Child Restraint Features - RECARO ProRIDE Instruction Manual

WARNING!
A child CAN use this child restraint in the Forward-Facing position ONLY if:
• T he child is at least 12 months of age.
Forward-Facing position
• The child's weight is between 20 and 70
pounds (9.1kg and 31.7 kg).
• The harness CAN be positioned AT
or ABOVE the child's shoulders,
when the child is seated in the
Performance RIDE / ProRIDE .
• The child's standing height* is LESS
than 50 inches (127cm).
• When the child is sitting and the head restraint is in the highest
position, the top of the child's ears must be BELOW the top of the
head restraint.
• If ANY portion of the child's head exceeds the top edge of the child
restraint, there must be a vehicle headrest support.
NOTE: A child's standing height measures the distance from the
top of their head to the bottom of their feet, when they are standing.
Safety Stripe System
Your child restraint is equipped with the easy-to-use RECARO Safety
Stripe System . You will notice that your harness has a white stripe
TM
on the outside edges. This added safety feature will allow you to
ensure that your harness is not twisted. The white stripe should
always remain at the outside edge of the harness above the lower
buckle. If it is not, please loosen your harness system and remove
any twist prior to use.
DEATH or SERIOUS INJURY
can occur
(Select Models)
TM
10

Child Restraint Features:

It is important to become familiar with the features of your
child restraint system. These diagrams help you identify
key features.
Integrated 5-Point
Harness
Harness
Pockets (2)
Armrests (2)
Seat Base
Level Line
Seat Bottom
Head
Restraint
Trim Cover &
Comfort Padding
Chest Clip
Latch
Plates (2)
Adjuster
Lever
Cover
Harness
Recline
Adjuster Strap
Adjuster
11
Buckle
