Installation and User's Guide
Installation and User's Guide
1/2.5" PRIMARY COLOR CMOS HIGH SENSITIVE DAY/NIGHT HD CCTV
CHDC-22SDC / CHDC-22SDHSC
HD CCTV CAMERA
http://www.orionimages.com
All contents of this document may change without prior notice, and actual product appearance may differ
from that depicted herein
Advertisement
Table of Contents
Related Manuals for ORION Images CHDC-22SDC
Summary of Contents for ORION Images CHDC-22SDC
- Page 1 Installation and User’s Guide Installation and User’s Guide 1/2.5” PRIMARY COLOR CMOS HIGH SENSITIVE DAY/NIGHT HD CCTV CHDC-22SDC / CHDC-22SDHSC HD CCTV CAMERA http://www.orionimages.com All contents of this document may change without prior notice, and actual product appearance may differ...
-
Page 2: Table Of Contents
Thank you for choosing ORION Images high quality HD CCTV Camera. Please read this instruction manual carefully to keep your ORION Images product at peak performance for longer service duration. All ORION Images products are designed and manufactured with utmost care and craftsmanship to provide long life and high quality performance, if it is properly used and maintained as outlined in this manual. - Page 3 Installation and User’s Guide http://www.orionimages.com CAUTION The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device. Pursuant to Part 15 of the FCC Rules.
-
Page 4: Handling Precautions
Installation and User’s Guide http://www.orionimages.com 1. HANDLING PRECAUTIONS Do not install the camera in a water-splashed or highly humid environment. Do not use the camera where the ambient temperature drops below 0° C or rises above +50° C. The images and component parts may be adversely affected or the camera may not function correctly. Never open the camera case because there are precision electrical and electronic components inside and an accident may results. -
Page 5: Features
Installation and User’s Guide http://www.orionimages.com 4. FEATURES HD-SDI OUTPUT This camera outputs and HD-SDI signal featuring resolutions of 1080/25p, 30p, 50i, 60i or 720/30p, 50p, 60p SMPTE 292M standard. MULTI OUTPUT MODEL (CHDC-22SDHSC) It has outputs of HD-SDI, Composite, S-Video, HDMI, and YPbPr Component. NTSC / PAL OUTPUT This output can be used for a test or an adjustment. -
Page 6: Name Of Parts And Functions
Installation and User’s Guide http://www.orionimages.com 5. NAMES OF PARTS AND FUNCTIONS Top View Rear View ① BUILT-IN ZOOM LENS This is optical 10X zoom lens built in. 1/3.6” F=4.5~45mm, F1.8 ~ 2.2 ② CAMERA MOUNT These holes are for camera mount plate enclosed and provided in both top and bottom of the camera body. - Page 7 Installation and User’s Guide http://www.orionimages.com ⑦ MULTI IN / OUT This is 9-pin multi-connect to use with a multi-port cable used for DC12V power and a serial control ⑧ CVBS OUT (CHDC-22SDHSC ONLY) This is NTSC / PAL output (BNC) ⑨...
-
Page 8: Operation
Installation and User’s Guide http://www.orionimages.com 6. OPERATION 6-1. USER SETUP The camera has a remote controller as standard to set up and various picture quality setups, back light compensation, Day/Night for optimum reproduction. The SETUP can be easily executed using the On-Screen-Menu system. Alteration of these function may be needed for some installations and we recommend that you should spend some time to become acquainted with these functions so that the best results can be obtained from this high performance HD CCTV camera. -
Page 9: Entering The Setup Mode And Its Basics
Installation and User’s Guide http://www.orionimages.com 6-3. ENTERING THE SETUP MODE AND ITS BASICS Press ENT button on a remote controller to display the following OSD menu on the screen. ... - Page 10 Installation and User’s Guide http://www.orionimages.com Resolution : Select HD Output format (In 1920 x 1080 / 30p) out 1920 x 1080 / 30p (In 1920 x 1080 / 30p) out 1920 x 1080 / 30p (In 1280 x 720 / 60p) out 1280 x 720 / 60p (In 1280 x 720 / 30p) out 1280 x 720 / 30p (In 1920 x 1080 / 25p) out 1920 x 1080 / 25p (In 1920 x 1080 / 25p) out 1920 x 1080 / 50i...
- Page 11 Installation and User’s Guide http://www.orionimages.com 6-3-6. FLICKERNESS If you see a flicker on the screen, please use this function and select ON, ON (50Hz fixed) or ON (60Hz fixed). 6-3-7. WHITE BALANCE You may select Manual, Auto, (Tungsten, Fluorescent D, Fluorescent N, Fluorescent W, Shade or Cloudy) When selected “MANUAL”, you may need to select X/Y values.
- Page 12 You can select Disable or Enable for OSD auto disappear function 6-3-15. SERIAL ID You can set your ID (number 1 ~ 7) and Baud rate (default is 19200). Please visit http://www.orionimages.com/product/CHDC-22SDC.asp to download a remote application software. (see figure 1.1 for application menu) Figure 1.1 (Application Menu)
- Page 13 Installation and User’s Guide http://www.orionimages.com 6-3-16. RESET Select “YES” to go back all settings to factory default. 6-3-17. EXIT Select either “SAVE & EXIT” or “EXIT WITHOUT SAVING” your camera set up. pg13 7300 Bolsa Avenue, Westminster CA 92683 / Tel: 714-766-6300 / Fax: 714-766-6310...
-
Page 14: Application Of Output
Installation and User’s Guide http://www.orionimages.com 7. APPLICATION OF OUTPUT pg14 7300 Bolsa Avenue, Westminster CA 92683 / Tel: 714-766-6300 / Fax: 714-766-6310... -
Page 15: Specifications
Installation and User’s Guide http://www.orionimages.com 8. SPECIFICATIONS CHDC-22SDC & CHDC-22SDHSC Image Sensor 1/2.5” CMOS Effective Pixel 2.2 M Pixel Sync System Internal HD-SDI (SMPTE 294M) / 75 ohm BNC x 1 1920 x 1080 30p / 25p / 60i, 1280 x 720 60p / 50p... -
Page 16: Outline Dimension
Installation and User’s Guide http://www.orionimages.com 9. OUTLINE DIMENSION Unit: mm Side View Front View pg16 7300 Bolsa Avenue, Westminster CA 92683 / Tel: 714-766-6300 / Fax: 714-766-6310... -
Page 17: Warranty And After-Sale Service
Keep this card in a safe place. Please consult ORION Images Corporation or your dealer for full warranty information. Your dealer will repair or replace free of charge within the warranty period according to the warranty coverage. - Page 18 Installation and User’s Guide http://www.orionimages.com pg18 7300 Bolsa Avenue, Westminster CA 92683 / Tel: 714-766-6300 / Fax: 714-766-6310...
