- Page 1 Digital Moisture Control Thermostat Installation and Operation Manual PNEG – 1711 Date: 2009 PNEG - 1711 Page 1 of 22 06/30/2009 Digital Thermostat Owner’s Manual...
- Page 2 6. Before attempting to remove and reinstall the fan blade, make certain to read recommended procedure listed within the SERVICING section of the manual. 7. Keep the dryer and wet holding equipment CLEAN. Do not allow fine material to accumulate. PNEG - 1711 Page 2 of 22 06/30/2009...
- Page 3 14. The operating and safety recommendations in this manual pertain to the common cereal grains as indicated. When drying any other grain or products, consult the factory for additional recommendations. 15. Routinely check for any developing gas plumbing leaks. Check LP vaporizer for contact with burner vanes. PNEG - 1711 Page 3 of 22 06/30/2009...
- Page 4 PNEG - 1711 Page 4 of 22 06/30/2009 Digital Thermostat Owner’s Manual...
- Page 5 PNEG - 1711 Page 5 of 22 06/30/2009 Digital Thermostat Owner’s Manual...
- Page 6 PNEG - 1711 Page 6 of 22 06/30/2009 Digital Thermostat Owner’s Manual...
- Page 7 PNEG - 1711 Page 7 of 22 06/30/2009 Digital Thermostat Owner’s Manual...
-
Page 8: Table Of Contents
Table of Contents TABLE OF FIGURES ................................ 9 CONTENTS ................................10 INSTALLATION .................................10 OPERATION ................................13 EXAMPLE SETUP ..............................18 TROUBLESHOOTING GUIDE ...........................18 DRILL DIMENSIONS TO SCALE ..........................19 WARRANTY ................................21 PNEG - 1711 Page 8 of 22 06/30/2009 Digital Thermostat Owner’s Manual... -
Page 9: Table Of Figures
Figure 6 - Default On / Off Screen .............................16 Figure 7 - Engaged Mode, notice the temperature to the left ....................17 Figure 8 - Disengaged Mode, notice the temperature to the right ..................17 PNEG - 1711 Page 9 of 22 06/30/2009... -
Page 10: Contents
Refer to Figure 1 for drilling dimensions. Make sure all wires and human limbs are out of the way when drilling. Section 6 is a drawing to scale that can be removed from this manual to be used as a guide for drilling the holes. PNEG - 1711 Page 10 of 22 06/30/2009... -
Page 11: Figure 1 - Drill Pattern
GSI moisture control. Remove the four Phillip head screws from the corner of the controller to access the connections on the GSI controller. Table 1 - Honeywell to GSI relation Honeywell Connection # Connection # PNEG - 1711 Page 11 of 22 06/30/2009 Digital Thermostat Owner’s Manual... -
Page 12: Figure 2 - A1 Through A3 Connections
Figure 2 - A1 through A3 Connections Figure 3 - B1 through B6 Connections PNEG - 1711 Page 12 of 22 06/30/2009 Digital Thermostat Owner’s Manual... -
Page 13: Operation
“SET” button is pressed. While in the setpoint menu, if the user allows approximately twenty-five seconds to pass without pressing a button, the menu is exited and the new setpoint is not saved. PNEG - 1711 Page 13 of 22 06/30/2009... - Page 14 This is only applicable when the controller is in Hi / Lo mode. See Section 3.3.1 for behavior. Range from 10 to 30 degrees. 3.2.6 Temperature Differential See descriptions of mode operations for behavior. Range from 1 to 10 degrees. PNEG - 1711 Page 14 of 22 06/30/2009 Digital Thermostat Owner’s Manual...
-
Page 15: Figure 5 - Default Hi / Lo Screen
“On” state. If the sensor temperature rises above the setpoint plus the differential, the Thermostat will be in the “Off” state. The relay position in each state is depicted below. PNEG - 1711 Page 15 of 22 06/30/2009 Digital Thermostat Owner’s Manual... -
Page 16: Figure 6 - Default On / Off Screen
If the controller is in the “Engaged” mode, the current sensor temperature is displayed on the left side of the screen (see Figure 7). If the controller is in the “Disengaged” mode, the current sensor temperature is displayed on the right side of the screen (see Figure 8). PNEG - 1711 Page 16 of 22 06/30/2009... -
Page 17: Figure 7 - Engaged Mode, Notice The Temperature To The Left
Figure 7 - Engaged Mode, notice the temperature to the left Figure 8 - Disengaged Mode, notice the temperature to the right PNEG - 1711 Page 17 of 22 06/30/2009 Digital Thermostat Owner’s Manual... -
Page 18: Example Setup
Check the input power of the controller Relay(s) does not open and close as Replace controller described in this manual If problem is not resolved above, contact GSI Service Department at (217) 226-5500. PNEG - 1711 Page 18 of 22 06/30/2009 Digital Thermostat Owner’s Manual... -
Page 19: Drill Dimensions To Scale
6. Drill Dimensions to Scale PNEG - 1711 Page 19 of 22 06/30/2009 Digital Thermostat Owner’s Manual... - Page 20 PNEG - 1711 Page 20 of 22 06/30/2009 Digital Thermostat Owner’s Manual...
-
Page 21: Warranty
7. Warranty Limited Warranty The GSI Group, LLC. (“GSI”) warrants products which it manufactures to be free of defects in materials and workmanship under normal usage and conditions for a period of 12 months after sale to the original end- user or if a foreign sale, 14 months from arrival at port of discharge, whichever is earlier. - Page 22 Prior to installation, the end-user has the responsibility to comply with federal, state and local codes which apply to the location and installation of products manufactured or sold by GSI. PNEG - 1711 Page 22 of 22 06/30/2009 Digital Thermostat Owner’s Manual...
