i. Tech Dynamic Wireless Headphone Arrow Lite User Manual

Arrow Lite-R
Arrow Lite-R Overview
1
2
3
5
4
Fig.1

Getting Started

To use your Arrow Lite-R Bluetooth Headset ("the headset"), please follow the steps below:
1. Ensure your headset is fully charged
2. Pair your charged headset with a Bluetooth-enabled mobile phone
Wearing Your Arrow Lite-R
Fig. 2 Wearing your headset
ENGLISH
1 Status Indicator (This small
light will flash red, green or
orange dependant on
pairing mode and
operation)
2 Multi-function Button (MFB)
3 Charging Socket
8
4 Built-in Microphone
7
5 Built-in Rechargeable
Battery
6
6 Ear Hook
7 Volume Button(+/-)
8 Earpiece
Product Specifications
Bluetooth Specification:
Bluetooth Profiles Supported:
Range of Frequency:
Reception Distance:
Normal Charging Time:
Talk Time*:
Standby Time*:
Dimensions:
Weight:
*may vary due to users' operation mode and mobile phone settings
Declaration of Conformity
We, i.Tech Dynamic Ltd., declare that the following product:
Product Name: Arrow Lite-R
Model No.: C51-A06104-XX
Is in conformity with the following essential requirements of Council Directive 1999/5/EC
( referred to as R&TTE Directive ) : Article 3.1a, 3.1.b and 3.2. and the product is
manufactured in accordance with Annex II of above directive.
A copy of the Declaration of Conformity can be found at:
http://www.itechdynamic.com
1
Charging Your Headset
Charger
The headset comes with a built-in rechargeable battery. Prior to using the headset for the first time, it
is recommended to fully charge the battery first.
Important : The headset will turn off and no operation while in charging mode. For details, please refer
to "Charging your headset" section.
Insert the charger plug into the headset's charging socket (refer to Figure 3) and plug the mains charger
to an AC wall outlet. The light on the Arrow Lite-R (status indicator) will stay red during charging.
IMPORTANT: Charging indication will be delayed for a few seconds if the headset has not been used for
a long time or the battery is drained.
Normal Charging Time
It takes about three hours to fully charge the battery. When the battery is fully charged, the status
indicator will turn off. Unplug the mains charger from the AC wall outlet and the
3
v2.0+EDR Class 2
Headset and Handsfree
2.4GHz Spectrum
10 metres
Within 3 hours
Up to 7 hours
Up to 120 hours
57.6 (L) x 20.7 (W) x 25.8 (H) mm
13.7 grams
Charger Plug
Charging
Socket
Fig.3
2
4
