- Page 1 User Manual VGA Self-Powered Splitter Series SP-VS102A VGA Self-Powered 1 x 2 Splitter with Audio SP-VS104A VGA Self-Powered 1 x 4 Splitter with Audio SP-VS108A VGA Self-Powered 1 x 8 Splitter with Audio © Digitogo, Inc. (D2G) www.digitogo.com...
- Page 2 Introduction D2G proudly introduces the VGA Self-Powered Splitter series. With our Self-Powered function, these splitters can operate perfectly at 1080p resolution without needing extra power supply. High bandwidth of 730 MHz supports 2K or higher resolution. In case 2K resolution is desirable for broadcast, power supply or USB power may be needed to view all 4 ports.
-
Page 3: Panel Description
Panel Description SP-VS102A / SP-VS104A / SP-VS108A Front (sample: SP-VS104A) Power Supply Power Indicator Spare USB Port Audio Input VGA Input Rear VGA Outputs Audio Outputs... - Page 4 2. Use high performance VGA & Audio cables. 3. Please turn off power for all the sources and display devices. Installing SP-VS102A / SP-VS104A / SP-VS108A: 1. Connect VGA & Audio cable to your VGA source and VGA Splitter Input.
- Page 5 Diagram SP-VS102A / SP-VS104A / SP-VS108A (sample SP-VS104A) Display Source SP-VS104A...
-
Page 6: Speci Cation
Speci cation Model/Order # Model/Order # SP-VS102A SP-VS102A SP-VS104A SP-VS104A SP-VS108A VGA Self-Power VGA Self-Power VGA Self-Power VGA Self-Power VGA Self-Power Model Name Model Name 1 x 2 Splitter with Audio 1 x 2 Splitter with Audio 1 x 4 Splitter with Audio... -
Page 7: Warranty
Warranty Digitogo warrants that product has limited warranty for 2 years from the date of receipt. Items that are physically damaged, misused, or altered are void of warranty. In the even if product fails because of defects, Digitogo will replace or repair provided that the equipment has been proven malfunction not subject to damage in transit, damage caused by natural catastrophes or environmental conditions.
