- Page 1 ® Superior Liquid Cooling Systems PSU-1300ATX-12N PSU-1300ATX-12N User’s Manual User’s Manual English v1.1 Protected by U.S. Patents 6,313,990; 6,664,627; 7,167,366; 7,295,436 Other Technology Pending U.S. & World-Wide Patents...
- Page 2 Please check the Koolance website at www.koolance.com/ support for the latest product manuals. Your Koolance PSU-1300ATX-12N power supply may arrive with rubber inserts to protect the top nozzle connections during shipping. These should be removed before inserting your desired nozzles.
- Page 3 Koolance Incorporated does not warrant them. TRADEMARKS The Koolance name and logo, and the Exos name and logo are trademarks or registered trademarks of Koolance, Inc. Other company and product names used in this publication are for identifi cation purposes only and may be trademarks or registered trademarks of their respective companies.
- Page 4 WARNING: Due to U.S. regulation, power draw over a typical household 110-volt AC line limits the PSU-1300ATX-12N to 1300W output. When powered by a 220V AC circuit, the unit is capable of outputting 1700W. Users are responsible for safely supplying adequate AC power for the PSU-1300ATX-12N power supply.
-
Page 5: Internal Connections
Peripheral x 2 Cables SATA x 2 2 x 8-pin (IDE, Floppy, etc.), Cables, 4 Plugs Main ATX 24pin Mainboard 12V 4 Plugs *PSU Temperature Sensor *Internal PSU coolant temp. sensor is compatible with Koolance systems only (PC3/Exos 2 and later). User Manual... -
Page 6: External Connections
How the PSU-1300ATX-12N is Cooled The PSU-1300ATX-12N power supply is not a self-dissipating product and must be connected to an existing liquid cooling system (not included). The power supply will overheat and may become permanently damaged if operated without proper cooling. -
Page 7: Preparation For Installation
PSU mounting plate (or the purchase of a separate Koolance PSU-1300ATX-12N “Chassis PSU Mounting Plate”, if compatible). Note that for thermal purposes, Koolance recommends using at least a PC4 when also used to liquid cool the PSU-1300ATX-12N. - Page 8 For most computer cases, the PSU-1300ATX-12N must be installed from inside the chassis due to its width. If you do not have a Koolance case, please skip to the next section. Koolance PC3-726, PC3-736, PC4-1026, and PC4-1036 systems must give up one hard drive cage in order to fi...
-
Page 9: Support Bracket
fl at wing and the computer chassis side panel. Installation of the bracket is optional. Installation Carefully guide the power supply into the chassis (per normal installation). Screw the PSU-1300ATX-12N to the computer chassis’ PSU mounting area. User Manual... -
Page 10: Tubing Connection
These should only be installed on the top nozzle sockets! Attach the inlet and outlet tubing to the inlet and outlet nozzles. If you require the PSU-1300ATX-12N hoses to be connected inside the computer chassis, install the supplied L-bracket into an available rear card slot. -
Page 11: Specifications
Specifi cations AC Input Operating Range: 90-264VAC@110V, 180-264V@220V, Auto-switching Frequency: 47-63Hz Current: 15A @ 110V, 10A @ 230VAC PFC: Active Effi ciency: 83 (avg) - 85% (max) @ 110V; 86 (avg) - 87% (max) @220V DC Output Output Max: +5V @ 30A +3.3V @ 30A +12V @ 120A (12V1@20A, 12V2@20A, 12V3@40A, 12V4@40A) 12V1, 12V4, 3.3V total combined power = 650W@110V, 850W@220V... -
Page 12: Limited Warranty
OPERATING COMPONENTS AT SPEEDS OR FUNCTIONS OTHER THAN THOSE SPECIFIED BY THEIR MANUFACTURERS. Use of unauthorized replacement parts or liquid additives will void this warranty. Koolance Incorporated will not pay for warranty service performed by a non-authorized repair or diagnostic service and will not reimburse the consumer for damage resulting from warranty service performed by a non-authorized repair service. - Page 13 9001 Printed in Korea...
