Connections
Cold water supply
Connect water-inlet hose (Figure 6)
- Minimum water pressure: 0.1 MPa or 1 bar
- Maximum water pressure: 1 MPa or 10 bar
Drain
Mount drain hose with the supplied elbow,
connect to a vented drain (Figure 7.1/7.2) .
The elbow must be between 65 and 90 cm
above the floor.
Secure drain hose against slipping off.
Replacing the water-inlet hose
After replacement, check to ensure
connections are tight and that there are
seals on both ends.
Regularly check the condition of the
water-inlet and drain hose Replace
damaged hoses only with original
replacement parts which are available
through Customer Service.
Figure 6
Figure 7.1
Figure 7.2
8
3/4"
