Summary of Contents for RSF Woodburning Fireplaces The CHAMELEON
- Page 1 Owner's Manual Residential Factory Built Fireplace Operation • Maintenance • Installation CHAMELEON Keep these instructions for future use. RSF-IIC_03-06...
-
Page 2: Table Of Contents
Dear Customer, The CHAMELEON combines technology and elegance to give you a beautiful view of the fire without compromising on heating efficiency or environmental quality. We have designed your new CHAMELEON to be easy to install, operate and maintain. It is in your best interest to become familiar with its operation. -
Page 3: Safety First
Use only firelogs that have been evaluated for fireplace use. In Canada, they should meet the requirements of ULC/ORD-C127-M1990. Refer to the firelog warnings and caution markings prior to use. CHAMELEON Owner's Manual RSF Woodburning Fireplaces... -
Page 4: General Specifications
The door is also a mandatory option on the CHAMELEON. To help you harmonize your fireplace into your decor, we offer a selection of door styles and colors: Cathedral (FO-TZDC) (in black only), black (FO-TZDB), gold (FO- TZDG) and pewter (FO-TZDP). -
Page 5: Operation
OPERATION AIR CONTROLS The CHAMELEON is designed to use outside air for combus- tion. The control for the outside air is located on the left side, underneath the door (see Figure 1). Pushing the control handle to the far right will completely open the outside air damper and allow fresh air into the base of the fireplace. -
Page 6: Maintenance
PAINT You can touch up the face of the CHAMELEON with Stove Bright Metallic Black high temperature paint which is available at most fireplaces dealers. Follow the directions outlined on the spray can. DO NOT attempt to paint the fireplace while it is still warm. - Page 7 The most important factor for controlling the burning rate of the CHAMELEON is a good seal on the door gasket. If the door gasket is worn or damaged to the point where the seal is not adequate as described above then remove and replace the gasket.
- Page 8 24” Hearth extension Intake Duct Option FO- CID: MANDATORY with Beneath hearth the Clean Facing (not extension the facing shown here) (Refer to text for particulars) Electrical knockouts Spark guard Figure 4: General Installation CHAMELEON Owner's Manual RSF Woodburning Fireplaces...
-
Page 9: Location
12" min. to side wall from the door 5” spark guard 5” x 36” 2” 38 1/2” 13 1/4” min. 16 min” 5 1/2” Beneath hearth extention Non-combustible flooring (Refer to text for particulars) Figure 5: Unit dimensions CHAMELEON Owner's Manual RSF Woodburning Fireplaces... -
Page 10: Ceiling Clearance
Outside air fireplace to the ceiling. connection Under no circumstances should the distance between the ceiling and the top of the CHAMELEON be less than 39" (see Figure 4). OUTSIDE AIR DUCT 2” aluminium After the fireplace is correctly positioned, connect the duct tape outside air inlet to the outside (see Figure 6). -
Page 11: Chimney Installation
CHAMELEON (30° or 45°) 3 metal screws in each joint Beneath hearth extension (Refer to text for particulars) Figure 8: Offset chimney installation example Figure 9: Offset chimney through a wall example CHAMELEON Owner's Manual RSF Woodburning Fireplaces... -
Page 12: Offset Chimney
Beneath hearth extension (Refer to text for particulars) above each offset to support the weight of the flue Figure 10: Chimney installed with chase enclosure (elbows cannot support a flue above an offset). example CHAMELEON Owner's Manual RSF Woodburning Fireplaces... -
Page 13: Chase Enclosure
The enclosure walls can be framed with any suitable materials (2 x 4 or 2 x 6 studs, plywood, gypsum board, etc.). Because of the high heat output potential of the CHAMELEON, combustible material must NOT go closer to the fireplace than the standoffs, top, back and sides. -
Page 14: Mantel
The CHAMELEON is offered with various facings. Refer to the facing installation instructions for particular details. Some facings require the installation of gravity vents and intake ducts while others do not. Make sure to have all the required options installed properly. -
Page 15: Mandatory Options With The Clean Facing
Replace the plug. 9. Finally, install the 2 front refractory bricks (11.6.CT on the left and 11.7.CT on the right) and the refractory plug (11.10.C) as shown in Figure 13g. CHAMELEON Owner's Manual RSF Woodburning Fireplaces... - Page 16 11.6.CT 11.10.C 11.5.CT 11.7.CT Side view Figure 13: Refractory brick installation Figure 13a 11.3.CT 11.1.CT 11.2.CT Figure 13b Figure 13c 11.8.CT Figure 13d Figure 13e 11.10.C 11.4.CT 11.6.CT 11.7.CT 11.5.CT Figure 13f Figure 13g CHAMELEON Owner's Manual RSF Woodburning Fireplaces...
-
Page 17: Fireplace Options
Chameleon Intake Duct (Mandatory with FO-CAMF-4) FO-CIF Chameleon Inline Fan FO-DUCT5 5 feet insulated flexible duct FO-FDGRK8 Gasket Replacement Kit FO-FDHB8 Circulating Internal Blower (for FO-CAMF-5 only) FO-FSC2 Firescreen FO-VCT Gravity Vent Kit (Mandatory with FO-CAMF-4) CHAMELEON Owner's Manual RSF Woodburning Fireplaces... - Page 18 We recommend that our products be installed and serviced by professionals who are certified in the U.S. by NFI (National Fireplace Institute) or in Canada by WETT (Wood Energy Technical Training). www.nficertified.org CHAMELEON Owner's Manual RSF Woodburning Fireplaces...
-
Page 19: Year Limited Warranty
30 years, subject to the following conditions: During the first year RSF Woodburning Fireplaces will repair or replace, at our option, any parts which upon examination by an authorized RSF Woodburning Fireplaces representative are found to be defective, except the parts listed in the EXCLU- SIONS portion of this warranty.
