Panacom Q916 Installation And Operation Manual

Audio intercom system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation and Operation Manual
This manual is suitable for the following components:
Part Number
Description
PANQ916KS
Kit (Silver door, silver master room, power supply)
PANQ916KG
Kit (Grey door, silver master room, power supply)
PANQ916K/SP
Stainless steel door plate Kit (Door, silver master room, power supply)
PANQ916K/GP
Gold door plate Kit (Door, silver master room, power supply)
PANQ916M
Silver master room station
PANQ916S
Silver room station
PANQ916DG
Grey door station
PANQ916DS
Silver door station
PANQ916MUS
Music module
Model Q916
1

Advertisement

Table of Contents
loading

Related Manuals for Panacom Q916

Summary of Contents for Panacom Q916

  • Page 1 Installation and Operation Manual Model Q916 This manual is suitable for the following components: Part Number Description PANQ916KS Kit (Silver door, silver master room, power supply) PANQ916KG Kit (Grey door, silver master room, power supply) PANQ916K/SP Stainless steel door plate Kit (Door, silver master room, power supply)

  • Page 2: Technical Specifications

    It has the following features:  Easy to operate. All the functions of the Panacom Q916 can be controlled from any room station using only three buttons.  Paging feature allows communication to all room stations.

  • Page 3: Installation

    Installation  Before installing the system, refer to “ID settings” on page 7.
  • Page 4  Use 6 core cable (14/020) or CAT5 cable between all stations.  Figure 8 cable is required between the Door Station and electric door latch.  12V DC auxiliary output provided on the master station when door bell is pressed. Figure 8 cable is required from Master station to auxiliary device.

  • Page 5: Music Module

    Music module The Q916 System allows background music to be played from the master and room stations. This is possible by using the music module (PANQ916MUS). The music module allow any external music device such as MP3 player, iPod or radio to be plugged into the 2.1mm jack.
  • Page 6 If you purchase a flush mount plate door kit (PANQ916K/SP or GP), the door stations can only be flush mounted. A wall box is available if required (PANWBOX). Cut out size: 90mm W x 160mm H x 50mm D. Surface Mounting Instruction Fix the surface mount base to the wall.

  • Page 7: Room Stations

    ID Setting Behind each station is a rotary ID dial. Each station must be addressed to a specific and unique ID setting. Room Stations. Each Room Station is required to be configured to its unique station ID address. Each room station must have a different ID to each other. Gently turn the dial with a fine blade screw driver with the arrow pointing to the ID number as tabled below.

  • Page 8: Operating The Door Station

    Operating Instructions Operating the Door Station. Press the CALL button on the door station will ring a chime to all room stations. The door station can be answered by pressing and holding the TALK button on any room station to talk and releasing the talk button to listen. Pressing the CANCEL button will end conversation.
  • Page 9 Cancel button of the monitored room station. Only one Room Station can be monitored at any one time. LEDs The Panacom Q916 is equipped with red and green LEDs to indicate system mode and status. The table below describes the functions of each LED indicator.

  • Page 10: General Care And Cleaning

    General Care & Cleaning Important Precautions  DO NOT press the Door Release button continuously for long period of time as this could cause an overload.  DO NOT drop, shake, or subject units to shock.  DO NOT clean the units with benzene, thinners or any solvents. Cleaning To clean simply wipe with a soft cloth, dampened slightly in a mild soap solution.
  • Page 11 PSA Products also supply these products; Video Intercoms Audio Intercoms Wireless Intercoms Security Alarm Systems CCTV cameras and DVR Systems Access Control Systems Apartment Intercom Systems Access Control Smoke Alarms and Accessories Fire Panels and Detectors Fire Extinguisher and Blankets...
  • Page 12 Another Quality Product by: PSA Products Pty Ltd 17 Millicent Street, Burwood Victoria 3125 Australia Tel: 1300 772 776 (PSAPRODUCTS) Fax: (03) 9888 9993 e-mail: enquiry@psaproducts.com.au web-site: www.psaproducts.com.au...
