- Page 1 SEC-CAMIP30 SEC-CAMIP40 SEC-CAMIP40EC MANUAL (p. 2) IP Cam System User’s Manual Manual IPCAM V4.0.3 EN...
-
Page 2: Table Of Contents
Contents IPCAM system ............................3 How to install ..........................3 How to Add a device into IP Cam System ..................5 Video via Internet..........................6 How to use IP Cam System......................8 Search Tool .............................. 17 How to use Search Tool........................ 17 Connect IP Cam and computer .................... -
Page 3: Ipcam System
1. IPCAM system 1.1 How to install Insert the software CD in your CD-R device, start the installation. Choose Shelexec.exe to start installing the software or check the disc contents and click the startup.html file to open the start up page. The following starting screen appears. - Page 4 1.1.1 Click Next to start the installation. 1.1.2 Click Next. 1.1.3 Click Install. 1.1.4 Click Finish to complete IP Cam System installation. Check the Finished box if you wish to run User’s Manual automatically. Note: Adobe Reader is needed Run DB Upgrade Tool to check if your application is ready for an upgrade. Click Upgrade if it prompts Incompatible database version as figure.
-
Page 5: How To Add A Device Into Ip Cam System
How to Add a device into IP Cam System 1. Select an empty channel 2. Click Add a device 3. Press Search or type in ID and Password of your device (Note: Search function can be used under local network only) 4. -
Page 6: Video Via Internet
Video via Internet 1. Select an empty channel 2. Select Add one device 3. Type in your Device ID / Password (Printed on the product body) Type in your User ID / Password (Set up by user, can be edited, please refer to Search Tool ) 4. -
Page 8: How To Use Ip Cam System
How to use IP Cam System A. IP Cam Setting Edit Device Setting Edit device Basic Info / Alarm Setting / Schedule recording Add one device Add a new device on display channel. Delete selected device Delete the selected device from display channel. Start all cameras Start all connection with camera device. -
Page 9: Alarm Setting
Basic Info Device ID Each individual ID shown on back of IP Cam Device Password Each individual password shown on back of IP Cam Channel Name Edit camera name. User ID / User Password Each user’s personal ID and password Channel Name Alarm Setting: After selecting Enable Alarm, click Motion detection setting to... - Page 10 Schedule Alert Add one duration Edit selected duration Delete selected duration Select Add one duration to schedule alarm Set days and time or full time alarming The icons below shows the status on this device Alarm has been enabled Alarm detected on channel Schedule recording...
-
Page 11: Schedule Recording
Schedule Recording: Select enable schedule recording Add one duration Edit selected duration Delete selected duration Select Add one duration to schedule recording Set days and time or full time recording B. Display Setting a. 4 Channel b. 6 Channel c. - Page 12 Search Tool Use to set up IP Cam (Local network only) System Setting Reconnect IP Cam Auto reconnects IP Cam when disconnected. Alarm Setting Sound effects file Select your preferable sound when alarming. Snap shot and video recording path Setup save folder for the recorded files and snapshots.
- Page 13 [LAN Mode] Your PC and IPCam are on local area network. (icon [P2P Mode] Images directly come from IPCam on Internet. (icon [Relay Mode] Images go through relay server. Slow frame rate. (icon This field shows PC's IP. This field shows the date and time when IPCam executed. ...
- Page 14 History of snapshot Image location Open folder Image history About IP Cam System Version of your IP Cam System and User’s Manual.
- Page 15 D. Display Channels Relay Mode Video source via local network Video source via Internet Frames per second Video recording Snapshot manually Shortcut function Right click on the display channel Disconnect Disconnect the device. Stretch video Stretch video display. ...
- Page 16 Snapshot Take picture of the selected device. Manual recording Start recording instantly. E. Device Control Selected device Shows the IP address/ Device ID of the selected camera Pan/Tilt Control For control the camera angle. (For selected model only) ...
-
Page 17: Search Tool
2 Search Tool How to use Search Tool Click IP CAM Setup Search Tool helps setting up your IP cam directly. Note: This software can be operated under the local network only Device List Basic Settings Authentication of Device Device List Search for cameras under local network Info of camera found Note:... - Page 18 Brightness Select brightness by clicking on Low, Standard, or High. Quality +: for clear picture and bigger file size for less picture quality and smaller file size Environment Please select the Indoor, Outdoor or Night mode, depending on the environment condition.
-
Page 19: Connect Ip Cam And Computer
Connect IP Cam and computer Use Search Tool to start the connection Disable Auto DHCP Setting Please click search, then select an IP cam on the list. Set IP address for PC and Camera Make sure the IPs of LAN and IPCAM are the same, except the last block... - Page 20 Changing IP Address in Windows Click Start button → Right click My Network Places icon → click Properties → Right click Local Area Connection icon → Click Properties → click Internet Protocol [TCP/IP] icon → click Properties IP address in PC...
-
Page 21: Ip Cam Mobile
3. IP Cam Mobile, see also starting screen Please download the dedicated video monitoring software for Apple OS4 and Android operation system. For further detail please visit web page as below: http://www.p2pipcam.com/3g All other Smart Phones users please use web browser to visit Allmycloud server as below: http://www.allmycloud.com Please refer to the example for iPhone as below and refer to the user’...
