    GAS-FIRED INFRARED Nexgrill Industries ,Inc. OUTDOOR PATIO HEATER 145, Brea Canyon Road INSTALLATION, OPERATION Walnut, CA 91789, U.S.A. MAINTENANCE INSTRUCTIONS ® ® FOR MODEL T–005 TABLE OF CONTENTS Page I PORTANT ………………………………………… TOOLS & PARTS……………………………………… PRECAUTIONS……………………………………….. ASSEMBLY INSTRUCTIONS ………………………. GAS REQUIREMENTS & LEAK TESTING …………...
  • Page 2 ﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase!!! Please contact Customer Service hotline at 800-913-8999 for help. IMPORTANT WARNING * * * * * * For outdoor use only (outside any enclosure) Improper operation, installation, adjustment, alteration, servicing or maintenance can cause severe property damage or serious injury or death.
  • Page 3 TOOLS AND PARTS NEEDED FOR ASSEMBLY NOTE: Propane Gas Tank is not supplied Tools Needed: Phillips Screwdriver Spray Bottle Of Soapy Water (To Check For Leaks) Parts Supplied: Base Assembly with Tank Cover Post & Burner Assembly Emitter Assembly Emitter Screen (2) Reflector Reflector Dome Cap Tank Enclosure 3/16”...
  • Page 4: Precautions

    PRECAUTION Do not use this space heater in an explosive atmosphere. Keep heater away from areas where gasoline or other flammable liquids or vapors are stored. Do not attempt to alter unit in any manner. EXAMPLE: using the heater without the top canopy reflector or radiant screen.
  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTION STEP 1: Connect Top Portion to Tank Enclosure Place top portion on of tank enclosure. Insert the three 3/16” truss head screws in three holes until tight. STEP 2: Attach Emitter Grid Line up three holes on bottom of Emitter Grid with corresponding holes in emitter "...
  • Page 6 ASSEMBLY INSTRUCTION STEP 3: Attach Emitter Screen a. Attach one piece emitter screen with two truss head 3/16" screws to the post. b. Hook up two emitter screen together. c. Screw the other emitter screen on post with two truss head 3/16” screws. STEP 4: Attach the Reflector Insert threaded end of final cap nut through cap and screw into center of...
  • Page 7 ASSEMBLY INSTRUCTION STEP 5: Cylinder Attachment To Heater Make sure gas control knob is in “OFF” position. Open the tank enclosure door to locate the regulator. Rotate gas pressure regulator outwards. Attach propane gas to regulator inlet fitting by turning the propane gas clockwise. The LP-Gas supply cylinder must be disconnected when this appliance is not in use.
  • Page 8: Gas Requirements & Leak Testing

    GAS REQUIREMENTS & LEAK TESTING Gas Requirements The gas pressure regulator provided with this heater must be used. This regulator is set for L.P Propane units at 10.0” W.C. Maximum inlet pressure to propane regulator must not exceed 100 PSI. The pressure regulator provided with this heater must be used.
  • Page 9: Locating Heater For Use

    LOCATING HEATER FOR USE Be Careful: When certain materials or items are left under this heater while in use, they will be subjected to radiant heat and could be seriously damaged. CEILING/OVERHANG " " The heater is primarily for heating of outdoor patios, decks, spas, pool and working areas. The minimum clearances to combustible construction shown in above must be maintained at all times The installation must conform to local codes or in the absence of local codes with the standard for the storage and handling of liquid petroleum gases:...
  • Page 10: Lighting Instruction

    LIGHTING INSTRUCTION BEFORE TURNING ON THE GAS SUPPLY: Be sure all gas connections are tight and there are no leaks. Make sure surrounding areas are free of combustible materials, gasoline, and other flammable vapors or liquids. BEFORE RE-LIGHTING: For your safety, if re-lighting a hot heater, always wait at least five (5) minutes. NOTE: 16.4 oz Propane tank must be used TO LIGHT: (A) Open tank enclosure door.
  • Page 11: Shutdown Instruction

    SHUTDOWN INSTRUCTION WHEN HEATER IS ON: Emitter grid will become brighter due to intense heat. The color is more visible at night. Burner will display tones of blue and yellow flame. These flames should not be yellow or produce thick black smoke, indicating an obstruction of airflow through the burners.
  • Page 12: Storage/Burner Removal

    STORAGE/BURNER REMOVAL STORAGE Turn control knob “OFF” Disconnect LP source Stored in a well ventilated area out of children’s reach. Sheltered from direct contact with inclement weather. BURNER REMOVAL: (FOR BURNER CLEANING PURPOSE) 1. Remove reflector and emitter assembly by removal of the screws that fasten the emitter assembly to the lower screen cone .
  • Page 13: Trouble Shooting

    TROUBLE SHOOTING Problem Possible Causes Correction Purge gas line and repeat ignition operation Air in gas line Pilot won’t Check gas pressure Low gas pressure light Check gas passage way Blockage in gas line Reset the Heater keep in vertical position Tilt switch in trip angle/OFF position Pilot won’t Replace thermocouple...
  • Page 14 EXPLODED VIEW PARTS LIST DESCRIPTIO Q’TY REFLECTOR CAP NUT DOME CAP REFLECTOR EMITTER GRID MAIN BURNER ASSEMBLY EMITTER BASE EMITTER SCREEN … 3/16’’ TRUSS HEAD SCREW POST ORIFICE GAS PIPE 3/16’’SCREW SHROUD COVER PILOT ASSEMBLY GAS VALVE CONTROL REGULATOR TILT SAETY SWITCH VALVE KNOB CYLINDER HOUSING DOOR DOOR LATCH...
  • Page 15: Limited Warranty

    Our obligation under this warranty is limited to repair or replacement at our option of the product during the warranty period. The extent of any liability of Nexgrill Industries , Inc. under this warranty is limited to repair or replacement. This warranty does not cover normal wear of parts, damage resulting from any of the following: negligent use or misuse of the product, use on improper fuel/gas supply, use contrary to operating instructions, or alteration by any person other than our factory service center.
