  • Page 1 IBM 9.4/4.7 GB DVD-RAM Drive User’s Guide OPTIONS by IBM...
  • Page 2 Appendix C, ″Product warranties and notices″ on page C-1. First Edition (August 2000) © Copyright International Business Machines Corporation 2000. All rights reserved. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.
  • Page 3 Safety: Read first . Preface Installation and user’s guide. Appendix A. Problem solving . Appendix B. Help and service information . Appendix C. Product warranty and notices © Copyright IBM Corp. 2000 . vii . 1-1 . A-1 . B-1 . C-1...
  • Page 4 IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...

  • Page 5: Safety: Read First

    Avant d’installer ce produit, lisez les consignes de sécurité. Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Lees voordat u dit product installeert eerst de veiligheidsvoorschriften. Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. © Copyright IBM Corp. 2000...
  • Page 6 Pred inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy. Antes de instalar este producto lea la información de seguridad. Läs säkerhetsinformationen innan du installerar den här produkten. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza. IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...

  • Page 7: Registering Your Option

    Your feedback is valuable to us in developing products and services that are important to you, as well as in developing better ways to communicate with you. Register your option on the IBM Web site at http://www.ibm.com/pc/register...
  • Page 8 IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...

  • Page 9: Software Description

    Installation and user’s guide This section contains the product description, hardware and software ® installation instructions, and operating information for the IBM 9.4/4.7 GB DVD-RAM Drive. Product description 9.4/4.7 GB DVD-RAM Drive with MPEG-2 Software This option package is intended for multimedia applications. The drive comes with a CD containing MPEG-2 decoder software for Microsoft Windows 98, Windows 95, Windows 2000, Windows NT, and Windows Me.

  • Page 10: Installation Requirements

    Handle the drive with care. Dropping or jarring the drive can damage the components inside the drive housing. v Do not force insertion of the IDE or power cables. Doing so might damage the connector or the drive. IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide ® ® Pentium...

  • Page 11: Drive Controls And Connectors

    Drive controls and connectors The following diagrams show the location and functions of the drive controls and connectors. Front view of the drive 1 Disc drawer This drawer is where you load and unload a disc. 2 Headphone jack This jack provides audio output to the headphones. 3 Volume control This dial controls the headphone volume.

  • Page 12: Installing The Drive

    1. Before opening the antistatic bag that the drive is packed in, touch the bag to an unpainted metal surface for at least two seconds. This drains the static electricity from the package and your body. 2. Remove the drive from the bag. IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide Pin 1...
  • Page 13 Some non-IBM computers use special ATA cables with two wires reversed in the device connectors so that the drives can be configured by the cable instead of by jumper position.
  • Page 14 Step 5. Attaching the cables to the drive The following diagram shows where to connect the cables to the drive. The following is an illustration of the internal audio cable that comes with your option package. IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...
  • Page 15 5. Plug all power cords into the wall outlets. Step 7. Verifying device driver installation in Windows NT Some IBM computers with preinstalled Windows NT 4.0 contain a PIIXIDE device driver. This device driver replaces the Windows NT 4.0 native ATAPI device driver and provides DMA support.
  • Page 16 7. Select the DVD-RAM device in the menu display. 8. Click Properties. 9. Click the Settings tab to view the DMA option in the Options window. 10. Select the check box next to DMA. IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...
  • Page 17 Web site. The following is a list of manufacturer Web sites that contain Windows NT 4.0 DMA device drivers for system boards: v IBM: http://www.ibm.com v Intel: http://www.intel.com v VIA: http://via.com.tw v ALi: http://ali.com.tw...
  • Page 18 Note: Be sure that your Windows NT 4.0 operating system has the latest Service Pack for Windows NT that is provided by Microsoft. Refer to the documentation that comes with your computer to determine if there is 1-10 IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...
  • Page 19 an Intel chipset in your computer. For more information on installing Windows NT Service Packs, visit the Microsoft Web site at http://www.microsoft.com. To enable DMA in Windows NT 4.0, do the following: 1. Log on as an administrator. 2. Disable the CD-ROM device driver using the following instructions: a.
  • Page 20 1. Insert the tip of a ball point pen into the hole located in the ″Protect″ slot of the cartridge 1 and push the slider towards the top of the cartridge 2 to 1-12 IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...

  • Page 21: Removing The Disc From The Cartridge

    protect the media. 2. Reverse the procedure to enable writing on the media again. Using single- and double-sided DVD-RAM media DVD-RAM media is available in single-sided and double-sided versions. 2.6 GB and 4.7 GB versions are single-sided and are available in Type I or Type II cartridges.
  • Page 22 Do not touch the recording side of the disc when handling the bare media. 1-14 IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...
  • Page 23 Returning the disc to the cartridge To return the disc to the cartridge, align the label side of disc 1 with the DVD-RAM cartridge label side. Insert the disc and close the cartridge lid 2 . A clicking sound will ensure the lid door is closed. Precautions for handling Be careful when handling the removed disc.
  • Page 24 Using the MPEG-2 decoding software This section describes how to use and customize the MPEG-2 decoding software. You can find current information on MPEG-2 decodingsoftware in the readme file on the MPEG-2 decoding software CD. 1-16 IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...

  • Page 25: Changing The Dvd Region Code

    Changing the DVD region code Attention: Regionalization and Copy Protection (the DVD region code) uses the content scramble system (CSS) standard to prevent unauthorized duplication of the intellectual property rights distributed on DVDs. It was originally requested by the Motion Picture Association of America (MPAA) to address video piracy, but is applicable to any content.
  • Page 26 Keep the original packing materials. If you need to ship the drive unit to a different location, use the original packing materials to ensure that the drive is transported safely. 1-18 IBM 9.4/4.7 GB DVD-RAM Drive: User’s Guide...
