INSTALLATION AND OPERATION This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions. This symbol is intended to alert the user to the presence of “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electrical shock.
This unit provides a high level of reliability with low noise, a high output level and excellent performance to price ratio. The automatic gain control (AGC) range is -6dBm~+1dBm providing a stable output level that remains within 0.5 dB. The FT-FRXID-RM-SCAPC has two RF outputs with an output level of 35 dBmV.
Open box and inspect for damages. Locate the optical receiver, power cord, and user’s manual. 2. Mounting The FT-FRXID-RM-SCAPC is a rack mountable 1RU device. To ensure sufficient cooling, it is recommended to leave 1.75” spacing above and below device. 3. Making Connections Plug the power cord into the power supply socket and switch the power on.
Page 5
“RF OUT 1” and “RF OUT 2” may be connected to outside distribution via F-style connectors to coaxial cable. The -20dB “RF OUT TEST” is connected in the same fashion.
