ONYXWorks
NFN Gateway
PC
Installation & Operation Manual
D
Document 52307
06/01/07
Rev:
P/N: 52307:D
ECN: 06-053

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONYXWorks and is the answer not in the manual?

Questions and answers

Summary of Contents for Notifier ONYXWorks

  • Page 1 ® ONYXWorks NFN Gateway Installation & Operation Manual Document 52307 06/01/07 Rev: P/N: 52307:D ECN: 06-053...
  • Page 2 Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! typically made up of smoke detec- An automatic fire alarm system— bedrooms), smoking in bed, and violent explosions (caused by escap- tors, heat detectors, manual pull stations, audible warning devices, ing gas, improper storage of flammable materials, etc.).
  • Page 3: Installation Precautions

    A prescrites dans le Reglement Acclimate Plus™ HARSH™ NOTI•FIRE•NET™ VeriFire™ ™, NOTIFER Intergrated Systems™ ™ , NION and ONYXWorks are trademarks, and ONYX® FlashScan® UniNet® VIEW®, NOTIFIER® ® is registered trademark of Tyco are registered trademarks of Honeywell.
  • Page 4 Documentation Feedback Your feedback helps us keep our documentation up-to-date and accurate. If you have any comments, you can email Please include the following information: • Product name and version number (if applicable) • Manual page number • Your comment Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only.
  • Page 5: Table Of Contents

    Table 1.1 NFN Network Compatibility Table..................7 1.2: NFN Gateway PC System Architecture ......................8 Figure 1.1 Direct Panel Gateway System....................8 ® Figure 1.2 ONYXWorks System Example 1- One NFN Network ............8 ® Figure 1.3 ONYXWorks System Example 2 - Multiple NFN Networks ..........9 1.2.1: About Ethernet Network Installations ....................9...
  • Page 6 Table of Contents NFN Gateway - P/N: 52307:Rev: D 06/01/07...
  • Page 7: Section 1 Nfn Gateway Pc Overview

    Section 1 NFN Gateway PC Overview ® NOTE: In this document, unless expressly written otherwise, when the term ONYXWorks Workstation or Workstation is used those terms refer to the software application and the computer it is installed on as one.
  • Page 8: Nfn Gateway Pc System Architecture

    FACP Figure 1.1 Direct Panel Gateway System IP Network Workstation Workstation Workstation/ Gateway PC NFN Network FACP FACP FACP ® Figure 1.2 ONYXWorks System Example 1- One NFN Network NFN Gateway Installation & Operation Manual - P/N: 52307:Rev: D 06/01/07...
  • Page 9: 1: About Ethernet Network Installations

    FACP FACP FACP FACP FACP ® Figure 1.3 ONYXWorks System Example 2 - Multiple NFN Networks 1.2.1 About Ethernet Network Installations ® The ONYXWorks Workstation is a Proprietary Supervising Station that has a supervised client server architecture that communicates over Ethernet (TCP/IP) networks. The IP network can be a shared bandwidth system that operates over topologies such as an intranet, the Internet, or a frame relay system.
  • Page 10: Gateway Configuration Process Flow Diagram

    NFN Gateway PC Overview Gateway Configuration Process Flow Diagram 1.3 Gateway Configuration Process Flow Diagram Start Is the gateway “NFN Gateway PC software already Software Installation” on installed on the page 13 Workstation PC? Network “Network Interface Card Using Network Interface Card Installation Procedure”...
  • Page 11: Onyxworks ® System/Nfn Gateway Requirements

    ® 1.4 ONYXWorks System/NFN Gateway Requirements ® ® An ONYXWorks system may be comprised of one or more Workstations. An ONYXWorks ® system can utilize Pentium III UL 864 listed computers from existing NOTIFIER systems. 1.4.1 Network Interface Card ®...
  • Page 12: 1: Environmental Requirements

    This product must be installed in the following environmental conditions: • Temperature range of 0°C to 49°C (32°F - 120°F). • 93% humidity non-condensing at 30°C (86°F). 1.6 Related Documentation ® The following documentation resources is related to the ONYXWorks system. ® • ONYXWorks Workstation Manual (P/N 52342) ®...
  • Page 13: Section 2 Nfn Gateway Pc Configuration

    2.2 About the Network Interface Card Installation ® The Network Interface Card is a PCI PC card plugs into any vacant PCI slot into ONYXWorks Workstation (v3.0 or later). It draws its power from the Workstation computer itself. The card is connected to NFN network through its network port.
  • Page 14: 1: Network Interface Card Layout

    NFN Gateway PC Configuration About the Network Interface Card Installation 2.2.1 Network Interface Card Layout This PC board is shipped with a shunt plug over the UPS SUPV pins. Remove the shunt to write for UPS supervision. Connect cable to the EIA-232 connector (J2) on the network card.
  • Page 15: Table 2.1 Ncs-Ncw/F Status Leds

    About the Network Interface Card Installation NFN Gateway PC Configuration Network Interface Card LEDs The following lists the LED indicators and their functions: Table 2.1 NCS-NCW/F Status LEDs Color Function A HI Green Channel A High Threshold (NCS-NCW only) STATA Yellow Channel A inactive for at least 16 seconds RCDA...
  • Page 16: 2: Network Interface Card Installation Procedure

    NFN Gateway PC Configuration About the Network Interface Card Installation 2.2.2 Network Interface Card Installation Procedure Typically the Workstation is ordered with the Network Interface Card already installed. However if the card is being retrofitted into an existing Workstation computer use the this information as a guideline to install it.
  • Page 17: 3: Network Interface Card Cable Connections

    About the Network Interface Card Installation NFN Gateway PC Configuration 2.2.3 Network Interface Card Cable Connections Network Interface Card EIA-232 Connection The Network Interface Card is connected to an available Workstation Comm Port. Figure 2.3 Workstation to IP Connection NFN Network Connection The Network Interface Card is connected to NFN network through its network port using one of the following methods: •...
  • Page 18: Nfn Gateway Pc Configuration Procedure

    NFN Gateway PC Configuration NFN Gateway PC Configuration Procedure 2.3 NFN Gateway PC Configuration Procedure 2.3.1 NFN Gateway Settings NCM Address Setting Step 1. Start the NFN Gateway PC (Start >NFN Gateway). The NFN Gateway icon is added to and displays in the Windows System Tray. Step 2.
  • Page 19: Figure 2.8 Nfn Gateway Pc Mode Setting

    NFN Gateway PC Configuration Procedure NFN Gateway PC Configuration About the NFN Gateway Mode Setting Figure 2.8 NFN Gateway PC Mode Setting The NFN Gateway PC’s operation mode matches the mode that has been selected using the Configuration Tool’s System Options functionality. Refer to the Workstation or Configuration Tool manuals for information about selecting these modes: Supervising Station Mode Refer to the Workstation manual for a “Proprietary Supervising Station Mode Overview”.
  • Page 20 NFN Gateway PC Configuration NFN Gateway PC Configuration Procedure NFN Gateway Installation & Operation Manual - P/N: 52307:Rev: D 06/01/07...
  • Page 21: Section 3 Nfn Config Tool Reference Information

    Section 3 NFN Config Tool Reference Information 3.1 NFN Config Tool Description The NFN Config Tool interface is used to display configuration information about NFN network and the NFN Gateway. With the appropriate access level a user can view and/or change the gateways settings and security.
  • Page 22: 2: Panel Properties Fields

    NFN Config Tool Reference Information Property/Value Field Descriptions 3.2.2 Panel Properties Fields Figure 3.2 NFN Config Tool Panel Property/Value Field Descriptions Node - Is used to change the NFN network address of the panel. VERSIONS If the NCM Version field is displayed in red, then the version doesn’t match the Local Node entry. NOTE: The NCM version for panel must match the NCM version displayed in the Local Node entry.
  • Page 23: Menu Descriptions

    Menu Descriptions NFN Config Tool Reference Information 3.3 Menu Descriptions 3.3.1 File • Login... - Is used to gain editing control over the gateway. The factory default password is 00000000 (eight zeros). Refer to “Login Password Settings” on page • Reboot Gateway - Restarts the gateway on its NFN network.
  • Page 24 NFN Config Tool Reference Information Menu Descriptions NFN Gateway Installation & Operation Manual - P/N: 52307:Rev: D 06/01/07...
  • Page 25: Index

    Index Architecture listed for the purpose 9 Gateway System 8 Audio 21 NCM Address 21 Channel A Threshold 21 Channel B Threshold 21 Proprietary Supervising Station 9 COMM Port 21 Configuration Tool installation 13 Style 7 21 Documentation 12 Tools menu descriptions 23 Trouble Reminder 21 Ethernet Network...
  • Page 26 Index NFN Gateway - P/N: 52307:Rev: D 06/01/07...
  • Page 27: Limited Warranty

    INC. SHALL NOT BE LIABLE FOR ANY PERSONAL INJURY OR DEATH WHICH MAY ARISE IN THE COURSE OF, OR AS A RESULT OF, PERSONAL, COMMERCIAL OR INDUSTRIAL USE OF ITS PRODUCTS. ® ONYXWorks Workstation - Installation & Operation Manual - P/N: 52307:Rev: D 06/01/07...
  • Page 28 World Headquarters 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 fax 203-484-7118 www.notifier.com...
