AvaLAN AW900XTR User Manual

900 mhz ip addressable outdoor transceiver
Hide thumbs Also See for AW900XTR:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

AW900XTR
USER'S MANUAL
900 MHz IP Addressable Outdoor Transceiver
AvaLAN
Industrial-grade, long-range wireless Ethernet systems
W
I
R
E
L
E
S
S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW900XTR and is the answer not in the manual?

Questions and answers

Related Manuals for AvaLAN AW900XTR

Summary of Contents for AvaLAN AW900XTR

  • Page 1 AW900XTR USER’S MANUAL 900 MHz IP Addressable Outdoor Transceiver AvaLAN Industrial-grade, long-range wireless Ethernet systems...
  • Page 2 AW900XTR User’s Manual Thank you for your purchase of the AW900XTR IP Addressable Outdoor 900 MHz Wireless Ethernet Transceiver. The AW900XTR includes: • (1) Wireless transceiver in weatherproof die-cast aluminum package • (1) AW2-900 Flexible Antenna • (1) 120 VAC to 12 VDC power adapter • (1) AW-POE Power Over Ethernet Injector...
  • Page 3 User’s Manual AW900XTR Operational summary The AW900XTR Radio allows the user to create a long-range, wireless Ethernet net- work with up to 16 subscriber units per access point. The configuration may include any combination of AW900XTR and AW900XTP radios. (Please note that older AvaLAN 900 MHz radios can exist on the same LAN but cannot be used to form wireless links with the AW900XTR/XTP units because link encryption protocols have changed.)
  • Page 4 “DATA IN” port on the POE. Connect a second cable from the “P + DATA OUT” port on the POE and the AW900XTR. The AW900XTR is provided with a cable clamping device that allows an RJ45 plug on the cable to pass through it and can be tightened down around the cable to provide a weatherproof seal.
  • Page 5 The information on the left is the current status of the radio, while the boxes on the right allow you to change it. It is important that the IP address of the AW900XTR is in the same subnet as your computer. For example, if the subnet mask is 255.255.255.0 ( a class C network), the first three number groups of the IP address must match.
  • Page 6 If you scroll down in the Admin browser page, you will come to three more sections: • A graphical spectrum analyzer display that may help you to select radio chan- nels that avoid interference • A section to be used if an update to the AW900XTR’s firmware is required • An Advanced Links section with a dire warning about advanced users only.
  • Page 7 User’s Manual AW900XTR 8. On the Advanced Admin page, set the parameters as follows: • Choose Device Type: Access Point or Subscriber Unit. • For Subscriber Units, assign unique ID numbers in numeric order from 1 to 63. • For an Access Point, enter the number of Subscriber Units that will be com- municating with it.

  • Page 8: Limited Warranty

    This product is warranted to the original purchaser for normal use for a period of 360 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This war- ranty does not cover defects resulting from misuse or modification of the product.
