Connecting - TC-Helicon VoiceTone C1 User Manual

PA
PA
•
Turn down your PA when making all connections
• The latest version of VoiceSupport is available free from www.tc-helicon.com/voicesupport
• The USB connection does not provide power to the unit
• If you hear hum from your PA or amp, push the GRND LIFT in. Otherwise, it should remain out.

Connecting

MIC jack - Connect your mic here using a balanced XLR cable.
Phantom power is always on.
OUT jack - Connect to your PA mixer, another VoiceTone pedal
or powered speaker.
Power in - Connect the supplied 12VDC power supply.
Optional:
USB - Connect to a computer running the TC-Helicon
VoiceSupport application for registration, latest version and tips.
INST IN - Chords played on this instrument will be recognized
when the Key selector is set to Chromatic.
INST OUT - Connect to a PA or guitar amp to hear your
instrument.
