AC/DC Couple
The modulation input can be AC or DC coupled. Remember the output voltage
is the superimposed of OFFSET voltage and MODULATION voltage.
Power Amplifier
The TS200 can be used as a current or power amplifier. The modulation input
serves as amplifier input. The TS200 offers 0dB and 20dB gain options.
Remote Control
The MODULATION input can serve as a remote voltage setting. To do so,
adjust the OFFSET knob until the voltage reaches 0.0V and set to DC-couple,
then apply a DC voltage to MODULATION input. The DC input voltage can
come from a programmable power supply or DAQ (data acquisition). Whatever
the voltage on the MODULATION input is amplified and output to the
OUTPUT terminals. Note the TS200 offers two gain options: 0dB and 20dB.
8
