ADC Campus-Flex RS User Manual page 3

U T
SING HIS
This manual is organized as follows:
Chapter one describes the product and discusses Campus-flex architecture
and compatibility.
Chapter two describes how to install the ADC
Card in either a Campus-RS™ Desktop Unit (150-1158-01 or 150-1158-02)
or Campus-Star™ chassis (Campus-RS Line Unit, 150-1220-01).
Chapters three through five provide procedures on using the card to configure
and monitor a Campus-RS system.
Chapters six through nine provide reference material on viewing information
and status, testing, timeslot mapping (channel assignment), and timing.
The appendices provide additional the following background information:
•
Technical reference on defaults, pinouts, and menus
page A-1)
•
Abbreviations
•
The documentation set
•
Contacting ADC
Any changes or modifications not expressly approved by the grantee of this
device voids the user's authority to operate the equipment.
Campus-Flex RS Interface Card User Manual
M
ANUAL
(Appendix B on page
(Appendix C on page
(Appendix D on page
®
Campus-Flex
(Appendix A on
B-1)
C-1)
D-1)
Using This Manual
®
RS interface
iii
