- Page 1 METROLOGIC INSTRUMENTS, INC. ® IS421X ScanGlove Laser Bar Code Scanner Installation and User’s Guide MLPN 2187 Printed in USA October 1998...
- Page 2 Copyright ® © 1998 by Metrologic Instruments, Inc. All rights reserved. No part of this work may be reproduced, transmitted, or stored in any form or by any means without prior written consent, except by reviewer, who may quote brief passages in a review, or provided for in the Copyright Act of 1976.
-
Page 3: Table Of Contents
Table of Contents Introduction ........... 1 Unpacking List . -
Page 4: Introduction
Introduction The ScanGlove™ non-decode scanners interface directly into decode equipped "keyboard wedges," controllers, or decode, they are designed distinctly to accommodate many types of applications. When using the ScanGlove™ with a decoder, scanner operation is dependent upon your decoder. Since there are many decoders available, refer to the decoder’s documentation concerning scanner requirements and operation. -
Page 5: Theory Of Operation
Theory of Operation When connected to a decoder/controller and to the signals as defined in the pin assignment sections, the IS4210 and IS4213 scanners will operate as follows. The scanning process initiates by an infrared (IR) device located behind the window. -
Page 6: Connecting The Is4210 Or Is4213 Scanglove To A Decoder/Controller
Connecting the IS4210 or IS4213 ScanGlove to a Decoder/Controller Important Note: To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements for SELV (Safety Extra Low Voltage) according to EN 60950. Since each host system is unique, configure the decoder/controller to match your host system requirements. -
Page 7: Parts Of The Scanglove Scanner
Parts of the ScanGlove Scanner Becoming familiar with the features of the scanner will help when operating the scanner. The following illustration and list explain the pertinent parts. Figure 1 When the red LED is on, this shows that the Green and Red LED laser is on. -
Page 8: Audible Indicators
Audible Indicators Audible indicators show the status of the scanner. These indicators are dependent upon the decoder being used. The function of these indications may not work as described below if the decoder pinouts and software controls do not match the pin out signals as defined in the pin assignment section of this manual. -
Page 9: Visual Indicators
Visual Indicators There are visual indicators to show the status of the scanner. These indicators are dependent upon the decoder being used. The function of these indicators may not work as described below if the decoder pinouts and software controls do not match the pin out signals as defined in the pin assignment section of this manual. - Page 10 Signaux optiques Il existe des signaux optiques qui vous informent sur l'état du scanner. Ces signaux dépendent du décodeur que vous utilisez. Il peut arriver que les fonctions de ces signaux ne correspondent pas à celles qui suivent si vous utilisez un décodeur qui n'a pas été...
- Page 11 Optische Anzeigen Es sind optische Anzeigen vorhanden, die Ihnen Aufschluß über den Scannerstatus geben. Diese Anzeigen sind abhängig von dem von Ihnen verwendeten Dekodierer. Es kann sein, daß die Funktionen dieser Anzeigen nicht den nachfolgend angegebenen entsprechen, falls Sie einen Dekodierer verwenden, der nicht von Metrologic hergestellt wurde.
- Page 12 Segnali ottici Sono previsti dei segnali ottici che Vi informano sullo stato dello scanner. Questi segnali dipendono dal decodificatore da Voi utilizzato. Se utilizzate un decodifi-catore che non è stato fabbricato dalla Metrologic è possibile che le funzioni di questi segnali non corrispondano a quelle qui di seguito indicate.
-
Page 13: Labels
Labels The scanner is a CDRH Class II laser system. The CDRH Class II label and the serial number label are located at the bottom of the unit. The “Avoid exposure laser light emitted from this aperture” label is located directly over the output window. -
Page 14: Ir Sensor Activation
IR Sensor Activation The scanning process initiates by an infrared (IR) sensor located behind the output window. In short range mode the signal it projects extends approximately 4" - 7" beyond the output window. In long range mode the signal it projects extends approximately 9"... -
Page 15: Depth Of Field And Symbol Specification
Depth of Field and Symbol Specification (Refer to Figure 4) Code Type* Minimum Small Code Density Depth of Field Element Mil. (1/1000") UPC/EAN 10.4 1.5" - 5.5" UPC/EAN 13.0 100% 1.5" - 6.0" Code 39 High 1.5" - 4.0" Code 39 12.0 Medium 2.5"... -
Page 16: Maintenance
Maintenance Smudges and dirt can interfere with the proper scanning of a bar code. Therefore, the output window will need occasional cleaning. 1. Spray glass cleaner onto lint free, non-abrasive cleaning cloth. 2. Gently wipe the output window. -
Page 17: Specifications
Appendix A Specifications Application: Hand mounted laser bar code scanner Light Source: VLD 675 ± 5 nm Max. Laser Power: 1.0 mW CDRH: Designed to meet Class II laser product UL/CSA: Designed to meet UL 1950; CSA, C22.2 No. EMI: Designed to meet FCC Class A IEC: Class I... -
Page 18: Is4210 And Is4213 Pin Assignments
Appendix B IS4210 and IS4213 Pin Assignments The IS4210 and IS4213 scanners both terminate with a 9-pin female squeeze connector. The pin numbers impress on the connector. Signal Name Function Each positive transition of the scan sense Scan Sense signal represents the start of a scan cycle, which is one pass in each direction across the bar code. - Page 19 The proximity detect is a grounding switch that Proximity Detect is active while an object is in the specified detection field. The controlling computer should provide a +5 VDC pull up. Ground the +5 VDC pull up when the proximity detect activates. This shows that an object has moved within scanning range.
-
Page 20: Is4215 Pin Assignments
IS4215 Pin Assignments The IS4215 scanner terminates with a 25-pin male D-type connector. The pin numbers impress on the connector: Signal Name Function A power ground that can handle a 500- Ground milliampere load. A +5 VDC input to the head. Its use is to Laser/ start the flipper motor and signal processor, Motor Control... - Page 21 Each positive transition of the scan sense signal Scan Sense represents the start of a scan cycle, which is one pass in each direction across the bar code. Therefore, it sends the bar code data (both forwards and reverse) between the rising edges. There are 35 scan sense pulses per second, which equals 70 scans per second.
-
Page 22: Warranty And Disclaimer
INCLUDING, WITHOUT LIMITATION, ANY INJURY TO PROPERTY OR PERSON OR EFFECT ON BUSINESS OR PROFIT, AND IN NO EVENT SHALL ANY LIABILITY OF METROLOGIC EXCEED THE ACTUAL AMOUNT PAID TO METROLOGIC FOR THE PRODUCT. Metrologic Instruments, Inc. Customer Service Department 90 Coles Road 1-800-ID-METRO (1-800-436-3876) - Page 23 Disclaimer Metrologic Instruments, Inc. and the author or authors make no claims or warranties with respect to the contents or accuracy of this publication, or the product it describes, including any warranties of fitness or merchantability for a particular purpose. Any stated or expressed warranties are in lieu of all obligations or liability for any damages, whether special, indirect, or consequential, arising out of or in connection with the use of this publication or the product it describes.
-
Page 24: Notices
Appendix D Notices Notice This equipment has been tested and found to comply with limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. - Page 25 Anmerkung Nach Überprüfung dieses Geräts wurde festgestellt, daß es den Grenzwerten für Digitalgeräte der Klasse A gemäß Teil 15 der Richtlinien der US-amerikanischen Bundesbehörde für das Fernmeldewesen entspricht. Diese Grenzwerte wurden festgelegt, um einen angemessenen Schutz gegen schädliche Auswirkungen bei Einsatz des Geräts in einer Ladenumgebung zu gewähren. Das Gerät erzeugt und verwendet Hochfrequenzenergie und kann diese ausstrahlen, und kann, falls es nicht gemäß...
-
Page 26: Patents
Appendix E Patents “Patent Information This METROLOGIC product may be covered by one or more of the following U.S. Patents: U.S. Patent No. 4,360,798; 4,369,361; 4,387,297; 4,460,120; 4,496,831; 4,593,186; 4,607,156; 4,673,805; 4,736,095; 4,758,717; 4,816,660; 4,845,350; 4,896,026; 4,923,281; 4,933,538; 4,992,717; 5,015,833; 5,017,765;... -
Page 27: Index
Index External Power Supply Adaptor cable Asia Faulty equipment 19 Assignments 15-18 Germany (GmbH) ii, 19 Bar codes 2-6, 13, 15, 18 Green LED 2-6, 15 Beep 2, 3, 5, 6 Headquarters Cable Host adaptor 3 Humidity communication head shield IEC 825 10 CDRH Class II Indicators... - Page 28 Mechanical Transformer Notices 21, 22 USA corporate headquarters Operating current 14 Operating temperature Ventilation Operation 1, 2, 10, 21 Voltage 3, 14, 15, 18 Operational Output window 3, 4, 6, 10, 11, Warranty 13, 14 Watt(s) 14 Weight 14 Parts Window 3, 4, 6, 10, 11, Patents 23 13, 14...
