- Page 1 User’s guide “TSSHC-3NPSBFS-16A” Heating floor non programmable electronic thermostat For further information or to consult this guide on line, please visit our Web site. INS-TSSHC-3NPSBFS-16A-1209...
- Page 2 Protect the heating system with the appro- priate circuit breaker or fuse. You must regularly clean dirt accumulations on or in the thermostat. Do NOT use fluid to clean thermostat air vents. Do NOT use where exposed to water. Suitable for in- sulated walls. INS-TSSHC-3NPSBFS-16A-1209...
- Page 3 1. Description The TSSHC-3NPSBFS-16A non programmable electronic ther- mostat can be used to control ENERJOY radiant ceiling pan- els or heating floors with electrical current − with a resistive load − ranging from 0 A to 16 A at 120/208/240 VAC. It has an easy user interface.
-
Page 4: Installation
Thermostat mounting and connection Cut off power supply on lead wires at the electrical panel in order to avoid any risk of electric shock. 2. Ensure that the air vents of the thermostat are clean and clear of any obstruction. INS-TSSHC-3NPSBFS-16A-1209... - Page 5 (120-208-240 VAC) and an other pair (yellow) must be connected to the heating cable (refer to the drawings displayed on the back of the thermo stat). For connections with aluminum wires, you must use CO/ALR INS-TSSHC-3NPSBFS-16A-1209...
- Page 6 6. Reinstall the front part of the thermostat on the mounting base and tighten the screw at the bottom of the unit. 7. Turn on the power. 8. Set the thermostat to the desired setting (see the follow ing section). INS-TSSHC-3NPSBFS-16A-1209...
-
Page 7: Operation
At any time, the floor temperature (both in Floor and Ambi ent modes) is maintained at less than 82°F (28°C) in order to avoid overheating caused by an excessive heating request, which could damage some materials or be detrimental for health. INS-TSSHC-3NPSBFS-16A-1209... - Page 8 5 seconds. Then, you can release the A/F button. 2. Press down the + button to increase this limit or – button to decrease it. Regardless of the maximum floor set point (Floor mode), the maximum Ambient mode set point will always be 35°C (95°F). INS-TSSHC-3NPSBFS-16A-1209...
- Page 9 Night mode. The timer is set for the duration of the night. The thermostat will automatically return to the Day mode at the end of the night, and the Day mode temperature set point, which is higher, will become effective at this time. INS-TSSHC-3NPSBFS-16A-1209...
- Page 10 Once the timer has completed its cycle and when the thermostat is in the Day mode, you must manually return to the Night mode. If you want to automatically return to the Night mode, the Automatic mode must be selected. INS-TSSHC-3NPSBFS-16A-1209...
-
Page 11: Automatic Mode
It returns to the Day mode when the timer cycle is completed. 2- Day mode: activated for the remaining time of the 24-hour cycle. It returns to the Night mode at the end of the 24-hour cycle. INS-TSSHC-3NPSBFS-16A-1209... - Page 12 When the power is restored after a power failure for example, the Automatic mode is deactivated and its corresponding icon is blinking. The icon will stop to blink as soon as you will press down a button. INS-TSSHC-3NPSBFS-16A-1209...
- Page 13 Floor or Ambient mode temperature, as applicable. Safe mode If the thermostat fails to detect the presence of a floor sensor, it will automatically revert to ambient mode at a setpoint of 70°F. (with a maximum set point temperature of 75°F) INS-TSSHC-3NPSBFS-16A-1209...
- Page 14 SSHC, inc. with a temperature sensor already installed in the floor (other than the sensor supplied with this thermostat), you must con tact the SSHC, inc. customer service to validate the com patibility between the sensor and the thermostat. You must know the serial number and name of the installed sensor.
- Page 15 Failed test: The red indicator does not light up and the entire display blinks during 5 seconds. In this case, dis- connect the heating system at the electrical panel. INS-TSSHC-3NPSBFS-16A-1209...
- Page 16 N.B. If the thermostat isn’t unlocked within 5 minutes after the restoration of the power supply, the Lock icon will stop to blink and it will be impossible to unlock the thermostat unless cutting off the power supply again. INS-TSSHC-3NPSBFS-16A-1209...
- Page 17 However, its icon blinks for 5 minutes and you can deactivate this mode by simultaneously pressing down the + and – buttons for 10 seconds. The Lock option stays activated if you don’t follow this process and the icon stops blinking. INS-TSSHC-3NPSBFS-16A-1209...
-
Page 18: Troubleshooting
*** E3: Faulty floor sensor (open circuit) – written in the floor section N.B. If you do not solve the problem after checking these points, cut off the power supply at the main electrical panel and contact customer service (consult our Web site to obtain the phone numbers). INS-TSSHC-3NPSBFS-16A-1209... -
Page 19: Technical Specifications
Ambient Mode : 37 °F to 95°F (3 °C to 35°C) Floor Mode : 37 °F to 99°F (3 °C to 37°C) Temperature set point increments: 1 °F (1 °C) Storage: -104 °F to 122 °F (-40 °C to 50 °C) Certification: INS-TSSHC-3NPSBFS-16A-1209... -
Page 20: Limited Warranty
The warranty is limited to the factory repair or the replacement of the unit, and does not cover the cost of dis- connection, transport, and installation. Customer service SSHC, Inc. P.O. Box 769 Old Saybrook, CT 06475 (860) 399-5434 www.sshcinc.com...
