- Page 1 AW5800XTR USER’S MANUAL 5.8 GHz IP Addressable Outdoor Ethernet Transceiver AvaLAN Industrial-grade, long-range wireless Ethernet systems...
- Page 2 AW5800XTR User’s Manual Thank you for your purchase of the AW5800XTR 5.8 GHz IP Addressable Outdoor Ethernet Transceiver. The AW5800XTR includes: • (1) AW5800XTR Radio Transceiver • (1) AW5-5800 Omnidirectional Antenna (The illustration on the manual cover shows the optional AW23-5800 High Gain Directional Panel Antenna.) • (1) 120 VAC to 12 VDC power adapter...
- Page 3 16 subscriber units per access point. The configuration may include any combination of AW5800XTR and AW5800XTP radios. (Please note that older AvaLAN 5800 MHz radios can exist on the same LAN but cannot be used to form wireless links with the AW5800XTR/XTP units because link encryption proto- cols have changed.)
- Page 4 “DATA IN” port on the POE. Connect a second cable from the “P + DATA OUT” port on the POE and the AW5800XTR. The AW5800XTR is provided with a cable clamping device that allows an RJ45 plug on the cable to pass through it and can be tightened down around the cable to provide a weatherproof seal.
- Page 5 User’s Manual AW5800XTR The AW5800XTR should appear in the list at the default IP address of 192.168.17.17. If it does not, click “Search” to regenerate the list. If it still does not appear, you have a connection issue and need to re-examine the cabling or you may have a firewall issue on your computer.
- Page 6 If you scroll down in the Admin browser page, you will come to three more sections: • A graphical spectrum analyzer display that may help you to select radio chan- nels that avoid interference • A section to be used if an update to the AW5800XTR’s firmware is required • An Advanced Links section with a dire warning about advanced users only.
- Page 7 User’s Manual AW5800XTR 8. On the Advanced Admin page, set the parameters as follows: • Choose Device Type: Access Point or Subscriber Unit. • For Subscriber Units, assign unique ID numbers in numeric order from 1 to 63. • For an Access Point, enter the number of Subscriber Units that will be com- municating with it.
-
Page 8: Limited Warranty
This product is warranted to the original purchaser for normal use for a period of 360 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This war- ranty does not cover defects resulting from misuse or modification of the product.
