Orientalert VST-C598IH User Manual

Carbon monoxide alarm
Hide thumbs

Advertisement

Quick Links

Download this manual
CAUTION
:
Read these instructions carefully before operating or serving and retain for future
MAIN FEATURES
AC/DC operated carbon monoxide alarm
Test / Hush button
High and stable sensitivity
Quick fix mounting bracket for easy installation
and simple AC connector for easy installation
Inter-connectable up to 40 units
Fitting and battery tamper-resist feature
LED operation indicator
Low-battery and battery missing warning indicator
Auto reset after the CO is clear
SPECIFICATION
Model Number:
Detection Type:
Power Source:
Operation Current:
Alarm Level:
Alarm Sound Level
Operation Temperature:
Ambient Humidity:
Note: This CO alarm can only be interconnected with other VST alarms specified.
IMPORTANT INFORMATION ABOUT CARBON MONOXIDE ALARM
1. WHAT IS CARBON MONOXIDE?
Carbon monoxide is a colorless, odorless and tasteless poison gas that can be fatal when inhaled. CO blinds to the hemoglobin
in the blood and inhibits its capacity to carry oxygen. CO kills hundreds of people each year and injures many more because it
is difficult to be detected with the human senses. In high concentrations, CO can kill in minutes.
Carbon Monoxide Alarm User's Manual
MODEL: VST-C598IH
reference.
VST-C598IH
Electrochemical
220-240V AC 50Hz and 9V DC Battery back-up
<60mA operation (mains)
50ppm (Between 60-90 min)
100ppm (Between 10-40 min)
300ppm (<3min.)
85 Decibels at 1 meter
5℃ to 38 ℃
15% to 90% Relative Humidity
V-MUL-019B(A0)

Advertisement

loading
Need help?

Need help?

Do you have a question about the VST-C598IH and is the answer not in the manual?

Questions and answers

Related Manuals for Orientalert VST-C598IH

Summary of Contents for Orientalert VST-C598IH

  • Page 1 V-MUL-019B(A0) Carbon Monoxide Alarm User’s Manual MODEL: VST-C598IH CAUTION Read these instructions carefully before operating or serving and retain for future reference. MAIN FEATURES AC/DC operated carbon monoxide alarm Test / Hush button High and stable sensitivity Quick fix mounting bracket for easy installation...
  • Page 2 2. SOURCES OF CARBON MONOXIDE Inside your home, appliances used for heating and cooking are the most likely sources of CO. Vehicles running in attached garages can also produce dangerous levels of CO. CO can be produced when burning any fossil fuel, such as gasoline, propane, natural gas, oil and wood.
  • Page 3 Installation of your CO alarm is only one step in your safety plan. Educate yourself and family to the sources and symptoms of CO poisoning and how to use your carbon monoxide alarm: Test your CO alarm weekly Replace the battery immediately once depleted Buy appliances accepted by a recognized testing laboratory Install the appliances properly, following the manufacturer’s instructions Have installations done by professionals...
  • Page 4 DO NOT INSTALL CO ALARMS Improper location can affect the sensitive electronic components in this alarm. To avoid causing damage to the unit,. to provide optimum performance, and to prevent unnecessary nuisance alarms: 1. The alarm is not be located within 1.5m (5 feet) of any cooking appliance. 2.
  • Page 5 4000 feet for #14 AWG (20 OHMS loop resistance). This CO alarm can be interconnected with as many as 40 other DC or AC ORIENTALERT s CO alarms and/or smoke/heat alarms. Do not connect to any other type or model CO alarms except the ones we specify. And this CO alarm is powered by 220-240V AC 50Hz and with 9V DC Battery back-up.
  • Page 6 60-90 10-40 <3 WARNING: This product may not alarm at low carbon monoxide levels. Individuals with medical problems may consider using warning devices which provide audible concentrations under 30 ppm. Hush Feature WARNING: • The Hush Feature is for your convenience only and will not correct a CO problem. Always check your home for a potential problem after any alarm.
  • Page 7 End of Life warning The horn sounds 2 short “chirps” following with 1 long “chirp”every minute. In case of the above warning happened, the CO alarm is end of life, and the CO alarm should be replaced to a new one. If your CO alarm sounder is beeping, and you are not sure if it is a CO alarm or malfunction alert, reset the alarm, open windows for ventilation, turn off fuel-burning appliance (like kerosene or oil heaters, furnaces, wood-burning stoves, water heaters, or other fossil-fuel burning appliances)

  • Page 8: Battery Replacement

    3. Install fresh 9V batteries and test the Alarm again. WARNING: • DO NOT try fixing the Alarm yourself – this will void your warranty! If the CO Alarm is still not operating properly, and it is still under warranty, please see "How to Obtain Warranty Service" in the Limited Warranty. Install a new CO Alarm immediately.

  • Page 9: What To Do If The Alarm Sounds

    Golden Power #6F22, Megaton #6F22; New Leader #6F22; Gold Peak #1604; Eveready #522, #1222; Golden Power G6F22; Golden Power GL6F22A. CO ALARM REPLACEMENT: CO Alarms don’t last enduringly. CO Alarms are sophisticated electronic devices with many parts. Although the alarm and its component parts have undergone stringent tests, and are designed to be very reliable, it is possible that parts can fail.

  • Page 10: Limited Guarantee

    Electronics Co, Ltd. makes no guarantee, express or implied, written or oral, including that of merchantability or fitness for any particular purpose with respect to battery. Manufacturer: Xiamen Vs-Top Electronics Co., Ltd. 2nd floor, No-107 Xiaguang Road, Xinyang Industrial District, Haicang ,Xiamen, China. Tel: 0086-592-6017700 Fax: 0086-592-6017711 E-mail: info@vs-top.com Website: www.orientalert.com...
