User Manual
Color Door Camera DRC-4U
Thank you for purchasing COMMAX products.
Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
The company is not responsible for any safety accidents caused by abnormal operation of the product.
www.safemag.ru
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Commax DRC-4U
Summary of Contents for Commax DRC-4U
-
Page 1: User Manual
User Manual Color Door Camera DRC-4U Thank you for purchasing COMMAX products. Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. The company is not responsible for any safety accidents caused by abnormal operation of the product. -
Page 2: Table Of Contents
www.safemag.ru Contents 1. Introduction ........... 3 2. Important Safeguard ........4 3. Part Names........... 4 4. Installation & Wiring ........5 5. Package contents ......... 7 6. Specification ..........8 www.safemag.ru... -
Page 3: Introduction
The model number is located on the bottom and record the serial number in the space provided below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product. Model No. -
Page 4: Important Safeguard
www.safemag.ru 2. Important Safeguard Damage Requiring Service: This equipment from the power source and source and refer servicing to qualified service per- sonnel under the following conditions: when the power is damaged. if liquid has been spilled or objects have fallen into the unit if the equipment has been exposed to rain or water. -
Page 5: Part Names
www.safemag.ru 3. Part Names. www.safemag.ru... - Page 6 www.safemag.ru ① Camera Lens : Transferring image ② Speaker : It delivers voice to a visitor ③ Call Button : Call a residence ④ Microphone : It delivers voice from a visitor ⑤ LED & Illumination Sensor : Offer clear image at night ⑥...
-
Page 7: Installation & Wiring
www.safemag.ru 4. Installation & Wiring [FIG-1] [FIG-2] SCREW M3X8(1EA) SCREW T4X18(2EA) www.safemag.ru... -
Page 8: Package Contents
www.safemag.ru ① Fix a bracket on a wall with screws ② Wiring #1, 2, 3, 4 on the back side of a door camera with a monitor as shown in [FIG-2] ③ Put a door camera unit into a wall bracket ④... -
Page 9: Specification
6. Specification Model No. DRC-4U Rated Voltage (Supplied from monitor) Wiring 4T wires(polarity)to a monitor 2 wires(non-polarity)to a electric door look Video Transmission Standard NTSC or PAL STANDARD. Sensor Type C-MOS(COLOR) Transmission Full Duplex Minimum Illumination 0.1Lux(within300mm) Embedded LED(Night working) Effective Viewing Angle (H)90°,(V)67°... - Page 10 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Web site : www.commax.com Printed In Korea / 2012.03.105 PM104U000010 www.safemag.ru...
