturer or have the same to qualified service personnel.
-
Page 6: Caution And Care
Caution and care HEAVY OBJECTS SHOULD NEVER BE PLACED ON THE UNIT (E.G., MONITOR) NEVER TOUCH OR INSERT ANY OBJECT INSIDE THE UNIT Touching the inside of the cabinet or inserting foreign objects of any kind through the ventilation holes not only creates a safety hazard but can also cause extensive damage. - Page 7 WARNING: The power cords for use in the U.S., the continent of Europe, and U.K. are included with this unit. Use the appropriate one for your country. The power cord for use in the U.S. is used for 120V only. Never connect to any outlet or power suply having a different voltage or frequency.
-
Page 8: Table Of Contents
Contents Important safeguards ............ i-iv How to read this manual Caution and care ............2-3 • Viewing displays Contents ................4 (Refer to this information when operating): Reference information concerning operation Major operations and their functions ......5-6 Front view ..............5 (Caution required): Rear view .............. -
Page 9: Major Operations And Their Functions
Major operations and their functions Front view POWER HDD 1 HDD 2 TEMP HDD EXTENSION UNIT DX-ZD5 ACCESS 1. POWER indicator When the EXTERNAL CONTROL switch is set to OFF, or it is set to ON with the connected recorder turned on, this indicator illuminates while the MAIN switch on the rear panel is turned on. -
Page 10: Rear View
Major operations and their functions Rear view EXTERNAL SERIAL BUS MAIN CONTROL AC IN 100-240V 1. MAIN switch 4. I/O terminals This is the main power switch. When using this unit, CONT IN terminal set this switch to ON. Terminal for inputting the power on/off status of the 2. -
Page 11: Connections
Connections 1. Connectable recorders MITSUBISHI DIGITAL RECORDER DX-TL5000U, DX-TL5000E 2. Connection example • Connect this unit and a digital recorder by using the supplied USB cable. • It is possible to connect some DX-ZD5UE(Z), as shown below. Digital recorder DX-TL5000U or DX-TL5000E VIDEO VIDEO OPTION SLOT... -
Page 12: Startup
Connections 3. Startup 1. Turn on the power of this unit. step 2. Turn on the main switch of the recorder. step The POWER indicator of this unit illuminates. 3. After “POWER OFF” is displayed on the LCD of the recorder, press the POWER button of the recorder. step 4. - Page 13 User Menu Copy 2 This item is used to copy the data by specifying only the Copy start point. The point is specified by the date and time or step the bookmark. The copy continues until the end point of Copy Data to Copy 1 Drive the recording data reaches or the media to be copied be- comes full unless the copy is stopped manually (when “FIFO...
-
Page 14: Attaching And Removing The Hdd
Connections • “LPA” appears for “From Main” when “Long Pre-Alarm • Make sure that the MAIN switch on the rear panel is Area” (System Menu Memory Data Management turned OFF when attaching or removing the HDD. Setting for Main Memory Change Partition Setting) Wait at least 1 minute after turning off the power. - Page 15 2. Remove the screws. 7. Attach the new HDD onto the HDD tray with four step step screws. • Make sure to attach the HDD in the correct direction. • When attaching the HDD to this unit, use the supplied screws.
- Page 16 Connections 11. Attach the metal part. 15. Fix the front covers with two screws. step step • Adjust the upper side first, then push the lower side into the unit. • Take care not to deform the springs. 16. Close the left end of each screw covers on both sides step of the cover.
-
Page 17: Troubleshooting
6. Troubleshooting If problems with the unit persist even after you’ve followed the suggestions below, please disconnect the power cord and contact the retailer from whom you purchased the unit. Description of problem Please consult the following The unit is not turned on. •... -
Page 18: Recording Time Table
Recording time table Continuous recording time table HDD continuous recording time Displays the estimated recordable time (when recording on two 250 GB HDDs). • The following table shows the total number of recordable frames of all the cameras which are set for recording. •... - Page 19 • With audio recording <Audio recording using 12.8 KHz PCM sampling is possible.> d : day, h : hour Number of frames /sec. Picture grade Audio Channel 1 1d7h 1d23h 2d14h 3d6h 4d21h 5d5h 9d16h 11d20h Audio Channel 2 1d7h 1d23h 2d14h 3d6h...
- Page 20 Recording time table • When recording data in PAL system • Without audio recording d : day, h : hour Number of frames 66.7 33.3 /sec. Picture grade Super 1d9h 2d1h 2d18h 3d11h 4d1h 5d12h 8d15h 10d15h Fine 1d15h 2d10h 3d6h 4d1h 4d19h...
- Page 21 • With audio recording <Audio recording using 12.8 KHz PCM sampling is possible.> d : day, h : hour Number of frames 66.7 33.3 /sec. Picture grade Audio Channel 1 1d9h 2d1h 2d18h 3d10h 5d11h 8d11h 10d9h Audio Channel 2 1d9h 2d1h 2d17h...
-
Page 22: Specifications
Specifications General 100 to 240 V AC ±10 %, 50/60 Hz Rated Power Supply: Rated Input: 0.7 - 0.4 A (100-240 V) 41 °F-104 °F (5 °C to 40 °C) Operating Temperature: Relative Humidity: Max. 80 (%) Altitude: Max. 2000 (m) Dimensions: 424 (Width) x 361 (Depth) x 49 (Height) (mm) Weight:... - Page 23 SLD Security & Communications The Old Forge, Ockham Lane, Ockham, Surrey GU23 6PH England Phone +44.1483225633 · Fax +44.1483225634 sales@sld.co.uk · www.sld.co.uk...
