HAMMER DRILL
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Item# 21404

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21404 and is the answer not in the manual?

Questions and answers

Related Manuals for Wel-Bilt 21404

Summary of Contents for Wel-Bilt 21404

  • Page 1 HAMMER DRILL OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 21404...

  • Page 2: Intended Use

    For technical questions please call 1-800-222-5381. INTENDED USE: Your Wel-bilt Hammer Drill has been designed for drilling timber and metal utilizing a normal drilling action and into masonry using hammer action TECHNICAL SPECIFICATIONS: Input current: 4.5A...

  • Page 3: Important Safety Considerations

    SAVE THESE INSTRUCTIONS IMPORTANT SAFETY CONSIDERATIONS • Stay alert, watch what you are doing and use common sense when operating the Hammer Drill. Do not use the Hammer Drill while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating the Hammer Drill may result in serious personal injury.
  • Page 4 ASSEMBLY Page of 10...

  • Page 5: Operation

    Attaching the auxiliary handle 1. The auxiliary handle provides additional control, support and guidance for the drill. 2. The auxiliary handle can be set to any position around the 360ºhandle collar mount. 3. Loosen the auxiliary handle grip by rotating it anti-clockwise to the handle collar. 4.
  • Page 6 2. The tool can be locked on by first depressing the trigger switch and then pressing the lock-on button. Fig E 3. Once the lock-on button has been engaged, the switch will remain locked on. 4. To turn the tool off, press and release the trigger switch. Speed control 1.

  • Page 7: Maintenance

    be very hot after even a short period of use. Drilling in all materials 1. Always use sharp drill bits. 2. Mark the place where the hole is to be drilled. 3. Commence with a slow speed to start the hole then increase the speed once the hole has been started.
  • Page 8 • Keep ventilation slots of the drill clean at all times and prevent any foreign matter from entering. • If the housing of the drill requires cleaning do not use solvents but a moist soft cloth only. Part list Part# Description Part# Description...
  • Page 9 For replacement parts and technical questions, please call 1-800-222-5381. Page of 10...
  • Page 10 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, •...
