- Page 1 MX SERIES USER' S MANUAL USER' S MANUAL MX SERIES MIXER TAPE/USB TO MIX NF03483-1.0...
- Page 2 SAFETY RELATED SYMBOLS Protective Ground Before turning the unit ON, make sure that it is connected to Ground. This is to prevent the risk of electric shock. Never cut internal or external Ground wires. Likewise, never remove Ground wiring from the Protective Ground Terminal. This symbol, wherever used, alerts you to the Operating Conditions presence of un-insulated and dangerous voltages...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION..................1 2. FEATURES..................1 3. USEFUL DATA..................1 4. CONTROL ELEMENTS.................3 5. INSTALLATION TIPS ................8 6. WIRE CONNECTIONS.................9 7. BLOCK DIAGRAM ................10 8. TECHNICAL SPECIFICATION.............14 9. GUARANTEE ..................15... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing the MX series mixing console. This series include four mixers (MX.5/MX.6USB/MX.10USB/MX.12USB). There is 2-band EQ on all mono channels (MX.5), and3-band EQ on mono channels and stereo channels (MX.6USB/MX.10USB/MX.12USB). These mixers are really ideal for small club gigs. - Page 5 HOOKUP DIAGRAM Small Club Gig Mono in/Stereo out Reverb Microphones 1 and 2 Headphones Active Speakers TAPE/USB TO MIX Keyboard Drum Machine DAT Recorder CD Player Computer Set-up Microphones Active Studio Monitors Headphones Direct Box Digital Audio TAPE/USB TO MIX Workstation Guitar Digital Audio Interface...
-
Page 6: Control Elements
LINE inputs. The adjustable range goes from 0 dB to 50dB. EQUALIZATION The MX series has 3-band EQ on all mono channels (except MX.5 has 2-band EQ). And only the MX.6 USB has EQ controls on stereo channels. All bands provide up to 15 dB boost or cut. - Page 7 CONTROL ELEMENTS 7- 75 Hz Low-Cut Switch (MX.10 USB/MX.12 USB only) By pressing this button you will activate a 75Hz low frequency filter that cuts the bass frequency below 75Hz. You can use this switch to reduce the hum noise caused by the mains power supply, or the stage rumble while using a microphone.
- Page 8 CONTROL ELEMENTS 13- CD/TAPE INPUTS Use the Tape Input if you wish to listen to your mixer from a Taper Recorder or DAT . When the TAPE TO MIX switch is pushed in, the signal coming from Taper Recorder will assign to main mix; when the CD/TAPE switch which on the front panel is engaged in the signal can also be assigned to the CONTROL ROOM/PHONES outputs.
- Page 9 CONTROL ELEMENTS 22- METERS This stereo LED meter will indicate the level of the overall output signal. 23- MAIN MIX This control sets the level of main mix signals sent to the Main Outputs, Tape Outputs, CONTROL ROOM, PHONES, and LED Display. On the MX.5 and MX.6 USB, this is a rotary control;...
-
Page 10: Installation Tips
INSTALLATION TIPS 29- USB interface The USB interface provides a digital audio connection to PC/MAC. USB use With this interface you can use the MX.6USB/10USB/12USB like sound card for recording at 16bit/44.1kHz and playback audio file(wave, aiff, mp3 etc.) With Windows and Macintosh computers. -
Page 11: Wire Connections
WIRE CONNECTIONS Either the 1/4" TRS phone jack or XLR connector can be wired in balanced and unbalanced modes, which will be determined by the actual application status, please wire your system as the following wiring examples: For 1/4" Phone jack TAPE/USB TO MIX Ring... -
Page 12: Block Diagram
BLOCK DIAGRAM MX.5... - Page 13 BLOCK DIAGRAM...
- Page 14 BLOCK DIAGRAM TAPE/USB TO MIX TAPE/USB TO MIX...
- Page 15 BLOCK DIAGRAM...
-
Page 16: Technical Specification
TECHNICAL SPECIFICATION Model Number MX Series Mixer Frequency Response Mic Input to any Output (Trim at 0 dB) 10 Hz to 150 kHz +0, -1 dB -3 dB 10 Hz to 200 kHz 20 Hz to 20 kHz Distortion THD and SMPTE IMD Mic Input to Main Output <0.005% @+4 dBu output... -
Page 17: Guarantee
GUARANTEE Topp Pro guarantees the normal operation of the product against any defect of manufacture and/or vic e of materia l, by the term o f (12) months, counted as of the date of purchase on the part of the user, committing itself to repair or to change, to its e lection, wi thout pos itio n some , any piece or component that will fail in normal conditions of use within the mentioned period.
