- Page 1 6m DISCOVERY LINEAR AMPLIFIER (GS – 31) Operating Manual WiMo Antennen und Elektronik GmbH Am Gäxwald 14, D-76863 Herxheim Tel. (07276) 96680 FAX 6978 http://www.wimo.com e-mail: info@wimo.com...
- Page 2 1Amp plate current or to drive with more than 100W continuous wave drive. Also, care should be taken not to exceed 1.5 : 1 SWR. WiMo Antennen und Elektronik GmbH Am Gäxwald 14, D-76863 Herxheim Tel. (07276) 96680 FAX 6978 http://www.wimo.com...
-
Page 3: Specifications
1. SPECIFICATIONS Function………………….The 6m Discovery is a desk top linear RF amplifier with a nominal output of 1000W covering the range 50 – 54MHz for amateur radio use. Type of emission…………………………………………………SSB/FM/CW/RTTY Dimensions………………………………….……14in wide x 9.75in high x 17in deep 360mm x 250mm x 430mm Weight……………………………………………………………………………..25kg Output power…………………………………...…………………….1000W CW/SSB Gain……………………………………………...………………………12dB nominal... - Page 4 2. INTRODUCTION The 6m Discovery is a high quality linear amplifier which is designed around a GS 31 medium mu triode in grounded grid configuration. The amplifier uses a Pi – L network in the output circuit and a tuned input circuit. The amplifier is forced air cooled to give you the ability to operate at full output power for as long as you wish.
-
Page 5: Installation
3. INSTALLATION SETTING UP a) Unpack the amplifier and check that it is undamaged. The carton should also contain a power cable, operating manual, phono plug (for relay switching lead) and spare fuse. Please retain the packing and box should it be necessary to ship it or move it to another location. -
Page 6: Front Panel Controls
4. OPERATING CONTROLS FRONT PANEL CONTROLS ON/OFF SWITCH…………………………………………..Mains power on and off STBY/TX……………………………………….…………Amplifier standby / operate PLATE METER……………………..0 – 1.5A, monitors the plate current of the valve GRID METER…………………………...0 – 400mA, monitors the grid current which should not rise above 300mA GRID / RF OUT…………………..switches the grid meter to monitor relative RF O/P LOAD CONTROL…………………………………..Adjusts the loading of the output TUNE CONTROL…………………………………….Adjusts the tuning of the output... -
Page 7: Rear Panel
TX………………………N – type connector, coaxial INPUT to amplifier from driver ANT…………………….N – type connector, coaxial OUTPUT to antenna through a suitable power meter PTT…………………………………….……Phono connector for relay switching lead WiMo Antennen und Elektronik GmbH Am Gäxwald 14, D-76863 Herxheim Tel. (07276) 96680 FAX 6978 http://www.wimo.com e-mail: info@wimo.com... -
Page 8: Operation
5. OPERATION SET-UP Connect all the cables as previously described in the manual, then double-check. When you are satisfied that everything is correct and the STBY/TX switch is on STBY, switch the amplifier on. There is a slight delay while the soft-start operates, then the POWER and WAIT lights should be on. - Page 9 STBY/TX switch to STBY then back to TX. The LED should now have gone out and the amplifier is able to be keyed once more. Tune the amplifier correctly to achieve maximum output with minimum grid current. WiMo Antennen und Elektronik GmbH Am Gäxwald 14, D-76863 Herxheim Tel. (07276) 96680 FAX 6978 http://www.wimo.com...
-
Page 10: Operating Precautions
2 of this manual. Excessive drive giving output in excess of these specifications will shorten valve life and could affect the reliability of other components. WiMo Antennen und Elektronik GmbH Am Gäxwald 14, D-76863 Herxheim Tel. (07276) 96680 FAX 6978 http://www.wimo.com... -
Page 11: Warranty
This warranty is not transferable from the original owner on sale of the unit to another. WiMo Antennen und Elektronik GmbH Am Gäxwald 14, D-76863 Herxheim Tel. (07276) 96680 FAX 6978 http://www.wimo.com...
