- Page 1 User’s guide “TSSHC-3DNPSB-16A-115F” Electronic thermostat For further information or to consult this guide on line, please visit our Web site. www.sshcinc.com INS-TSSHC-3DNPSB-16A-115F-1210...
- Page 2 You must regularly clean dirt accumulations on the thermostat. Do NOT use fluid to clean thermostat air vent. Do not install thermostat in a wet place. However, installing it in isolated walls is allowed. INS-TSSHC-3DNPSB-16A-115F-1210...
- Page 3 1. Description The TSSHC-3DNPSB-16A-115F non programmable electronic thermostat can be used to control electric heating units such as ENERJOY radiant ceiling panels, electric baseboards, convectors, or aeroconvectors. It keeps the temperature of a room at the requested set point with a high degree of accuracy.
-
Page 4: Installation
• close to a window, on an external wall, or close to a door leading outside; • exposed directly to the light or heat of the Sun, a lamp, a fireplace or any other heat source; • close or in front of an air outlet; • close to concealed ducts or a chimney; and • in a location with poor air flow (e.g. behind a door), or with frequent air drafts conditions (e.g. head of stairs). INS-TSSHC-3DNPSB-16A-115F-1210... - Page 5 Cut off power supply on lead wires at the electrical panel in order to avoid any risk of electric shock. 2. Ensure that the air vents of the thermostat are clean and clear of any obstruction. 3. Using a screwdriver, loosen the screw retaining the mounting base and front part of the thermostat. Remove the front part of the thermostat from the mounting base by tilting it upward. 4. Align and secure the mounting base to the connection box using the two screws supplied. Installation work and electrical wiring must be done by qualified person(s) in accordance with all applica- ble State/Country codes and standards. INS-TSSHC-3DNPSB-16A-115F-1210...
- Page 6 Four-wire installation 6. Reinstall the front part of the thermostat on the mounting base and tighten the screw at the bottom of the unit. 7. Turn on the power. 8. Set the thermostat to the desired setting (see the following section). Installation work and electrical wiring must be done by qualified person(s) in accordance with all applica- ble State/Country codes and standards. INS-TSSHC-3DNPSB-16A-115F-1210...
-
Page 7: Operation
Day mode. The temperature is displayed in Fahrenheit and is set at 105°F (41°C) by default. Language (English/ French) To switch the display from English to French and conversely, press down the backlit button for 20 seconds. The display is set in English by default. INS-TSSHC-3DNPSB-16A-115F-1210... - Page 8 (-) button to decrease it. Set points can be adjusted by increments of 1°F or 1°C. To quickly scroll through the set point values, press and hold down the button. The minimum set point is 37°F (3°C), and the maximum set point is 113°F (45°C). INS-TSSHC-3DNPSB-16A-115F-1210...
- Page 9 Night mode. The timer is set for the duration of the night. The thermostat will automatically return to the Day mode at the end of the night, and the Day mode temperature set point, which is higher, will become effective at this time. INS-TSSHC-3DNPSB-16A-115F-1210...
- Page 10 Once the timer has completed its cycle and when the thermo- stat is in the Day mode, you must manually return to the Night mode. If you want to automatically return to the Night mode, the Automatic mode must be selected. INS-TSSHC-3DNPSB-16A-115F-1210...
-
Page 11: Automatic Mode
1- Night mode : activated for the duration of the Night mode timer cycle. It returns to the Day mode when the timer cycle is completed. 2- Day mode : activated for the remaining time of the 24-hour cycle. It returns to the Night mode at the end of the 24-hour cycle. Adjustment procedure of the Automatic mode: 1. When the thermostat is set in Day mode, switch to the Night mode by pressing down the Day/Night button and releasing it immediately (press it down twice if the backlit screen is off and once if the backlit screen is on). 2. From the Night mode, simultaneously press down the (+) and (-) buttons for more than 3 seconds. Then, the number of programmed hours will be displayed by the three figures at the top of the screen and ‘‘HRS’’ will be displayed instead of the three figures at the bottom of the screen. Then, you can release the buttons. INS-TSSHC-3DNPSB-16A-115F-1210... - Page 12 Day/ Night modes is deactivated, and, if previously activated, the icon that corresponds to this mode will blink. The blinking will stop as soon as you press down a button. INS-TSSHC-3DNPSB-16A-115F-1210...
-
Page 13: Temperature Control
• If the ambient temperature is 2.7°F over the set point, duty cycle is set at 0%. • If the ambient temperature is between: [SetPoint – 2.7°F, SetPoint + 2.7°F}, duty cycle is given by a PI (proportional- integral) control. Red Indicator When the heating comes on, the heating red indicator lights-up. INS-TSSHC-3DNPSB-16A-115F-1210... - Page 14 The Snowflake icon is displayed when the temperature set point is between 37°F (3°C) and 41°F (5°C). A minimum temperature will be maintained to ensure frost control. Please note that when the word ‘OFF’ is displayed, the ‘frost-free’ minimum tempera- ture feature is disabled. INS-TSSHC-3DNPSB-16A-115F-1210...
- Page 15 3. The Lock icon will appear after 13 seconds, indicating that the Lock mode is activated. Release the buttons. Procedures to deactivate the Lock mode 1. To deactivate the Lock mode, start by cutting thermostat power at circuit breaker and wait at least 20 seconds. 2. Turn thermostat power back on and the Lock icon will blink for a maximum of 5 minutes, indicating that it is possible to deactivate the Lock mode. 3. Simultaneously press down the (+) and (-) buttons for more than 13 seconds. (Note that the SET icon will blink after 3 seconds, it is important to hold down the two buttons to avoid switching to the adjustment or Fan mode). After 13 seconds, the Lock icon will disappear, indicating that the Lock mode is deactivated. Release the buttons. INS-TSSHC-3DNPSB-16A-115F-1210...
- Page 16 15 minutes. The deactivation of the Fan mode will cause the thermostat to go back to the heating cycle previously pro- grammed. Once the adjustment finished, we can exit the Fan mode by not pressing on any button for 5 seconds. INS-TSSHC-3DNPSB-16A-115F-1210...
- Page 17 5 minutes, during which it is possible to deactivate the lock mode as it was described in Procedures to deactivate the Lock mode. If this is not done, the Lock mode will stay activated and the icon will stop blinking. INS-TSSHC-3DNPSB-16A-115F-1210...
-
Page 18: Troubleshooting
The display indicates Faulty thermal sensor. Contact customer E1 or E2. service. Possibility of a bad contact. Check Weak luminosity of the thermostat wirings. Refer to the installation display. section. N.B. If you are unable to solve the problem after having verified these points, please communicate with our customer service. INS-TSSHC-3DNPSB-16A-115F-1210... -
Page 19: Technical Specifications
Temperature display resolution : 1 °F (1 °C) Temperature set point range : 37°F to 113°F (3°C to 45°C) Temperature set point increments : 1 °F (1 °C) Storage temperature : -22 °F to 185 °F (-30 °C to 85 °C) INS-TSSHC-3DNPSB-16A-115F-1210... -
Page 20: Limited Warranty
The warranty is limited to the factory repair or the replacement of the unit, and does not cover the cost of disconnection, transport, and installation. Customer service SSHC, Inc. P.O. Box 769 Old Saybrook, CT 06475 (860) 399-5434 www.sshcinc.com...
