Hamlet HXDAS25 User Manual

2bay raid system usb 3.0 mobile raid enclosure for two 2.5” sata hard drives

Advertisement

2BAY RAID SYSTEM USB 3.0 MOBILE
RAID Enclosure for Two 2.5" SATA Hard Drives
USER MANUAL
HXDAS25
www.hamletcom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HXDAS25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hamlet HXDAS25

  • Page 1 2BAY RAID SYSTEM USB 3.0 MOBILE RAID Enclosure for Two 2.5” SATA Hard Drives USER MANUAL HXDAS25 www.hamletcom.com...
  • Page 2 Hamlet at info@hamletcom.com. The information on the importer for your country can be found in the “About Us” section of the Hamlet website at www.hamletcom.com. Trademarks and changes All trademarks and company names mentioned in this manual are used for description purpose only and remain property of their respective owners.
  • Page 3: Specifications

    Introduction Features Supports JBOD, RAID0,RAID1,Normal mode • Enhanced data protection and high-performances storage • Support with USB3.0 high speed reach up to 5.0Gbps • Supports Plug-play and Hot-plug • Support mode select by RAID switch • Specifications Inner Interface: SATA •...
  • Page 4: Package Contents

    Package Contents Dual bay enclosure 2.5” • USB 3.0 cable • USB power cable • Manual • Screws & screw driver • Setting the RAID Mode RAID (Redundant Array of Independent Disks) is a set of technology standards for teaming disk drives to improve fault tolerance and performance.
  • Page 5 Normal Mode (Non-Raid) Normal mode, it's the default setting of HDD enclosure, and will not use any RAID mode. In Normal condition, both of the two hard disk mode inside the enclosure are in independent operation state, and also will be identified as the two separate hearts in the system, users can choose any hard drive for storing files.
  • Page 6 FAST Mode (RAID 0/Striping) FAST mode it's also our familiar RAID 0 mode. In RAID 0 state, data storage is divided into two parts, respectively in two hard disk storage, then the theory storage speed of hard disk is twice the one of single block hard disk.
  • Page 7 SAFE Mode (RAID 1/Mirroring) Safe mode is RAID 1 mode. In this state, two hard drives are closely mirrored. The actual capacity of portable hard drive equals to the smaller capacity one, storage speed is same.as a single block of hard disk. The advantage of RAID 1 lies that any piece of hard disk stored data losing, others can not lose, its weakness is the capacity loss of hard drive is bigger.
  • Page 8: System Setup

    System Setup Hard Drive Installation Follow the instruction below to install the hard drives. Take out the two screws on the rear panel. Pull out the inner HDD tray from the aluminum shell. Insert the HDDs into the 7+15P SATA connectors on the corresponding PCBA.
  • Page 9 Insert the inner HDD tray back into the aluminum housing. Close the rear cover. The HDDs installation is now completed.
  • Page 10: Connect To Computer

    Connect to computer Connect the mini USB end of the USB cable into the mini USB port of the HDD enclosure. Connect the other end of the USB cable (type A) into any active USB port of the computer. Connect the USB power cable to the enclosure and into an available USB port of the computer.
  • Page 11: Replacing Hard Drives

    Replacing Hard Drives When one drive fails, the HDD LED will display below state: If HDD1 fails: LED1 is off. If HDD2 fails: LED2 is off. If one drive fails and the RAID mode is set to RAID0 or JBOD, the data will be lost and the system can not be accessed again until the drive have been replace.
  • Page 12 FAQs Can I use external USB hub? Yes, USB hub works in the same way as the computer USB ports. My computer doesn't have USB 3.0 port, can I use USB 3.0 host adaptor? USB 3.0 host adapter works in the same way as the built-in USB ports.
