- Page 1 I.D. AL - FLASH MPX SD - interactive video player - User manual Flash MPX SD MANUAL ® Waves System V 1.0 - 2011...
-
Page 2: Table Of Contents
Information in this manual is subject to change without notice and do not represent any commitment from Waves System. The equipment described in this manual is supplied under condition of the terms of license specifying the legal use conditions. This manual can’t be reproduced or used, in whole or in part, in any form and by any mean, for other use than private, without the written permission from Waves System. -
Page 3: A - Safety Instructions
‘Caution!’ messages included in this manual. This device, made by Waves System, has been designed in a way that practically eliminates any risk if it is used in accordance to its intended purpose. Nevertheless, with a concern for safety, we would like to draw your attention to the following instructions: •... - Page 4 I.D. AL - FLASH MPX SD - interactive video player - User manual conversion of the device automatically entails loss of the homologation. The operation of a modified device is liable to a penalty. In the interest of occupational safety, the operator and the user are held responsible for complying with the regulations.
-
Page 5: B - Product Information
I.D. AL - FLASH MPX SD - interactive video player - User manual A.6 - Terms of use: • This product has been designed for indoors use only. • If this device has been exposed to very high temperature fluctuations (e.g.: after transportation), do not connect it immediately. -
Page 6: Product Presentation
I.D. AL - FLASH MPX SD - interactive video player - User manual 1 - Product presentation The Flash MPX SD is an Audio/Vidéo player. The files are stored on an USB stick, SD card or Compact Flash. This standalone player can read files automatically when switch on. -
Page 7: Installation
I.D. AL - FLASH MPX SD - interactive video player - User manual 2 - INSTALLATION 1 - On/Off switch 2 - Compact Flash connector 3 - SD card connector 4 - USB connector 5 - LEDs 6 - Infrared sensor... -
Page 8: First Use
3 - First use Connect the Flash MPX SD on a video display and insert a media (USB stick, SD card, CF) with few mpeg video files. Connect the PSU and switch on. You can see your video. If no media is detected, you will see a jpeg background image. -
Page 9: Quick Start
I.D. AL - FLASH MPX SD - interactive video player - User manual 4 - Quick Start The Flash MPX SD plays from : - USB falsh memory - SD card or Compact Flash memory Don’t use name over 8 characters. No space ->... - Page 10 - When switch on, Flash MPX SD play «myvideo.mpg» in loop. - With a contact on input 1, Flash MPX SD play «file1.mpg» and return to the root file «myvideo.mpg» - With a contact on input 2, Flash MPX SD play «file2.mpg» and return to the root file «myvideo.mpg»...
-
Page 11: Input Modes
5 - Input modes 5.1 - Standard mode playlist.txt is a text file that contains the Flash MPX SD setup and instruction on how you want the input (push button) to play the files that are located inside the file folder. - Page 12 ** : File can not be nterrupted Special codes : - Code «00» 010000=file1.mpg After read «file1.mpg», Flash MPX SD return to the root and read the files - Code «99» 010099=file1.mpg Flash MPX SD stop and wait a new command. Display a black screen.
- Page 13 I.D. AL - FLASH MPX SD - interactive video player - User manual Annexe A - Specifications • Power supply : 12V DC • Size : Width : 160mm - Height : 28mm Depth without connector : 135mm • Connectors : - Audio/Vidéo :...
