Washing Machine
Use & Care Guide
Dear ASKO customer,
Thank you for choosing this quality product from
Scandinavia, made in Vara, Sweden. We hope that this
product will give you many years of pleasure from using it.
To get the most out of your new machine, we recommend
that you read the Use & Care Guide before using the
machine.
Sole agency in Taiwan: Victory Appliances Co., Ltd.
Customer service: Taipei: (02) 89131001 Taichung: (04) 26916953
Kaohsiung: (04) 26916953
Address: 207-2, 8F., Beihsin Rd. sec. 3, Hsintien, Taipei Hsien, Taiwan
Website: www.asko.com.tw
ASKO W6122
Advertisement
Table of Contents
Related Manuals for Asko W6122
Summary of Contents for Asko W6122
-
Page 1: Washing Machine
Washing Machine Use & Care Guide Dear ASKO customer, Thank you for choosing this quality product from Scandinavia, made in Vara, Sweden. We hope that this product will give you many years of pleasure from using it. To get the most out of your new machine, we recommend that you read the Use &... -
Page 2: Table Of Contents
Contents Contents Care and cleaning Before using your machine Checking the filter and drainage pump 13 for the first time Cleaning the detergent compartment 13 Transport protection Cleaning the outside of the machine 13 Packing material Cleaning the inside of the machine to Washer door avoid unpleasant smells Checking water hardness... -
Page 3: Before Using Your Machine For The First Time
Before using your machine for the first time Checking water hardness Transport protection The quantity of detergent required depends Has the transport protection been on water hardness, among other things. removed? If not, see the “Transport Phone your local Water Board to check the protection”... -
Page 4: Safety Instructions
Safety instructions General Transport/ Winter storage • Read and keep this “operating If the machine is to be transported or instructions”! stored in unheated premises where the • Installation of water and electricity, if temperature can fall below freezing, do as required, should be carried out by a follows: qualified professional. -
Page 5: Child Safety
Child safety Keep an eye on children! Always close the door and start the programme immediately once you have added detergent. Do not allow small children to use or play with the washing machine. Store detergent and fabric softener out of the reach of children! Automatic door opening The machine comes with an automatic... -
Page 6: Parts Of The Washing Machine
Parts of the washing machine Detergent compartment Main power switch Programme panel Type plate Hatch - drainage pump Drainage pump (behind hatch) Washer door Outer door (not all models) Detergent compartment Detergent compartment - pre-wash Detergent compartment - main wash Fabric softener compartment Note! In the plastic bag that contains, amongst... -
Page 7: Front Panel
Front panel Main power switch Start/Stop Options button Door opening Programme selector Options button Button for selecting Super Rinse SuperRinse... -
Page 8: Advice And Tips Before Washing
Advice and tips before washing Here are some tips that may help you Laundry labels before washing. Look at the item’s laundry label. The table below indicates suitable wash programmes Sorting your laundry for various materials and wash loads. Sort items according to: •... -
Page 9: Wool And Silk
Wool and silk Dyeing fabrics These fabrics are sometimes labelled as If you want to dye fabrics in the machine, machine washable and sometimes as select the Heavy white programme with the hand wash. The machine’s Wool/Hand Super Rinse option On. programme is at least as gentle as washing by hand. -
Page 10: Washing
Washing Sort your laundry Liquid detergent Should you prefer to use a liquid detergent, See “Advice and Tips section before we have provided a partition piece with washing.” the detergent drawer specifically for use with liquid detergents. Insert the partition Note! in the slot at the back of the main wash Empty pockets. -
Page 11: Select Programme
Select programme You can select a programme by turning the programme selector. A red field lights up beside the selected programme. Start by pressing the Start/Stop button, or selecting an option. Quick Synthetics Guidelines as to what specific programmes can be used for. Wool/Hand Colour Heavy, 95 °C, 1200 rpm spin cycle. -
Page 12: Select Options
Close the door and press the if you are not satisfied with the results. Start/Stop button Fabric softener SuperRinse To add or remove washing after the Pour the fabric softener programme starts into the compartment If you want to add or remove items after the with the symbol. -
Page 13: Care And Cleaning
Care and cleaning Checking the filter and drainage Cleaning the detergent pump compartment The washing machine has a filter, where Pull the detergent compartment out as far coins, hairpins and the like can get caught. as it will go. To clean the filter and drainage pump: 1. -
Page 14: Rinse Holes Under The Agitator
Rinse holes under the agitator If you think that objects such as nails, paper clips, needles or the like may have fallen into the wash drum, you should check under the agitator. Such objects can rust and cause spots on clothing. Nails and other sharp objects can cause holes in fabrics. -
Page 15: Troubleshooting
Troubleshooting The washer door will not open • Insert the handle back into its slot and screw it tight. Close the hatch to the 1. Check that the main power switch is on. drainage pump. 2. Is there power? Check your home’s If the washer door still will not open in the fuses (circuit breakers). - Page 16 Water intake error If L4 is flashing, there is a problem with the water supply. Check: - that the tap on the water pipe is open. - that the filter in the machine’s water intake is not blocked. 1. Shut off the water tap. 2.
-
Page 17: Technical Information
Technical information Technical data Height: 850 mm Width: 595 mm Depth: 585 mm Weight: 73/78 (with outer door) kg Cylinder volume: 50 l Max. washing capacity: 6.0 kg Spin speed: 800/1200 rpm Rated power: See type plate. Element power: See type plate. Water pressure: 0.1 - 1 MPa 1 - 10 kp/cm... -
Page 18: Transport Protection
Transport protection Before the machine is used, the three 3. Finally, the rubber spacers should be transport protection devices should be turned over and replaced in the transport removed as shown below. protection device holes. Each transport protection device consists of a screw, a washer, and a rubber spacer. -
Page 19: Installation
Installation Positioning the washing machine There should be a stopcock on the water pipe. The washing machine can be installed as If the pipes are newly installed, it may be a built-in or freestanding unit. Position the wise to flush them through so that any dirt is machine so that the electrical plug is easily washed away. -
Page 20: Electrical Installation
Electrical connections must be made via a plug connected to an earthed wall socket. If you need to extend or connect the power source system, please contact Asko’s agency or qualified technician for assistance. Connection on delivery The machine is supplied as single-phase, 230V with plug, heat output 2000 W (see type plate) and has a 10A fuse. -
Page 21: Service
Service Before contacting the service division, Make sure you know the model designa- tion, type designation and serial number. The model designation can be found on the detergent compartment. Type designation and serial number can be found on the type plate above the washer door. -
Page 22: Own Notes
Own notes... -
Page 23: Search Words
Search words Acrylic Main power switch 6, 7 Allergies Artificial fibres Options Options button Bleaching Overflow guard function Care Packaging Child safety Panel 6, 7 Child safety catch Polyester Cleaning Powder detergent Cotton Programmes 8, 12 Delicates Quick guide Depth Detergent 4, 10, 13 Detergent compartment... -
Page 24: Quick Guide
Quick guide Washing Select programme • Empty pockets and do up zips. • Select a programme by turning the • Read the item’s laundry label. programme selector. • Sort your laundry. Quick Synthetics Wool/Hand Colour NB! Place underwired Rinse White bras in a laundry net.
