Assembly & Operating Instructions
Liquid Propane Gas Grill
Rona Sku No.: 70005002
Item number : 720-0670E
!
WARNING:
Read this Owner's manual carefully and be sure your gas grill is properly assembled,
installed and maintained. Failure to follow these instructions could result in serious
injury and/or property damage. This gas grill is intended for outdoor use only and is not
intended to be installed in or on recreational vehicles or boats.
Note to Installer
Leave this Owner's Manual with the customer after delivery and/or installation.
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1- (888)874-8661, 7 a.m. - 5 p.m., PST, Monday - Friday
• Parts
• Assembly
• Safety Rules
• Use and Care
• Troubleshooting
Advertisement
Table of Contents
Related Manuals for Grill Master 720-0670E
Summary of Contents for Grill Master 720-0670E
- Page 1 Assembly & Operating Instructions Liquid Propane Gas Grill Rona Sku No.: 70005002 Item number : 720-0670E • Parts • Assembly • Safety Rules • Use and Care • Troubleshooting WARNING: Read this Owner’s manual carefully and be sure your gas grill is properly assembled, installed and maintained.
-
Page 2: Table Of Contents
Table of Contents Warranty------------------------------------------------2 Safety Precautions--------------------------------2~4 WARNING Hardware List------------------------------------------5 Parts Diagram -----------------------------------------6 Do not store or use gasoline or other Parts List------------------------------------------------7 flammable liquids or vapors in the Assembly Instructions---------------------------8~12 vicinity of this or any other appliance. Lighting Instructions----------------------------13~14 An LP cylinder not connected for use Cleaning and Maintenance-------------------14~15 shall not be stored in the vicinity of this Troubleshooting--------------------------------------16... - Page 3 Precautions • Have your LP gas tank filled by a reputable A tank of approximately 12 inches in diameter by 18- propane gas dealer and visually inspected and re- 1/2 inches high is the maximum size LP gas tank to qualified at each filling.
- Page 4 Burner Flame Check WARNING A strong gas smell, or the hissing sound of gas indicates a serious problem with your gas grill or the LP gas tank. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious bodily injury, death, or property damage.
-
Page 5: Hardware List
Contents for Hardware Pack The following table illustrates a breakdown of the hardware pack. It highlights what components are used in the various stages of assembly. Item Description Specification Quantity Phillips Head Screw 1/4 x 15mm 16 pcs Phillips Head Screw 1/4 x 10mm 14 pcs Phillips Head Screw... -
Page 6: Parts Diagram
Par\Part s Diagram... -
Page 7: Parts List
Model 122.16643900 Parts List 0670E-018 Main Bezel 0670E-054 Rotisserie Burner Igniter Wire 0670E-019 Main Control Knob 0670E-055 Rotisserie Burner 0670E-020 Side Shelf, Left 0670E-056 Rear Buffer 0670E-021 Side Shelf Front Panel, Left 0670E-057 Rotisserie Heat Shield 0670E-022 Timer 0670E-058 Main Burner Igniter Wire A 0670E-023 Bottle Opener 0670E-059 Main Burner Igniter Wire B 0670E-024 Sw ivel Caster With Brake... -
Page 8: Assembly Instructions
Assembly Instructions Figure 2 CAUTION: While it is possible for one person to assemble this grill, obtain assistance from another person when handling some of the larger, heavier pieces 1. Open lid of shipping carton and remove top sheet of cardboard. Lay cardboard sheet on floor and use as a work surface to protect floor and grill parts from scratches. - Page 9 Installing Grill Head Figure 8 1. Be sure grill cart doors are closed to stabilize cart. Remove grill head from carton. Place onto cart from above as shown in Figure 6. CAUTION: Grill head is heavy. To avoid injury, obtain the help of an assistant for this step.
- Page 10 5. Using (2) 1/4 x 10mm screws and (2) 1/4 lock Figure 12 washers, securely attach side burner shelf to grill head. Fully tighten two screws from previous step. Secure side burner control panel to main control panel with screw removed in step 2. (Fig. 11) 6.
- Page 11 Installing Gas Tank Heat Shield Figure 17 1. Assemble 2pcs longer gas tank heat shield bracket A to gas tank heat shields using (2) 5/32 x 8mm Phillips head screws with 5/32 lock washers from up to down (Fig. 16 A) 2.
- Page 12 Figure 21 Installing Cooking Components Important: Before cooking on your grill the first time, wash cooking grids and cooking rack with warm , soapy water. Rinse and dry thoroughly. Season with cooking oil regularly. After cooking is completed, turn grill to HIGH setting for 3 to 5 minutes to burn off excess grease or food residue.
-
Page 13: Lighting Instructions
Checking for LP gas leaks Never test for leaks with a flame. Prior to first use, at the beginning of each season, or every time your LP gas tank is changed, you must check for gas leaks. 6. To light additional burners, turn burner knob(s) to 1. - Page 14 If Grill Still Fails To Light WARNING 1. Check gas supply and connections for leaks. Check Never lean over the grill cooking area while that all wire connections are secure. lighting your gas grill. Keep your face and body a safe distance (at least 18 inches) from the 2.
-
Page 15: Cleaning And Maintenance
Cleaning and Maintenance Cleaning Exterior Stainless Steel Surfaces To ensure a proper working unit the following proper care and maintenance is suggested. •Weathering and extreme heat can cause exterior stainless steel surfaces to turn tan in color. Machine Cleaning Cooking Grids oils used in manufacturing process of stainless steel We suggest you wash your cooking grids in a mild soap can also cause this tanning color. -
Page 16: Troubleshooting
3. Inspect each burner for damage (cracks or holes) Regardless of which burner cleaning procedure you and if such damage is found, order and install a new use, we recommend you also complete the following burner. After installation check to ensure that gas steps to help prolong burner life. -
Page 17: Cooking Instruction
Cooking Instructions Indirect Cooking To cook indirectly, the food should be placed on the left or right side of your grill with the burner lit WARNING on the opposite side. Indirect cooking must be Do not leave the grill unattended. done with the Lid down. -
Page 18: Cooking Chart
Grill Cooking Chart FOOD Weight or thickness Temperature Time Special instructions and tips Slice or chop vegetables and dot with butter or Vegetables Medium 8 to 20 minutes margarine. Wrap tightly in heavy duty foil. Grill turning occassionally. Wrap individually in heavy duty foil. Cook Potatoes Whole Medium... - Page 19 LIMITED WARRANTY (Model # 720-0670E) The manufacturer warrants to the original consumer-purchaser only that this product (Model #720-0670E) shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase. The...
