Page 1: User Manual
Stollmann TA+P2I E + V GmbH User manual TA+P2I Adapting ISDN Phones to POTS FXS User Manual Release r04 November 2007 Ref: TA+P2I_manual_r04_en_OEMKD.doc Release r04 Page 1 of 16... - Page 2 Exclusion of Liability The present manual by Stollmann Entwicklungs- und Vertriebs-GmbH (hereinafter referred to as Stollmann) reflects the present state of the art of the products de- scribed therein. We have endeavoured to give a description that is as complete and clear as possible in order to make work with our products as easy as possible for you.
-
Page 3: Table Of Contents
2.2 Procedure of Installation for ISDN phones ............. 5 2.3 Procedure of Installation for ISDN PABX ............7 2.4 Displays ......................9 2.5 Interfaces......................9 Usage of the TA+P2I ..................10 3.1 Incoming call....................10 3.2 Outgoing call....................11 3.3 Call waiting ....................11 3.4 Call Hold / Enquiry.................. -
Page 4: Introduction
Software Version V1.700 or later 1.1 Product description Using the TA+P2I you can connect ISDN phones or an ISDN PABX with two ana- logue interfaces (POTS FXS). The analogue lines of the TA+P2I react like standard analogue phones und have to be connected with the FXO ports of the switching system or adapter. -
Page 5: Procedure Of Installation For Isdn Phones
The installation of your TA+P2I is done in a few simple steps: • Connect the power supply to the TA+P2I and mains: the green LED “READY” at the front panel will be lit. Attention: Please use only the delivered power supply! •... - Page 6 Stollmann TA+P2I E + V GmbH User manual o If one ISDN phone shall react only to the phone numbers of one of the analogue lines of the cable modem, change the former MSN settings and use the digit “1” as MSN for that phone, which shall react on incoming call from line 1.
-
Page 7: Procedure Of Installation For Isdn Pabx
ISDN phone To use the TA+P2I please take the following steps: [1] Connect the power supply to the TA+P2I and mains: the green LED “READY” at the front panel will be lit permanently. Attention: Please use only the delivered power supply! [2] Connect „LINE 1“... - Page 8 MSN inside the ISDN PABX: Set up the MSN of your ISDN PABX as they are signaled by the TA+P2I: per de- fault the MSN “1” for the analogue line 1 and the MSN “2” for the analogue line More setups you will find in the next chapter.
-
Page 9: Displays
Stollmann TA+P2I E + V GmbH User manual 2.4 Displays READY The TA+P2I is powered and ready to use ERROR Hardware-Error, the TA+P2I cannot be used LINE1 The analogue line 1 is connected to a working analogue inter- face LINE2... -
Page 10: Usage Of The Ta+P2I
If a phone number according to the call number of the analogue lines shall be used, you have to set up this correct MSN both in the TA+P2I and the ISDN phones. To change the setting for the MSN for analogue line 1 please do the following: •... -
Page 11: Outgoing Call
(LINE 1 or LINE 2), that will be used for the outgoing call. If no MSN is defined either in the TA+P2I or the ISDN phone the first analogue line will be used always. To make an outgoing call with calling line restriction please use the menu user inter- face of the ISDN phone. -
Page 12: Three Party Conference
Stollmann TA+P2I E + V GmbH User manual 3.5 Three party conference You can start a three party conference by the typical sequence as usual for the ISDN phone (menu driven). 3.6 Call forwarding You can activate and deactivate call forwarding by the typical sequence as usual for an analogue line by prefix codes. -
Page 13: Diagnostic
If not, please check the connection be- tween the plug LINE2 and the analogue port. Is the MSN programmed in the ISDN phone also programmed in the TA+P2I? Check the setting of the MSNs in the ISDN phone and the TA+P2I. Please re- fer to the chapter outgoing call. -
Page 14: Configuration
Stollmann TA+P2I E + V GmbH User manual 5 Configuration 5.1 Overview Configuration commands Every configuration command has to be dialed en-bloc from the ISDN phone: enter the configuration dial number, go off hook and go on hook. Set up 1. MSN xxx for Line1: 00000101xxx Set up 2. -
Page 15: Technical Features
Plug 2 x RJ 45 Terminating resistors 2 x 100 Ohm Phantom feeding ISDN-Bus 2,5 Watt Supplementary services TA+P2I MSN, DDI, Call Waiting, Hold, Resume, Three Party Conference, Call Forwarding Supplementary services transparent using All available on analogue line DTMF... - Page 16 Stollmann TA+P2I E + V GmbH User manual © 2007 Stollmann E+V GmbH November 2007 Ref: TA+P2I_manual_r04_en_OEMKD.doc Release r04 Page 16 of 16...
