DMC-S3P
Model No.
DMC-S3PC
DMC-S3PR
DMC-S3PU
DMC-S3EB
DMC-S3EE
DMC-S3EF
DMC-S3EG
DMC-S3EP
DMC-S3GA
DMC-S3GC
DMC-S3GD
DMC-S3GF
DMC-S3GK
DMC-S3GN
DMC-S3GT
DMC-S1P
DMC-S1PC
DMC-S1PR
DMC-S1PU
DMC-S1EB
DMC-S1EE
DMC-S1EF
DMC-S1EG
© Panasonic Corporation 2011 Unauthorized copy-
ing and distribution is a violation of law.
ORDER NO. DSC1101009CE
B26
Digital Camera
Advertisement
Chapters
Table of Contents
Related Manuals for Panasonic LUMIX DMC-S3P
Summary of Contents for Panasonic LUMIX DMC-S3P
- Page 1 DMC-S3P Model No. DMC-S3PC DMC-S3PR DMC-S3PU DMC-S3EB DMC-S3EE DMC-S3EF DMC-S3EG DMC-S3EP DMC-S3GA DMC-S3GC DMC-S3GD DMC-S3GF DMC-S3GK DMC-S3GN DMC-S3GT DMC-S1P DMC-S1PC DMC-S1PR DMC-S1PU DMC-S1EB DMC-S1EE DMC-S1EF DMC-S1EG © Panasonic Corporation 2011 Unauthorized copy- ing and distribution is a violation of law.
-
Page 2: Table Of Contents
DMC-S1EP Colour [DMC-S1] DMC-S1GA (A)...Blue Type (except PR/PU/EB/EF/GD/GK/GT) (K)...Black Type DMC-S1GC (N)...Gold Type (only P) DMC-S1GD (P)...Pink Type (only GA/GC/GD/GF/GT) (PA)..Pink Type (only P/PR/PU/EB/EE/EG/EP/GN) DMC-S1GF (S)...Silver Type (except EB/EF/GD) DMC-S1GK (W)..White Type (only GA/GC/GD/GF/GK/GN/GT) [DMC-S3] DMC-S1GN (A)...Blue Type (only P/PC/EB/EE/EG/EP/GK/GN) DMC-S1GT (K)...Black Type (R)...Red Type (except GD) -
Page 3: Safety Precautions
1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure 1.) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check. -
Page 4: How To Discharge The E.capacitor On Flash P.c
1.4. How to Discharge the E.Capacitor on Flash P.C.B. CAUTION: 1. Be sure to discharge the E.capacitor on FLASH P.C.B.. 2. Be careful of the high voltage circuit on FLASH P.C.B. when servicing. [Discharging Procedure] 1. Refer to the disassemble procedure and remove the necessary parts/unit. 2. -
Page 5: Warning
2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD). -
Page 6: Caution For Ac Cord(For Eb
A replacement fuse cover can be purchased from your local 2.3.2.3. How to Replace the Fuse Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety. -
Page 7: How To Replace The Lithium Battery
NOTE: This Lithium battery is a critical component. (Type No.: ML421 Manufactured by Energy Company, Panasonic Corporation.) It must never be subjected to excessive heat or discharge. It must therefore only be fitted in requirement designed specifically for its use. -
Page 8: Service Navigation
3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2. -
Page 9: General Description About Lead Free Solder (Pbf)
3.3. General Description About Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin (Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that of the normal solder. -
Page 10: How To Define The Model Suffix (Ntsc Or Pal Model)
3.5. How to Define the Model Suffix (NTSC or PAL model) There are nine kinds of DMC-S1 and DMC-S3, regardless of the colours. • a) DMC-S1 (Japan domestic model) • b) DMC-S1P/PC, DMC-S3P/PC • c) DMC-S1EB/EF/EG/EP, DMC-S3EB/EF/EG/EP • d) DMC-S1EE, DMC-S3EE •... -
Page 11: Initial Settings
3.5.2. INITIAL SETTINGS: After replacing the MAIN P.C.B., make sure to perform the initial settings after achieving the adjustment by ordering the following procedure in accordance with model suffix of the unit. 1. IMPORTANT NOTICE: Before proceeding Initial settings, make sure to read the following CAUTIONS. 2. - Page 12 [CASE 1. After replacing MAIN P.C.B.] When MAIN P.C.B. has just been replaced, all of the model suffix is displayed as follows. (Five pages in total) [CASE 2. Other than “After replacing MAIN P.C.B.”]...
- Page 13 • Step 5. Choose the model suffix in “INITIAL SETTINGS”: (Refer to “CAUTION 1”) [Caution: After replacing MAIN P.C.B.] The model suffix can been chosen, JUST ONE TIME. Once one of the model suffix have been chosen, the model suffix lists will not be displayed, thus, it can not be changed. Therefore, select the area carefully.
- Page 14 • Step 7. CONFIRMATION: Confirm the display of “PLEASE SET THE CLOCK” in concerned language when the unit is turned on again. When the unit is connected to PC with USB cable, it is detected as removable media. (When the “GT” or “GK” model suffix is selected, the display shows “PLEASE SET THE CLOCK” in Chinese.) 1) As for your reference, major default setting condition is as shown in the following table.
-
Page 15: Specifications
4 Specifications... -
Page 16: Location Of Controls And Components
Always use a genuine Panasonic AC adaptor (optional). When using an AC adaptor, ensure that the Panasonic DC coupler (optional) and AC adaptor (optional) are used. If the power supply is cut off due to a power cut or the AC adaptor being disconnected, the motion picture being recorded using the AC adaptor will not be recorded. -
Page 17: Selecting The Recording Mode
The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic. (Batteries which do not support this function cannot be used). Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products. -
Page 18: Service Mode
6 Service Mode 6.1. Error Code Memory Function 1. General description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly (i.e.,when the unit is powered on by the battery, the battery is pulled out) The error code is memorized to FLASH-ROM when the unit has just before powered off. - Page 19 • 3. Error Code List The error code consists of 8 bits data and it shows the following information.
- Page 20 Important notice about "Error Code List" 1) About "*" indication: The third digit from the left is different as follows. - In case of 0 (example: 18001000) When the third digit from the left shows "0", this error occurred under the condition of INITIAL SETTINGS has been completed.
-
Page 21: Service Fixture & Tools
7 Service Fixture & Tools 7.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit. 7.2. When Replacing the Main P.C.B. After replacing the MAIN P.C.B., be sure to achieve adjustment. The service software is available at “TSN Website”. -
Page 22: Disassembly And Assembly Instructions
8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart 8.3. Disassembly Procedure This is a disassembling chart. When assembling, perform this chart conversely. Item Removal Rear Case Unit (Fig. D1) Card Battery 3 Screws (A) 1 Screw (B) (Fig. D2) 3 Locking tabs Operation Button Rear Case Unit... - Page 23 8.3.1. Removal of the Rear Case Unit (Fig. D2) 8.3.2. Removal of the Center Ornament (Fig. D1) (Fig. D3)
- Page 24 8.3.3. Removal of the Rear Operation Unit 8.3.4. Removal of the LCD Unit (Fig. D4) (Fig. D5)
- Page 25 8.3.5. Removal of the Lens Unit 8.3.6. Removal of the Front Case Unit (Fig. D7) (Fig. D6)
- Page 26 8.3.7. Removal of the Flash Unit and Flash P.C.B. (Fig. D9) 8.3.8. Removal of the Main P.C.B. (Fig. D10) (Fig. D8)
- Page 27 [WHEN ASSEMBLING] 8.3.10. Removal of the Battery Door Unit CAUTION: Before soldering the Terminal A (Connecting part of Main P.C.B. and Top P.C.B.) Before soldering the Terminal A, make sure to tighten the "Screw (D)" first in order to eliminate the gap between Main P.C.B.
-
Page 28: Removal Of The Ccd Unit
8.4. Removal of the CCD Unit To prevent the CCD unit from catching the dust and dirt, do not remove the CCD unit except for replacing. -
Page 29: Measurements And Adjustments
9 Measurements and Adjustments 9.1. Introduction When servicing this unit, make sure to perform the adjustments necessary based on the part(s) replaced. Before disassembling the unit, it is recommended to back up the camera data stored in flash-rom as a data file. IMPORTANT NOTICE (After replacing the MAIN P.C.B.) After replacing the MAIN P.C.B., it is necessary to use the “DIAS”... - Page 30 9.2.2. Flash-Rom Data Backup When trouble occurs, it is recommended to backup the Flash-rom data before disassembling the unit. There are two kinds of Flash-rom data backup methods: [ ROM_BACKUP (Method of Non-PC backup) ] 1. Insert the SD-card into the camera. 2.
-
Page 31: Details Of Electrical Adjustment
9.3. Details of Electrical Adjustment 9.3.1. How to execute the Electrical Adjustment It is not necessary to connect the camera to a PC to perform adjustments. “Flag reset operation” and “Initial setting operation” are required when carrying out the alignment, follow the procedure below. 9.3.1.1. - Page 32 9.3.1.3. Execute Adjustment (In case of “OIS Adjustment”) 1. Perform step “9.3.1.1.” to “9.3.1.2.”, to reset the OIS flag status “F” (Set) to “0” (Reset) 2. Press “[ W ] side of the zoom button” after Flag reset. OIS Adjustment screen is displayed on the LCD panel. (Refer to Fig.3-3) 3.
- Page 33 9.3.2. Adjustment Specifications The following matrix table shows the relation between the replaced part and the Necessary Adjustment. When a part is replaced, make sure to perform the necessary adjustment(s) in the order indicated. The table below shows all the information necessary to perform each adjustment.
-
Page 35: After Adjustment
9.4. After Adjustment 9.4.1. Initial Setting Since the initial setting has been released to execute the built-in adjustment software, it should be set up again before shipping the camera to the customer. Refer to the procedure described in “3.5.2. INITIAL SETTINGS” for details. [ IMPORTANT ] 1. -
Page 36: Maintenance
10 Maintenance 10.1. Cleaning Lens and LCD Panel Do not touch the surface of lens and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the its surface. Note: The Lens Cleaning KIT ;... - Page 37 DSC1101009CE S1. About Indication of The Schematic Diagram Service Manual S1.1. Important Safety Notice COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS Diagrams and Replacement FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS USE ONLY THE SAME TYPE. 1.Although reference number of the parts is indicated on the P.C.B. drawing and/or Parts List schematic diagrams, it is NOT mounted on the P.C.B.
-
Page 38: S2. Voltage Chart
S2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. S2.1. -
Page 39: S3. Block Diagram
S3. Block Diagram S3.1. Overall Block Diagram (28mm ~ 112mm) MAIN P.C.B. CCD SIGNAL PROCESSOR 1/2.33" (24MHz) 14.1 MEGA PIX (DMC-S3) CDS, AGC, 12.1 MEGA PIX (DMC-S1) A/D, TG, CCD DRIVER ZOOM OIS UNIT IRIS SHUTTER FOCUS CARD REGULATOR MICROPHONE SYSTEM IC SYSTEM IC SPEAKER... -
Page 40: S3.2. Flash/Top Block Diagram
S3.2. Flash/Top Block Diagram FLASH BLOCK DIAGRAM FLASH P.C.B. TL8003 LAMP(+) T8001 F8001 FP8001 (UNREG+) 12-14 C8003 CL8031 FP8001 (For Flash (UNREG-) Charge) 7-10 CL8010 CL8011 FLASH TL8001 IC8100 TRG SECOND (IGBT DRIVER) RPGND CL8006 CL8005 To MAIN P.C.B. CL8032 FP8001 (STB CHG DET) FULL... -
Page 41: S4. Schematic Diagram
S4. Schematic Diagram S4.1. Interconnection Diagram TOP P.C.B. (COMPONENT SIDE) BATTERY REAR OPERATION UNIT LENS UNIT LCD UNIT UNIT MAIN P.C.B. (FOIL SIDE) MICROPHONE MAIN-FLASH FPC FLASH P.C.B. (FOIL SIDE) SPEAKER RL8010 RL8009 DMC-S1/S3 INTERCONNECTION DIAGRAM... -
Page 42: S4.2. Flash Schematic Diagram
S4.2. Flash Schematic Diagram CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE 1.25A 32V FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQUES 1.25A 32V D' INCENDIE N' UTILISERQUE DES FUSIBLE DE MÉME TYPE 1.25A 32V. TL8002 TL8003 LAMP[-]... -
Page 43: S4.3. Top Schematic Diagram
S4.3. Top Schematic Diagram D_GND RL6301 SHUTTER_0 RL6302 SHUTTER_1 RL6303 S6301 K0F212A00003 RL6304 IGBT_VCC R6337 R6338 D6301 POWER RL6305 CATHODE 33[18] 33[18] B3ADB0000169 R6339 5100 POWER_ON_L RL6306 tokei RL6307 K0F111A00539 S6302 D_GND RL6308 SAFETY_GND SHUTTER_SW TL6304 TL6305 Confidential Until DMC-S1/S3 Schematic Diagram... -
Page 44: S4.4. S1 Ccd Flex Schematic Diagram
S4.4. S1 CCD Flex Schematic Diagram FT3101 CON_CHK CCD_GND CCD_GND CCD_GND 31 30 CCD_OUT CCD_GND rrV8 MSUB CCD_GND rrV7S MSUB [37]rrV10 [29]rrH1B MSUBSW rrV7 MSUBSW [38]rrV9A V11B rrV11B rrSUB rrV6 IC3101 SUBSW1 MN34542PBHLV SUBSW1 SUBSW2 SUBSW2 rrV5 rrH2A R3107 rrV9B [11]rrV3A [20]rrHL rrH1A... -
Page 45: S4.5. S3 Ccd Flex Schematic Diagram
S4.5. S3 CCD Flex Schematic Diagram FT3101 CON_CHK CCD_GND CCD_GND CCD_GND 31 30 CCD_OUT V11B CCD_GND MSUBSW φV11B CCD_GND φV10 φH4 [37]φV12 [29]MSUBSW φV9A φH2 [38]φV11A φV9B φSUB IC3101 φV8 φH1 MN34571PBHLV φH3 φV7 φV6 φHL R3107 SUBSW1 φV5 [11]φV3A [20]SUBSW2 SUBSW1 1300... -
Page 46: S5. Print Circuit Board
S5. Print Circuit Board S5.1. Flash P.C.B. R8003 CL8010 CL8005 R8002 CL8032 Q8001 (Component Side) CL8011 F8001 G8001 CL8008 R8021 CL8031 CL8004 TL8003 T8001 CL8006 FP8001 TL8001 L8001 TL8002 C8007 R8013 R8032 D8002 RL8010 RL8009 (Foil Side) DMC-S1/S3 Flash P.C.B. S-10... -
Page 47: S5.2. Top P.c.b
S5.2. Top P.C.B. D6301 R6337 R6338 (Component Side) C6321 TL6305 C6314 S6302 TL6304 (Foil Side) DMC-S1/S3 Top P.C.B. S-11... -
Page 48: S5.3. S1 Ccd Flex P.c.b
S5.3. S1 CCD Flex P.C.B. (Component Side) C3101 TH3101 R3108 Q3101 IC3101 (Foil Side) DMC-S1/S3 S1 CCD Flex P.C.B. S-12... -
Page 49: S5.4. S3 Ccd Flex P.c.b
S5.4. S3 CCD Flex P.C.B. (Component Side) TH3101 C3101 R3108 Q3101 IC3101 (Foil Side) DMC-S1/S3 S3 CCD Flex P.C.B. S-13... - Page 50 S-14...
-
Page 51: S6. Replacement Parts List
ELECTROSTATIC DISCHARGE (ESD) TO ELECTROSTATICALLY SENSITIVE (ES) DEVICES section. <DEFINITION OF PARTS SUPPLIER> 1. Parts marked with [ENERGY] in the remarks column are supplied from Panasonic Corporation Energy Company. 2. Parts marked with [SPC] in the remarks column are supplied from AVC-CSC-SPC. - Page 52 DMC-S1EB-K Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3102 ERJ2GEJ222X M.RESISTOR CH 1/16W 2.2K VEP56128A MAIN P.C.B. 1 (DMC-S1) E.S.D. R3107 ERJ2GEJ132X M.RESISTOR CH 1/16W 1.3K VEP56128B MAIN P.C.B. 1 (DMC-S3) E.S.D. R3108 ERJ2GEJ470X M.RESISTOR CH 1/16W 47...
- Page 53 DMC-S1EB-K Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEP56128A MAIN P.C.B. 1 (DMC-S1) E.S.D. VXW1248 LENS UNIT (W/O CCD) VEP56128B MAIN P.C.B. 1 (DMC-S3) E.S.D. VEK0R19 CCD UNIT 1 (DMC-S1) E.S.D. VEP58152A FLASH P.C.B.
- Page 54 DMC-S1EB-K Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPF1372 CAMERA BAG 1 P,PC,PU DE-A91BA/SX BATTERY CHARGER 1 P,PC,PU K1HY08YY0017 USB CABLE W/PLUG 1 P,PC,PU ----- BATTERY 1 P,PC,PU VFC4297-B HAND STRAP 1 P,PC,PU VFF0736-S CD-ROM...
- Page 55 DMC-S1EB-K Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VQT3E40 BASIC O/I 1 GN VPF1372 CAMERA BAG 1 EXCEPT P,PC,PU (ENGLISH) DE-A92BA/SX BATTERY CHARGER 1 GA,GC,GD,GF,GK VQT3E38 BASIC O/I 1 GT DE-A92CA/SX BATTERY CHARGER 1 GT (CHINESE(TRADITIONAL))
-
Page 56: S7. Exploded View
S7. Exploded View S7.1. Frame and Casing Section B101 B102 B103 16-2 16-1 S-20... -
Page 57: S7.2. Packing Parts And Accessories Section (1
S7.2. Packing Parts and Accessories Section (1) (PC only) Stick the UPC label (Ref 232) for PC model on the original UPC place. (PC only) S-21... -
Page 58: S7.3. Packing Parts And Accessories Section (2
S7.3. Packing Parts and Accessories Section (2) (GT only) (DMC-S1PR DMC-S3PR) (DMC-S1EF/EE/EG/EP/GA/GF/GD DMC-S3EF/EE/EG/EP/GA/GF/GD) (DMC-S1EB/GC DMC-S3EB/GC) (DMC-S1GT/GK DMC-S3GT/GK) (DMC-S1GN DMC-S3GN) (GD only) Stick the UPC label (Ref 332) for GD model on the original UPC place. S-22...
