Summary of Contents for Think Appliances BACE6004
- Page 1 BACE6004 60cm touch control ceramic hob BACE7004 70cm touch control ceramic hob...
- Page 2 We also carry a complete range of spare parts for all Think products. For all your spare parts enquiries please contact our team at Pronto Parts on: 1300 306 973 Again, thank you for choosing an appliance brought to you by Think Appliances and we look forward to being of service to you. Kind regards...
- Page 3 BACE6004 60 cm Side touch control 4 zone ceramic hob. BACE7004 70 cm Side touch control 4 zone ceramic hob. NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 4: Table Of Contents
Contents Environmental note Important safety information 5 – 8 Specifications 8 – 9 Ceramic hob layout Control panel layout Using the ceramic hob Before first use Touch controls Switching a zone on 10 - 11 Turning off a zone Residual heat indicator Locking the hob top Safety cut-off Hob guidelines... -
Page 5: Environmental Note
Environmental note o The packaging materials that Think Appliance uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 6: Important Safety Information
Important safety information Your safety is of the utmost importance to Think Appliance. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Think Appliance Technical Department. - Page 7 Child Safety o Think Appliance strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. During and after use, all surfaces will become hot. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
- Page 8 Cleaning o Cleaning of the hob should be carried out on a regular basis. o IMPORTANT: Before attempting to clean the appliance, it should be disconnected from the mains and cool. o Great care should be taken whilst using this appliance and when following the cleaning procedure.
-
Page 9: Specifications
o Pans should be lifted on and off the hob surface and not dragged. o Cooking zones should not be switched on without cookware placed on it. Also the cookware should not be empty. Specifications Product dimensions: Aperture dimensions: Height: 520 mm Height: Width:... -
Page 10: Ceramic Hob Layout
For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. The rating plate of your hob is located on the underneath of the appliance. Therefore it is a good idea to record this information before you install your appliance. -
Page 11: Using The Ceramic Hob
Using the ceramic hob Before first use IMPORTANT: You should clean the ceramic hob surface (see “Cleaning and maintenance” section). o You should switch on one cooking zone at a time, for 5 minutes at the maximum setting. This will help to eliminate any new smell that exists and evaporate any humidity that has formed on the heating elements during transit. -
Page 12: Turning Off A Zone
o Press the plus button (4) and the number 1 will appear in the cooking zone indicator. Use the plus and minus buttons until the power level that you require appears in the cooking zone indicator. o If you wish to switch on another zone whilst another is already in use, simply press the ON/OFF button for the zone in question. -
Page 13: Locking The Hob Top
Locking the hob top o The whole hob top can be locked by pressing the safety lock button (5) whilst the appliance is turned on. o A neon above the safety lock button will light to show that the safety lock feature has been switched on. o When the safety lock feature is activated, it will disable any of the other buttons on the control panel. - Page 14 o The worktop is fitted with cooking areas of different diametre and power. o The positions where the heat will radiate from are clearly marked on the hob top. The saucepans must be positioned exactly on these zones for efficient heating to occur. Pans should have the same diametre as the cooking zone that they are being used on.
-
Page 15: Cleaning And Maintenance
Cleaning and maintenance Cleaning operations must only be carried out when the hob is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process. Cleaning the ceramic hob top Any residues that are left on the hob top surface from cleaning agents will damage it. -
Page 16: Using A Ceramic Hob Scraper
Using a ceramic hob scraper A ceramic hob scraper will be provided with your appliance. The following guidelines should be followed when using the ceramic hob scraper:- o The scraper should be placed on the ceramic surface at an angle. o Residues should be removed by sliding the blade carefully over the ceramic surface. -
Page 17: Positioning
Positioning The adjacent furniture must be able to withstand a minimum temperature rise of 85°C above the ambient temperature of the room it is located in, during periods of use. This appliance is classified as Class 3 and therefore is to be built into a kitchen unit (depending on size) or 600mm worktop, providing the following minimum distances are allowed: o 700 mm between the hob surface and the underside of any... - Page 18 o IMPORTANT: You must observe the ventilation requirements shown in the drawing above. o IMPORTANT: There are ventilation holes around the outside of the hob. YOU MUST ensure that these holes are not blocked by the work top, when you put the hob into position (see drawing opposite).
-
Page 19: Electrical Connection
o Carefully turn the hob back over and then gently lower it into the aperture hole that you have cut out. o There are holes on the base or the sides of the hob that you can fix the four brackets to. There are three holes in each one of the brackets. -
Page 20: Connecting The Mains Supply Cable
o The spur outlet must still be accessible even when your oven is located in its operating position. o Cable type: H05 RRF 3 core x 4 mm² Connecting the mains supply cable o The mains terminal block is located on the underside of the hob and the terminals are accessible by removing the terminal block cover by removing the cover screw. -
Page 21: Replacing The Mains Supply Cable
o The cable connections must be in accordance with the diagram located on the bottom of the hob (see above) o The brass link must be positioned as marked in the appropriate diagram. Once established, you should use a good quality screwdriver to carefully fully tighten ALL of the terminal screws. -
Page 22: My Appliance Isn't Working Correctly
o Unscrew the terminal screws fixing the cable. o Replace the cable with one of the same length and in accordance with the specification given on page 19. o The “green-yellow” earth wire must be connected to the terminal marked . - Page 23 o A humming sound is heard when a cooking zone is selected. * This is normal; the sound will disappear when the zone heats up. o The cooking zones have become discoloured. * This maybe caused by burnt on remnants of food. This will not affect the working of the appliance.
