Summary of Contents for Think Appliances BACE6006
- Page 1 BACE6006 60cm induction hob BACE7006 70cm induction hob...
- Page 2 We also carry a complete range of spare parts for all Think products. For all your spare parts enquiries please contact our team at Pronto Parts on: 1300 306 973 Again, thank you for choosing an appliance brought to you by Think Appliances and we look forward to being of service to you. Kind regards...
- Page 3 BACE6006 60 cm Touch control induction zone hob BACE7006 70 cm Touch control induction zone hob NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 4: Table Of Contents
Contents Environmental note Important safety information 5 – 8 Specifications Electrical details Ceramic hob surface layout Control panel layout Using the ceramic hob Before first use Touch controls Turning the hob on Turning on a zone and setting a power level 11 - 12 Turning off a zone gradually Turning off a zone instantly... -
Page 5: Environmental Note
Environmental note o The packaging materials that Think Appliance uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 6: Important Safety Information
Important safety information Your safety is of the utmost importance to Think Appliance. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Think Appliance Technical Department. - Page 7 Child Safety o Think Appliance strongly recommend that babies and young children are prevented from being near to the appliance and should not be allowed to touch the appliance at any time. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
- Page 8 o IMPORTANT: This ceramic induction hob fully complies with current legislation regarding electro-magnetic interference and is designed not to interfere with other electronic appliances providing these comply with the same legislation. o As the hob generates magnetic fields in its immediate vicinity, pacemakers and active heart implants must be designed to comply with relevant regulations.
- Page 9 Declaration of conformity This appliance complies with the following European Directives: -73/23/EEC dated 19/02/1973 Low Voltage Directive. -89/336/EEC dated 03/05/1989 EMC Directive inclusive of Amending Directive 92/31/EEC. -93/68/EEC dated 22/07/1993 CE Marking Directive. -89/109/EEC dated 25/01/1992 Materials that can touch food. o The manufacturer declares that the hob is built using certified materials and requires the appliance to be installed in accordance with the standards currently in force.
-
Page 10: Specifications
Specifications Product dimensions: Aperture dimensions: Height: 520 mm Height: 490 mm Width: 590/700mm Width: 560 mm Depth: 60 mm Product specifications: o 1 x 2.00 kW induction zone (diametre 180 mm) o 2 x 1.40 kW induction zone (diametre 180 mm) o 1 x 2.00 kW induction zone with booster option (diametre 180 o Front touch control operation o Timer... -
Page 11: Ceramic Hob Surface Layout
For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. The rating plate of your hob is located on the underneath of the appliance. Therefore it is a good idea to record this information before you install your appliance. -
Page 12: Using The Ceramic Hob
Using the ceramic hob Before first use IMPORTANT: You should clean the ceramic hob surface (see “Cleaning and maintenance” section). o You should switch on one cooking zone at a time, for 5 minutes at the maximum setting. This will help to eliminate any new smell that exists and evaporate any humidity that has formed on the heating elements during transit. -
Page 13: Turning Off A Zone Gradually
o Press the plus or minus section of the zone power level adjustment control until the zone indicator shows the power level that you require. o IMPORTANT: WHEN MULTIPLE COOKING ZONES ARE BEING USED. IF THE POWER OUTPUT GOES ABOVE A CERTAIN LEVEL, THEN THE POWER OF PARTICULAR ZONES MAY BE REDUCED. -
Page 14: Turning Off A Zone Instantly
Turning off a zone instantly o Press the zone selection button (8) of the cooking zone that you want to switch off. o Press the plus and minus sections of the zone power level adjustment control simultaneously. o The zone will switch off immediately. o A flashing “H”... -
Page 15: Booster Function
Booster function The back right zone has a booster function, when this function is selected, it increases the power output of that particular zone to 2600 watts. o Press the ON/OFF button (5) o The cooking zone indicators (2) will all read “-”. o Press the zone selection button (8) for the back right zone and set your desired power level using the zone power level adjustment control (3). -
Page 16: Cookware That Is Suitable For An Induction Hob
o If the symbol shown above appears on a cooking zone indicator (2) after you have placed a pan on a cooking zone and selected it; this means that the pan is either the incorrect size or shape. Or it could be made from a material that is inappropriate for use on an induction zone hob. -
Page 17: Locking The Hob Top
o Press the plus symbol on the zone power level adjustment control. The zone indicator will show power level 5. o Press the plus or minus section of the zone power level adjustment control until the zone indicator shows the power level that you require. -
Page 18: Safety Cut-Off
o To disable the safety lock feature, you should press the safety lock button (4) again. The “L0” symbol will disappear from the timer display (7) and you are then able to adjust the power of any zone on the hob top. Safety cut-off o If one or more of the cooking zones are accidentally left on, a safety cut off will activate after a certain period of time. -
Page 19: Cleaning And Maintenance
o If these rules are not followed, then there will be a great loss of heat and energy. Heat not absorbed by the saucepan, will spread to the hob, frame and surrounding cabinets. o Preferably cover pans with a lid to permit cooking at a lower heat. -
Page 20: After Each Use
After each use o Wipe the appliance over with a damp cloth and a little washing up liquid. o Dry the appliance by rubbing the surface with a clean cloth. Cleaning table Type of deposit Remove Remove What should I immediately? when the use to remove... -
Page 21: Using A Specialist Ceramic Hob Cleaner
Using a specialist ceramic hob cleaner It is possible to purchase specialist ceramic hob cleaner/conditioner. You should follow the instructions given by the manufacturer of the specialist ceramic hob cleaner. You should ensure that it is suitable for use on your appliance. Installation The installation must be carried out by a suitably qualified person, in accordance with the current... -
Page 22: Unpacking The Appliance
Unpacking the appliance When unpacking the appliance please check that the following items are contained within the packaging:- 1 hob 1 Ceramic hob scraper 1 Installation and instruction manual 4 Fixing brackets 4 Fixing screws 1 Sealing strip Installing the appliance o Cut a hole in the worktop that corresponds with the drawing shown above. - Page 23 o IMPORTANT: You must observe the ventilation requirements shown in the drawing above. o IMPORTANT: There are ventilation holes around the outside of the hob. YOU MUST ensure that these holes are not blocked by the work top, when you put the hob into position (see drawing opposite).
-
Page 24: Electrical Connection
o Carefully turn the hob back over and then gently lower it into the aperture hole that you have cut out. o There are holes on the base or the sides of the hob that you can fix the four brackets to. There are three holes in each one of the brackets. -
Page 25: Connecting The Mains Supply Cable
o The spur outlet must still be accessible even when your oven is located in its operating position. o Cable type: H05 RRF 3 core x 6 mm² Connecting the mains supply cable o The mains terminal block is located on the underside of the hob and the terminals are accessible by removing the terminal block cover by removing the cover screw. - Page 26 o The cable connections must be in accordance with the diagram located on the bottom of the hob (see above) o The brass link must be positioned as marked in the appropriate diagram. Once established, you should use a good quality screwdriver to carefully fully tighten ALL of the terminal screws.
-
Page 27: Replacing The Mains Supply Cable
Replacing the mains supply cable If the mains supply cable is damaged, then it must be replaced by an appropriate replacement. The mains supply cable should be replaced in accordance with the following instructions: o Switch the appliance off at the control switch. o Open the terminal block on the underside of the hob. -
Page 28: Error Codes
* The pans that you are using are not suitable for use on an induction hob. o The residual heat indicator has not come on after I have switched a cooking zone off. * The cooking zone has only been turned on for a short period of time;... - Page 29 IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Think Appliance Service Department on telephone number 1800 444 357 or Fax 1300 133 279 DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF.
