Summary of Contents for APB-DynaSonics ProDesk-4
- Page 1 ProDesk-4 OWNER’S MANUAL APB-DynaSonics, Inc. 20 West End Road Totowa, New Jersey, 07512, U.S.A. Tel: 973-785-1101 Fax: 973-785-1105 Web: www.apb-dynasonics.com...
- Page 2 APB-DynaSonics...
- Page 3 ProDesk-4 OWNER’S MANUAL IMPORTANT SAFTEY INSTRUCTIONS 1) Read These Instructions 2) Keep These Instructions 3) Heed All Warnings 4) Follow All Instructions 5) Do Not Use this Apparatus near water 6) WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
-
Page 4: Table Of Contents
TABLE OF CONTENTS PSU INSTALLATION........................................ 6 OPERATION WITH DUAL POWER SUPPLIES .............................. 7 POWER SUPPLY PS450 - SPECIFICATION..............................8 YOUR PRODESK-4 CONSOLE..................................... 9 BLOCK DIAGRAM ( L ) ....................................10 BLOCK DIAGRAM ( R ) ....................................11 MONO INPUT ........................................12 MONO INPUT - EQUALIZATION................................13 MONO INPUT - AUXILIARY SENDS.................................14... - Page 5 ProDesk-4 OWNER’S MANUAL POWER SUPPLY Model PS450 THE SYMBOLS BELOW APPEAR IN THE TEXT THAT FOLLOWS AND HAVE THE FOLLOWING MEANINGS: TO AVOID ELECTRIC SHOCK FOLLOW THE INSTRUCTION NEXT TO THIS SYMBOL. TO AVOID AN UNSAFE CONDITION FOLLOW THE INSTRUCTION NEXT TO THIS SYMBOL...
-
Page 6: Psu Installation
APB-DynaSonics PSU INSTALLATION This unit is for installation in APB DynaSonics sound mixing consoles and is intended for this purpose only. Complete consoles are shipped with power supply(s) installed. When adding a second power supply to an existing console or when replacing an existing power supply follow these instructions: Switch off AC power. -
Page 7: Operation With Dual Power Supplies
There are no user serviceable parts inside the PS unit enclosure. Units contain hazardous AC and DC voltages. Return defective units to APB-DynaSonics or authorized agent for servicing. The unit will not operate outside a console. Automatic circuits prevent operation when disconnected from the... -
Page 8: Power Supply Ps450 - Specification
APB-DynaSonics POWER SUPPLY PS450 - SPECIFICATION High efficiency switch-mode power supply Zinc-plated steel enclosure with ventilation by internal fans PS units plug into the APB ProDesk sound console chassis. IEC 60320 C13 AC inlet connection Universal AC input voltage and frequency 100-240V 50/60Hz... -
Page 9: Your Prodesk-4 Console
In addition to the hard copy of this manual, it will appear within our web site www.apb-dynasonics.com with the latest updates as well as new supplemental information. We suggest that you occasionally check our web site for additional information about your console as well as for new product releases and news from APB-DynaSonics. -
Page 10: Block Diagram ( L )
15A IEC 15A IEC The ProDesk-4 normally ships with 1 supply, an optional power supply can be fitted in all chassis sizes except for the 16-channel. With 2 PSUs fitted, the total Console load is shared equally between the 2 supplies. -
Page 11: Block Diagram ( R )
ProDesk-4 Block Diagram Aux Outputs Master Metering Bus In 1 of 6 shown Main Metering +4dBu Main Output Levels The meters are capable of displaying 3 different types of ballistic response: Aux Mix Bus ∑ Average (VU-style), Peak (PPM-style), or a combination of both. -
Page 12: Mono Input
APB-DynaSonics MONO INPUT Preamp Controls +48-Volt Phantom Power Switch with LED When depressed, provides +48-Volt phantom power to the XLR connector. Phantom power is required for operation of many condenser microphones. See your microphone instructions to see if phantom power is required or is to be defeated (some - though few - microphones require phantom power NOT be activated or they may be damaged). -
Page 13: Mono Input - Equalization
ProDesk-4 OWNER’S MANUAL MONO INPUT - EQUALIZATION High-Pass Filter Control Adjust the high-pass filter corner frequency between 20Hz and 400Hz at a roll off rate of 12dB per octave. This control is used to remove unwanted signal content below the set frequency such as stage rumble. -
Page 14: Mono Input - Auxiliary Sends
APB-DynaSonics MONO INPUT - AUXILIARY SENDS Aux 1-6 Pre-Fader / Pre-EQ Switch This switch defines the “Pre” signal source for all Auxes: Up is Pre-Fader (and Post-EQ), Down is Pre-EQ. Internally, the default Pre-EQ source is set to Post-insert. A qualified technician can change this to Pre-insert (Post HPF) on a channel-by-channel basis. -
Page 15: Mono Input - Mute, Solo And Level Control
ProDesk-4 OWNER’S MANUAL MONO INPUT - MUTE, SOLO and LEVEL CONTROL Mute Switch (Local) - Internally Illuminated Activation of this latching switch will mute the primary outputs as well as all pre and post fader auxiliary sends of the channel. When depressed, it will illuminate RED, indicating the status of this local mute only;... -
Page 16: Mono Input - Bus Assignment And Panning
APB-DynaSonics MONO INPUT - BUS ASSIGNMENT AND PANNING Pan Control This control blends the post-fader signal between any of the assigned bus pairs: L-R, Group1-2 and Group 3-4. When at the center, detented position, both sides are fed equal amounts of signal (each down by 3dB). -
Page 17: Mono Input - Rear Panel Connectors
ProDesk-4 OWNER’S MANUAL MONO INPUT - REAR PANEL CONNECTORS 1/4” TRS Direct Output Connector The connector provides an impedance-balanced line level output of the input channel’s signal. The default Direct Out signal is AFTER the microphone preamplifier but before all other processing. -
Page 18: Stereo Line Input
APB-DynaSonics STEREO LINE INPUT TRS/ALT (RCA OR USB) Line Input Switch Selects the stereo input source between the rear-panel 1⁄4” TRS jacks (switch UP) or the RCA connectors (switch DOWN) on Inputs A-B-C. On Stereo Input D, the USB Audio In signal is selected when this switch is depressed (there are no RCA jacks for Input D). -
Page 19: Stereo Line Input - Stereo Equalization
ProDesk-4 OWNER’S MANUAL STEREO LINE INPUT - STEREO EQUALIZATION High Frequency Level Control (Shelving) Adjusts the high frequency shelving cut/boost between +/-15dB. Boost or cut of the high frequency level control is usually used for minor tonal adjustments. Use of this EQ control will affect both the left and right signal paths. -
Page 20: Stereo Line Input - Aux Sends
APB-DynaSonics STEREO LINE INPUT - AUX SENDS Stereo Channel Aux Sends The signals feeding the Aux sends are normally summed-mono mixes of the left & right side signals within the module. For Auxes 1& 2, when switched to Stereo, the left-side channel signal feeds the Aux 1 control; the right-side channel signal feeds the Aux 2 control. -
Page 21: Stereo Line Input - Mute, Solo And Level Control
ProDesk-4 OWNER’S MANUAL STEREO LINE INPUT - MUTE, SOLO and LEVEL CONTROL Mute Switch (Local) - Internally Illuminated Activation of this latching switch will mute the primary outputs as well as all pre and post-fader auxiliary sends of the channel. When depressed, it will illuminate RED, indicating the status of this local mute only;... -
Page 22: Stereo Line Input - Bus Assignment And Balance
APB-DynaSonics STEREO LINE INPUT - BUS ASSIGNMENT AND BALANCE Balance Control This control feeds the post-fader channel signals to any of the assigned bus-pairs: L-R, Group1-2 and Group 3-4. This Balance control has no effect on the Mono or Center mix buses. -
Page 23: Stereo Line Input - Rear Panel Connectors
ProDesk-4 OWNER’S MANUAL STEREO LINE INPUT - REAR PANEL CONNECTORS 1/4” TRS Left and Right Balanced Input Connectors Provides for balanced line level inputs to the channel’s left and right inputs. Design level is +4dBu Input impedance is 10KΩ balanced The input signal may be balanced or unbalanced. -
Page 24: Master Section
Aux Master Controls ProDesk-4 is equipped with 6 Aux buses. The master controls for the first 4 Auxes are located above the 4 Group master faders; the remaining 2 Aux master controls are located above the Main output faders. They all share similar controls, but Aux-6 also has the additional feature of Fader-Flip with the Mono output. -
Page 25: Group Output (1 Thru 4)
Group Master Controls ProDesk-4 is equipped with 4 Group buses. These groups can be used as audio subgroups for combining and processing a collection of input channels. These processed channels can then be added to any of the main mix buses or fed directly to the Matrix section, pre or post fader. -
Page 26: Matrix Output (1 Thru 4)
MATRIX OUTPUT (1 thru 4) Matrix Master Controls ProDesk-4 is equipped with 4 Matrix buses. Each Matrix can be a mixture of any of the 4 Groups or Main output buses, along with an individual external input. Since each Matrix can be individually configured for use, the outputs can be used as the main system feeds for the PA, or as supplimental feeds for under-balcony speakers or guest rooms. -
Page 27: Main Output (L-R-C-M)
Main-Bus Master Controls ProDesk-4 is equipped with 4 Main mix buses: Left, Right, Center and Mono. These 4 buses are typically used as the main outputs of the console. These buses also can feed the Matrix section as well as the Monitor and Record Out sections for generating additional outputs from the Console. -
Page 28: Rear Panel Connections (For All 18 Major Buses)
APB-DynaSonics REAR PANEL CONNECTIONS (for all 18 major buses) Bus-Input (Main, Group & Aux) or External Input (Matrix): 1/4” Balanced TRS: Tip= Input+, Ring= Input–, Sleeve= Chassis A 1/4” TRS (10kΩ) balanced line input is provided for each bus. For the Main, Group and Aux buses, this balanced input directly feeds the corresponding mix bus. -
Page 29: Stereo Program In
ProDesk-4 OWNER’S MANUAL STEREO PROGRAM IN Stereo Program In This section serves as a general-purpose, stereo input into the console. Any of the 3 sources can be selected as the input signal; all selected sources are summed together. The resulting signal can be EQ’d and assigned to any of the Main buses, the Matrix, and Aux 1-2 pair. -
Page 30: Stereo Record Out (Alternate Out)
APB-DynaSonics STEREO RECORD OUT (Alternate Out) Stereo Record Out This section serves as a general-purpose, stereo output from the console. Any of 5 sources can be selected as the input signal, all selected sources are summed together and can be globally set to be pre or post their individual output controls. A Sum- Mono button provides mono compatibility. -
Page 31: Rear Panel Connections For Stereo Program In And Stereo Record Out
USB Audio In & Out The ProDesk-4 will appear as a USB-peripheral to your computer; there is on onboard circuitry (CODEC) that allows 2-way stereo communication via USB. Simultaneous record and playback of audio is possible using commonly available software. -
Page 32: Monitor / Headphone Control
MONITOR / HEADPHONE CONTROL ProDesk-4 is equipped with a comprehensive system to allow the operator to accurately monitor signals within the console. Multiple sources can be selected and combined for listening, and the Solo system permits selected inputs and ouputs to be monitored and metered. -
Page 33: Solo System- Monitor And Control
ProDesk-4 OWNER’S MANUAL SOLO SYSTEM- MONITOR and CONTROL When the Solo system is active (a PFL or AFL button is pressed), the Solo audio interrupts the default audio to the Headphone and Monitor output (unless a Solo Off button is depressed). You can listen to the Solo’d signal through the monitor system and also view the signal level on the Solo meters. -
Page 34: Talkback System
APB-DynaSonics TALKBACK SYSTEM The Talkback system allows the operator to selectively assign external audio or internal test signals to the console buses. A front-mounted XLR jack (located under the armrest) is provided for connection to a microphone or other low-level audio feed; internal sources include a “pinkish” noise generator and a 1kHz oscillator. -
Page 35: Solo-Linking And Mute-All
ProDesk-4 OWNER’S MANUAL SOLO-LINKING and Mute-All Solo Linking The ProDesk can connect to other consoles using the Bus Input and Output jacks; this allows the user to combine the audio from multiple consoles to create a larger overall mixer. APB consoles are equiped with Solo Linking connectors to also tie the Solo systems of the combined consoles together. -
Page 36: Mute-All Configuration
APB-DynaSonics Mute-All Configuration The different Modes for the Mute-All function are set by adjusting the position of the 4 removable jumpers (shunts) located behind the Phoenix connector on the circuit board. Two of the jumpers (Jumpers 1&2) determine if the Mute-All connector is internally DC powered or totally opto-isolated and activated by an external voltage. -
Page 37: Console Dimensions
ProDesk-4 OWNER’S MANUAL Console Dimensions Chassis Size > 16-Chan 24-Chan 32-Chan 40-Chan 48-Chan Module Order Inp•Inp•Mstr Inp•Inp•Inp•Mstr Inp•Inp•Mstr•Inp•Inp Inp•Inp•Inp•Mstr•Inp•Inp Inp•Inp•Inp•Mstr•Inp•Inp•Inp Length (L2) Inch 30.72in 38.82in 46.92in 55.02in 63.12in 780.3mm 986.1mm 1191.8mm 1397.5mm 1603.3mm Weight-lbs (kg) 90 (41) 100 (46) 115 (53) -
Page 38: Technical Specifications
TECHNICAL SPECIFICATIONS All measurements ref to 20Hz to 20KHz BW unless otherwise noted Frequency Response (any input to any output) +0 / -0.5dB 10Hz to 50kHz (ref to 1kHz) THD + Noise (Mic Input to Main Output) < 0.01% @ +15dBu output Phase Response (Mic Input to Main Output) +10/-15 degrees 20Hz to 20kHz (ref to 1kHz) Noise... - Page 39 ProDesk-4 OWNER’S MANUAL...
- Page 40 APB-DynaSonics • ProDesk-4 Owners Manual • Rev- 0.91 • July-2009...
