Projector
PA622U/PA522U
PA672W/PA572W
PA722X/PA622X
User's Manual
Model No.
NP-PA622U/NP-PA522U/NP-PA672W/NP-PA572W/NP-PA722X/
NP-PA622X

Advertisement

Table of Contents
loading

Related Manuals for NEC PA622U

Summary of Contents for NEC PA622U

  • Page 1 Projector PA622U/PA522U PA672W/PA572W PA722X/PA622X User’s Manual Model No. NP-PA622U/NP-PA522U/NP-PA672W/NP-PA572W/NP-PA722X/ NP-PA622X...
  • Page 2 (3) Great care has been taken in the preparation of this user’s manual; however, should you notice any questionable points, errors or omissions, please contact us. (4) Notwithstanding article (3), NEC will not be responsible for any claims on loss of profit or other matters deemed to result from using the Projector.

  • Page 3: Important Information

    Important Information Safety Cautions Precautions Please read this manual carefully before using your NEC projector and keep the manual handy for future reference. CAUTION To turn off main power, be sure to remove the plug from power outlet. The power outlet socket should be installed as near to the equipment as possible, and should be easily accessible.

  • Page 4: Important Safeguards

    The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by NEC Display Solutions of America, Inc. in this manual. Failure to comply with this government regu- lation could void your right to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 5 Important Information WARNING • Do not cover the lens with the lens cap or equivalent while the projector is on. Doing so can lead to melting of the cap due to the heat emitted from the light output. • Do not place any objects, which are easily affected by heat, in front of the projector lens. Doing so could lead to the object melting from the heat that is emitted from the light output.

  • Page 6: Remote Control Precautions

    Important Information • Handle the power cord carefully. A damaged or frayed power cord can cause electric shock or fire. - Do not use any power cord other than the one supplied with the projector. - Do not bend or tug the power cord excessively. - Do not place the power cord under the projector, or any heavy object.

  • Page 7: Lamp Replacement

    Important Information Note for US Residents The lamp in this product contains mercury. Please dispose according to Local, State or Federal Laws. Lamp Replacement • Use the specified lamp for safety and performance. • To replace the lamp, follow all instructions provided on page 142. •...

  • Page 8: Power Management Function

    Important Information Health precautions to users viewing 3D images Before viewing, be sure to read health care precautions that may be found in the user’s manual included with your 3D eyeglasses or your 3D compatible content such as Blu-ray Discs, video games, computer’s video files and the like.
  • Page 9 Important Information Clearance for Installing the Projector Allow ample clearance between the projector and its surroundings as shown below. The high temperature exhaust coming out of the device may be sucked into the device again. Avoid installing the projector in a place where air movement from the HVAC is directed at the projector. Heated air from the HVAC can be taken in by the projector's intake vent.

  • Page 10: Table Of Contents

    Table of Contents Important Information .................... i 1. Introduction ......................1 ❶ What’s in the Box? ......................1 ❷ Introduction to the Projector ...................2 Congratulations on Your Purchase of the Projector ..........2 Installation .........................2 Videos ........................2 Network ........................3 Energy-saving ......................3 Maintenance ......................3 About this user’s manual ...................4 ❸...
  • Page 11 Table of Contents Checking Energy-Saving Effect [CARBON METER] ..........30 ❺ Using the Optional Remote Mouse Receiver (NP01MR) ..........31 ❻ Correcting Horizontal and Vertical Keystone Distortion [CORNERSTONE] ....33 ❼ Preventing the Unauthorized Use of the Projector [SECURITY] ........36 ❽ Projecting 3D videos.....................39 Procedure to watch 3D videos using this projector ..........39 When videos cannot be viewed in 3D ..............41 ❾...
  • Page 12 Table of Contents ❼ Menu Descriptions & Functions [SETUP] ..............94 [MENU] ........................94 [INSTALLATION] .....................96 [CONTROL] ......................99 [NETWORK SETTINGS] ..................107 [SOURCE OPTIONS] ...................112 [POWER OPTIONS] .....................114 Returning to Factory Default [RESET] ..............116 ❽ Menu Descriptions & Functions [INFO.] ..............118 [USAGE TIME] ......................118 [SOURCE(1)] ......................119 [SOURCE(2)] ......................119 [WIRED LAN] ......................119...
  • Page 13 Table of Contents 9. Appendix ......................158 ❶ Throw distance and screen size .................158 Lens types and throw distance ................158 Tables of screen sizes and dimensions ..............161 Lens shifting range ....................162 ❷ Compatible Input Signal List ..................164 ❸ Specifications ......................167 ❹ Cabinet Dimensions ....................169 ❺...

  • Page 14: Introduction

    Registration card Limited warranty For customers in Europe: You will find our current valid Guar- • Important Infomation (For North NEC Projector CD-ROM antee Policy on our Web Site: America: 7N8N4121) (For Other User’s manual (PDF) and the www.nec-display-solutions.com countries than North America:...

  • Page 15: ❷ Introduction To The Projector

    Please consult your dealer for more information. Installation • Liquid crystal type high brightness/high resolution projector Model Brightness Resolution Aspect Ratio PA622U 6200 lm WUXGA (1920 × 1200) 16:10 PA522U 5200 lm WUXGA (1920 × 1200) 16:10...

  • Page 16: Network

    Convenient utility software (User Supportware) provided as standard The three utility software stored in the enclosed NEC Projector CD-ROM (Virtual Remote Tool, PC Control Utility Pro 4 (for Windows ) and PC Control Utility Pro 5 (for Mac OS )) can be used. The following three utility software on the CD-ROM cannot be used.

  • Page 17: About This User's Manual

    1. Introduction About this user’s manual The fastest way to get started is to take your time and do everything right the first time. Take a few minutes now to review the user’s manual. This may save you time later on. At the beginning of each section of the manual you’ll find an overview.

  • Page 18: ❸ Part Names Of The Projector

    1. Introduction ❸ Part Names of the Projector Front/Top The lens is sold separately. The description below is for when the NP13ZL lens is mounted. Lens Shift Dial (vertical/horizontal) Securing lever cover (→ page 19) (→ page 135) Indicator Section Zoom Lever/Zoom Ring (→...

  • Page 19: Rear

    1. Introduction Rear Remote Sensor (located on the Terminal Panel front and the rear) (→ page 8) (→ page 11) Ventilation (outlet) Ventilation (inlet) / Filter Cover Heated air is exhausted from here. (→ page 138, 145) AC Input Connect the supplied power cord’s three-pin plug here, and plug the other end into an active wall outlet.

  • Page 20: Control Panel/Indicator Section

    1. Introduction Control Panel/Indicator Section (POWER) Button (→ page 14, 25) 2. POWER Indicator (→ page 13, 14, 25, 173) 3. STATUS Indicator (→ page 173) 4. LAMP Indicator (→ page 142, 174) 5. TEMP. Indicator (→ page 174) 6. INPUT Button (→...

  • Page 21: Terminal Panel Features

    4. BNC IN [R/Cr/CV, G/Y/Y, B/Cb/C, H, V] Connec- Use this connector for wired remote control of the tors (BNC × 5) projector using the NEC optional remote control. (→ page 125, 130) Connect the projector and optional remote control 5.

  • Page 22: ❹ Part Names Of The Remote Control

    1. Introduction ❹ Part Names of the Remote Control 29. ▲▼◀▶ Button 8. TEST Button (→ page 70) (→ page 62) 9. Edge Blend. Button 30. ENTER Button (→ page 91) (→ page 62) 10. Multi. Button 31. L-CLICK Button* (→...

  • Page 23: Battery Installation

    1. Introduction Battery Installation 1. Press the catch and remove 2. Install new ones (AA). En- 3. Slip the cover back over the batteries until the battery cover. sure that you have the bat- it snaps into place. teries’ polarity (+/−) aligned NOTE: Do not mix different types of batteries or new correctly.

  • Page 24: Operating Range For Wireless Remote Control

    1. Introduction Operating Range for Wireless Remote Control 40 m/1575 inch 20 m/787 inch 20 m/787 inch 20 m/787 inch Remote sensor on projector cabinet 20 m/787 inch Remote control 15 m/591 inch 15 m/591 inch 15 m/591 inch 15 m/591 inch 40 m/1575 inch 40 m/1575 inch •...

  • Page 25: Projecting An Image (Basic Operation)

    2. Projecting an Image (Basic Operation) This section describes how to turn on the projector and to project a picture onto the screen. ❶ Flow of Projecting an Image Step 1 • Connecting your computer / Connecting the power cord (→ page 13) Step 2 •...

  • Page 26: ❷ Connecting Your Computer/Connecting The Power Cord

    2. Projecting an Image (Basic Operation) ❷ Connecting Your Computer/Connecting the Power Cord 1. Connect your computer to the projector. This section will show you a basic connection to a computer. For information about other connections, see “(2) Making Connections” on page 125. Connect the display output terminal (mini D-sub 15 pin) on the computer to the computer video input terminal on the projector with a commercially-available computer cable (with ferrite core) and then turn the knobs of the con- nectors to secure them.

  • Page 27: ❸ Turning On The Projector

    2. Projecting an Image (Basic Operation) ❸ Turning on the Projector 1. Remove the lens cap. 2. Press the (POWER) button on the projector cabinet or the POWER ON button on the remote control. The POWER indicator will light up in blue from red and then start blinking.

  • Page 28: Note On Startup Screen (Menu Language Select Screen)

    2. Projecting an Image (Basic Operation) Note on Startup screen (Menu Language Select screen) When you first turn on the projector, you will get the Startup menu. This menu gives you the opportunity to select one of the 29 menu languages. To select a menu language, follow these steps: 1.

  • Page 29: ❹ Selecting A Source

    2. Projecting an Image (Basic Operation) ❹ Selecting a Source Selecting the computer or video source NOTE: Turn on the computer or video source equipment connected to the projector. Detecting the Signal Automatically Press the INPUT button for 1 second or longer. The projector will search for the available input source and display it.
  • Page 30 2. Projecting an Image (Basic Operation) Selecting Default Source You can set a source as the default source so that it will be displayed each time the projector is turned on. 1. Press the MENU button. The menu will be displayed. 2.

  • Page 31: ❺ Adjusting The Picture Size And Position

    2. Projecting an Image (Basic Operation) ❺ Adjusting the Picture Size and Position Use the lens shift dial, the adjustable tilt foot lever, the zoom lever/zoom ring and the focus ring to adjust the picture size and position. In this chapter drawings and cables are omitted for clarity. Adjusting the projected image’s vertical and horizontal Adjusting the focus position...

  • Page 32: Adjusting The Vertical Position Of A Projected Image (Lens Shift)

    2. Projecting an Image (Basic Operation) Adjusting the vertical position of a projected image (Lens shift) CAUTION Perform the adjustment from behind or from the side of the projector. Adjusting from the front could expose your eyes to strong light which could injure them. Lens shift dial (Horizontal) Leftward Rightward...

  • Page 33: Focus

    2. Projecting an Image (Basic Operation) TIP: • The diagram below shows the lens shift adjustment range for the PA622U and PA522U (projection mode: desktop front). To raise the projection position higher than this, use the tilt feet. (→ page 23) •...

  • Page 34: Applicable Lens: Np30Zl

    2. Projecting an Image (Basic Operation) Applicable lens: NP30ZL The NP30ZL lens unit aligns the peripheral focus around the optical axis. Peripheral focus ring Focus Ring Zoom Lever 1. Turn the focus ring left and right to align the focus around the optical axis.

  • Page 35: Applicable Lens: Np11Fl

    2. Projecting an Image (Basic Operation) Applicable lens: NP11FL With the NP11FL lens, adjust the focus and picture distortion. Preparations: Turn the lens shift dials (vertical and horizontal) on the projector to return the lens shift to the center. Approximate lens center position (explained here for the desktop front projection mode) Horizontal dial ��������...

  • Page 36: Zoom

    2. Projecting an Image (Basic Operation) Zoom Turn the zoom lever or zoom ring clockwise and counterclockwise. • The separately sold NP11FL lens does not have a zoom ring. Zoom ring Adjusting the Tilt Feet 1. Turn the left and right tilt feet to adjust. The tilt feet lengthen and shorten when turned.

  • Page 37: ❻ Optimizing Computer Signal Automatically

    2. Projecting an Image (Basic Operation) ❻ Optimizing Computer Signal Automatically Adjusting the Image Using Auto Adjust Optimizing a computer image automatically. (COMPUTER/BNC(Analog RGB)) Press the AUTO ADJ. button to optimize a computer image automatically. This adjustment may be necessary when you connect your computer for the first time. [Poor picture] [Normal picture] NOTE:...

  • Page 38: ❽ Turning Off The Projector

    2. Projecting an Image (Basic Operation) ❽ Turning off the Projector To turn off the projector: 1. First, press the (POWER) button on the projector cabinet or the POWER OFF button on the remote con- trol. The [POWER OFF / ARE YOU SURE ? / CARBON SAV- INGS- SESSION 0.000[g-CO2]] message will appear.

  • Page 39: ❾ After Use

    2. Projecting an Image (Basic Operation) ❾ After Use Preparation: Make sure that the projector is turned off. 1. Unplug the power cord. 2. Disconnect any other cables. 3. Mount the lens cap on the lens. 4. Before moving the projector, screw in the tilt feet if they have been lengthened.

  • Page 40: Convenient Features

    3. Convenient Features ❶ Turning off the Image and Sound The projected video and the output sound from the internal speaker and sound output terminal will disappear momentarily. Press the BLANK button. The projected video will be cut off. Press the MUTE button. The projected audio will be cut off.

  • Page 41: ❷ Freezing A Picture

    3. Convenient Features ❷ Freezing a Picture Press the FREEZE button to freeze a picture. Press again to resume motion. NOTE: The image is frozen but the original video is still playing back. ❸ Enlarging a Picture You can enlarge the picture up to four times. NOTE: The maximum magnification may be less than four times depending on the signal.

  • Page 42: ❹ Changing Eco Mode/Checking Energy-Saving Effect Using Eco Mode [Eco Mode]

    3. Convenient Features ❹ Changing Eco Mode/Checking Energy-Saving Effect Using Eco Mode [ECO MODE] This feature enables you to select two brightness modes of the lamp: OFF and ON modes. The lamp life can be extended by turning on the [ECO MODE]. [ECO MODE] Description [OFF]...

  • Page 43: Checking Energy-Saving Effect [Carbon Meter]

    3. Convenient Features Checking Energy-Saving Effect [CARBON METER] This feature will show energy-saving effect in terms of CO emission reduction (kg) when the projector’s [ECO MODE] is set to [OFF], or [ON]. This feature is called as [CARBON METER]. There are two messages: [TOTAL CARBON SAVINGS] and [CARBON SAVINGS-SESSION]. The [TOTAL CARBON SAVINGS] message shows the total amount of CO emission reduction from the time of shipment up to now.

  • Page 44: ❺ Using The Optional Remote Mouse Receiver (Np01Mr)

    3. Convenient Features ❺ Using the Optional Remote Mouse Receiver (NP01MR) The optional remote mouse receiver enables you to operate your computer’s mouse functions from the remote control. It is a great convenience for clicking through your computer-generated presentations. Connecting the remote mouse receiver to your computer If you wish to use the remote mouse function, connect the mouse receiver and computer.

  • Page 45: About Drag Mode

    3. Convenient Features Operating your computer’s mouse from the remote control You can operate your computer’s mouse from the remote control. CTL Button + PAGE ▼/▲ Button ������������������������������ scrolls the viewing area of the window or to move to the previous or next slide in PowerPoint on your computer�...

  • Page 46: ❻ Correcting Horizontal And Vertical Keystone Distortion [Cornerstone]

    3. Convenient Features ❻ Correcting Horizontal and Vertical Keystone Distortion [COR- NERSTONE] Use the [CORNERSTONE] feature to correct keystone (trapezoidal) distortion to make the top or bottom and the left or right side of the screen longer or shorter so that the projected image is rectangular. 1.
  • Page 47 3. Convenient Features 5. Press the ▼ button to align with the [CORNERSTONE] and then press the ENTER button. The drawing shows the upper left icon ( ) is selected. The screen will switch to the [CORNERSTONE] screen. NOTE: • When a [GEOMETRIC CORRECTION] function other than [CORNERSTONE] has been set up, the [CORNERSTONE] screen will not be displayed.
  • Page 48 3. Convenient Features 11. Press the ◀ or ▶ button to highlight the [OK] and press the ENTER button. This completes the [CORNERSTONE] correction. • Select [CANCEL] and press the ENTER button to return to the [CORNERSTONE] screen. Selecting [CANCEL] will return to the adjustment screen without saving changes (Step 3). Selecting [RESET] will return to the factory default.

  • Page 49: ❼ Preventing The Unauthorized Use Of The Projector [Security]

    3. Convenient Features ❼ Preventing the Unauthorized Use of the Projector [SECURITY] A keyword can be set for your projector using the Menu to avoid operation by an unauthorized user. When a keyword is set, turning on the projector will display the Keyword input screen. Unless the correct keyword is entered, the pro- jector cannot project an image.
  • Page 50 3. Convenient Features 7. Type in the same combination of ▲▼◀▶ buttons and press the ENTER button. The confirmation screen will be displayed. 8. Select [YES] and press the ENTER button. The SECURITY function has been enabled. To turn on the projector when [SECURITY] is enabled: 1.
  • Page 51 3. Convenient Features To disable the SECURITY function: 1. Press the MENU button. The menu will be displayed. 2. Select [SETUP] → [CONTROL] → [SECURITY] and press the ENTER button. The OFF/ON menu will be displayed. 3. Select [OFF] and press the ENTER button. The SECURITY KEYWORD screen will be displayed.

  • Page 52: ❽ Projecting 3D Videos

    3. Convenient Features ❽ Projecting 3D videos This projector can be used to watch videos in 3D using commercially-available active shutter-type 3D eyewear. In order to synchronize the 3D video and eyewear, a commercially-available 3D emitter needs to be connected to the projector (on the projector side).
  • Page 53 3. Convenient Features The [3D SETTINGS] screen will be displayed. (2)Press the ▼ button to align the cursor with the [FORMAT] and press the ENTER button. The format screen will be displayed. (3)Select the input signal format using the ▼ button and then press the ENTER button. The 3D settings screen will disappear and the 3D video will be projected.

  • Page 54: When Videos Cannot Be Viewed In 3D

    3. Convenient Features When videos cannot be viewed in 3D Please check the following points when videos cannot be viewed in 3D. Please also read the operating manual attached to the 3D eyewear. Possible reasons Solutions The selected signal does not support 3D output� Please change the video signal input to one that supports 3D�...

  • Page 55: ❾ Controlling The Projector By Using An Http Browser

    3. Convenient Features ❾ Controlling the Projector by Using an HTTP Browser Overview The HTTP Server function provides settings and operations for: 1. Setting for wired network (NETWORK SETTINGS) To use wired LAN connection, connect the projector to the computer with a commercially available LAN cable. (→ page 137) 2.

  • Page 56: Handling Of The Address For Operation Via A Browser

    IP address of the projector has been set in the “HOSTS” file of the computer being used. Example 1: When the host name of the projector has been set to “pj.nec.co.jp”, access is gained to the network setting by specifying http://pj.nec.co.jp/index.html...
  • Page 57 3. Convenient Features PICTURE: Controls the video adjustment of the projector. BRIGHTNESS ▲ ���� Increases the brightness adjustment value� BRIGHTNESS ▼ ���� Decreases the brightness adjustment value� CONTRAST ▲ �������� Increases the contrast adjustment value� CONTRAST ▼ �������� Decreases the contrast adjustment value� COLOR ▲...

  • Page 58: Network Settings

    3. Convenient Features NETWORK SETTINGS • SETTINGS WIRED SETTING Set for wired LAN. APPLY Apply your settings to wired LAN. PROFILE 1/PROFILE 2 Two settings can be set for wired LAN connection. Select PROFILE 1 or PROFILE 2. DISABLE Turn off wired LAN connection DHCP ON Automatically assign IP address, subnet mask, and gateway to the projector from your DHCP server.
  • Page 59 Sample of a message to be sent from the projector: The lamp and filters are at the end of its usable life. Please replace the lamp and filters. Projector Name: NEC Projector Lamp Hours Used: 100 [H] SENDER’S ADDRESS Enter sender’s address.
  • Page 60 3. Convenient Features • NETWORK SERVICE PJLink PASSWORD Set a password for PJLink*. A password must be 32 characters or less. Do not forget your password. However, if you forget your password, consult with your dealer. HTTP PASSWORD Set a password for HTTP server. A password must be 10 characters or less. When a password is set up, you will be prompted for your user name (arbitrary) and password during LOGON.

  • Page 61: Multi-Screen Projection

    4. Multi-Screen Projection ❶ Things that can be done using multi-screen projection This projector can be used singly or arranged in multiple units for multi-screen projection. We will introduce an example using two projection screens here. Case 1 Using a single projector to project two types of videos at the same time [PIP/PICTURE BY PICTURE] Case 2 Using four projectors (liquid crystal panel: XGA) to project video with a resolution of 1920 ×...

  • Page 62: Case 2. Using Four Projectors (Liquid Crystal Panel: Xga) To Project Videos With A Resolution Of 1920 × 1080 Pixels [Tiling]

    4. Multi-Screen Projection Case 2. Using four projectors (liquid crystal panel: XGA) to project videos with a resolution of 1920 × 1080 pixels [TILING] Connection example and projection image On-screen menu operations 1 Four similar videos are displayed when four projectors are projected. Please request the retail store to adjust the projection position of each projector.
  • Page 63 4. Multi-Screen Projection 2 Operate the on-screen menu using the four respective projectors to divide the image into four portions. Display [DISPLAY] → [MULTI SCREEN] → [PICTURE SETTING] Screen in the on-screen menu and select [TIL- ING]. (1)In the screen for setting the number of horizontal units, select [2 UNITS]. (number of units in the horizontal direc- tion) (2)In the screen for setting the number of vertical units, select [2 UNITS].

  • Page 64: Things To Note When Installing Projectors

    4. Multi-Screen Projection Things to note when installing projectors • Leave sufficient space on the left and right of the projector so that the air intake and discharge outlets of the projector are not obstructed. When the air intake and discharge outlet are obstructed, the temperature inside the projector will rise and this may result in a malfunction.

  • Page 65: ❷ Displaying Two Pictures At The Same Time

    4. Multi-Screen Projection ❷ Displaying Two Pictures at the Same Time The projector has a feature that allows you to view two different signals simultaneously. You have two modes: PIP mode and PICTURE BY PICTURE mode. The projection video in the first screen display is known as the main display while the projection video that is called out subsequently is known as the sub-display.

  • Page 66: Projecting Two Screens

    4. Multi-Screen Projection Projecting two screens 1. Press the MENU button to display the on-screen menu and select [DISPLAY] → [PIP/PICTURE BY PIC- TURE]. This displays the [PIP/PICTURE BY PICTURE] screen in the on-screen menu. 2. Select [SUB INPUT] using the ▼/▲ buttons, and press the ENTER button. This displays the [SUB INPUT] screen.

  • Page 67: Switching The Main Display With The Sub-Display And Vice Versa

    4. Multi-Screen Projection Switching the main display with the sub-display and vice versa 1. Press the MENU button to display the on-screen menu and select [DISPLAY] → [PIP/PICTURE BY PIC- TURE]. This displays the [PIP/PICTURE BY PICTURE] screen in the on-screen menu. 2.

  • Page 68: Restrictions

    4. Multi-Screen Projection Restrictions • The following operations are enabled only for the main display. • Audio-visual adjustments • Video magnification / compression using the partial D-ZOOM/ZOOM +/− buttons. However, magnification / compression is up to the positions set in [PICTURE BY PICTURE BORDER] only. •...

  • Page 69: ❸ Displaying A Picture Using [Edge Blending]

    4. Multi-Screen Projection ❸ Displaying a Picture Using [EDGE BLENDING] A high resolution video can be projected on an even bigger screen by combining multiple projectors on the left, right, top and bottom. This projector is equipped with an “EDGE BLENDING Function” that makes the edges (boundaries) of the projection screen indistinguishable.

  • Page 70: Setting The Overlap Of Projection Screens

    4. Multi-Screen Projection Preparation: • Turn on the projector and display a signal. • When performing settings or adjustments using the remote control, enable the [CONTROL ID] so as not to activate the other projectors. (→ page 105) Setting the overlap of projection screens ①...
  • Page 71 4. Multi-Screen Projection 4 Select [CONTROL] → [ON] and press the ENTER button. Each [TOP], [BOTTOM], [LEFT], [RIGHT], and [BLACK LEVEL] has its own [CONTROL], [MARKER], [RANGE], and [POSITION]. • For Projector A, set the [CONTROL] for the [TOP], [LEFT] and[BOTTOM] to [OFF]. Similarly for Projector B, set the [CONTROL] for the [TOP], [RIGHT] and [BOTTOM] to [OFF].
  • Page 72 4. Multi-Screen Projection 1 Adjust [RANGE]. Use the ◀ or ▶ button to adjust the overlapped area. TIP: • Adjust to overlap one projector’ marker with the other projector’s marker. 2 Adjust [POSITION]. Use the ◀ or ▶ button to align one edge with the other edge of overlapped images. TIP: •...

  • Page 73: Black Level Adjustment

    4. Multi-Screen Projection Black Level Adjustment This adjusts the black level of the overlapping area and the non-overlapping area of the multi-screen (EDGE BLEND- ING). Adjust the brightness level if you feel the difference is too large. NOTE: This function is enabled only when [MODE] is turned on. Adjustable area varies depending on what combination of [TOP], [BOTTOM], [LEFT] and [RIGHT] are turned on.

  • Page 74: Segmented Portions For Black Level Adjustment

    4. Multi-Screen Projection 9-segmented portions for Black Level adjustment The center projector This function adjusts the brightness level of 9-segmented portions for the center projector and 4-segmented portions for the left bottom projector as shown below. TOP-CENTER TOP-LEFT TOP-RIGHT CENTER- LEFT CENTER-RIGHT CENTER...

  • Page 75: Using On-Screen Menu

    5. Using On-Screen Menu ❶ Using the Menus NOTE: The on-screen menu may not be displayed correctly while interlaced motion video image is projected. 1. Press the MENU button on the remote control or the projector cabinet to display the menu. NOTE: The commands such as ENTER, EXIT, ▲▼, ◀▶...

  • Page 76: ❷ Menu Elements

    5. Using On-Screen Menu ❷ Menu Elements Slide bar Solid triangle Available buttons Source Menu mode Highlight Radio button ECO mode symbol Off Timer remaining High Altitude symbol time Thermometer symbol Key Lock symbol Menu windows or dialog boxes typically have the following elements: Highlight �����������������������������Indicates the selected menu or item�...

  • Page 77: ❸ List Of Menu Items

    5. Using On-Screen Menu ❸ List of Menu Items • Basic menu items are indicated by shaded area. Some menu items are not available depending on the input source. Menu Item Default Options 1:HDMI1 2:HDMI2 3:DisplayPort 4:BNC 5:BNC(CV) INPUT 6:BNC(Y/C) 7:COMPUTER 8:HDBaseT ENTRY LIST...
  • Page 78 5. Using On-Screen Menu Menu Item Default Options OFF, HDMI1, HDMI2, DisplayPort, BNC, BNC(CV), BNC(Y/C), SUB INPUT COMPUTER, HDBaseT MODE PIP, PICTURE BY PICTURE PICTURE SWAP OFF, ON PIP/PICTURE START POSITION TOP-LEFT, TOP-RIGHT, BOTTOM-LEFT, BOTTOM-RIGHT BY PICTURE HORIZONTAL POSITION PIP SETTING VERTICAL POSITION SIZE LARGE, MEDIUM, SMALL...
  • Page 79 5. Using On-Screen Menu Menu Item Default Options ENGLISH, DEUTSCH, FRANÇAIS, ITALIANO, ESPAÑOL, SVENSKA, 日本語 DANSK, PORTUGUÊS, ČEŠTINA, MAGYAR, POLSKI, NEDERLANDS, SUOMI LANGUAGE ENGLISH , Ελληνικά, 中文, 한국어 NORSK, TÜRKÇE, РУССКИЙ, ROMÂNĂ, HRVATSKA, БЪЛГАРСКИ, INDONESIA, हिन् द ी, ไทย, , 繁體中文 COLOR SELECT COLOR COLOR, MONOCHROME...
  • Page 80 5. Using On-Screen Menu Menu Item Default Options MENU MODE ADVANCED ADVANCED, BASIC NOT SAVE SETTING VALUES OFF, ON ADMINISTRA- TOR MODE NEW PASSWORD CONFIRM PASSWORD ENABLE OFF, ON ACTIVE OFF, ON SUN, MON, TUE, WED, THU, FRI, SAT, MON-FRI, MON-SAT, EVERY TIME FUNCTION POWER, INPUT, ECO MODE...
  • Page 81 192�168�0�10 SUBNET MASK 255�255�255�0 WIRED LAN GATEWAY 192�168�0�1 AUTO DNS OFF, ON DNS CONFIGURATION RECONNECT PROJECTOR NAME PROJECTOR NAME PA622U Series HOST NAME necpj DOMAIN DOMAIN NAME ALERT MAIL OFF, ON NETWORK HOST NAME SETTINGS DOMAIN NAME SENDER'S ADDRESS ALERT MAIL...
  • Page 82 5. Using On-Screen Menu Menu Item Default Options LAMP LIFE REMAINING LAMP HOURS USED USAGE TIME FILTER HOURS USED TOTAL CARBON SAVINGS INPUT TERMINAL RESOLUTION HORIZONTAL FREQUENCY VERTICAL FREQUENCY SOURCE(1) SYNC TYPE SYNC POLARITY SCAN TYPE SOURCE NAME ENTRY NO� SIGNAL TYPE VIDEO TYPE BIT DEPTH...

  • Page 83: ❹ Menu Descriptions & Functions [Input]

    5. Using On-Screen Menu ❹ Menu Descriptions & Functions [INPUT] 1:HDMI1 This projects the video of the device connected to the HDMI 1 IN terminal. 2:HDMI2 This projects the video of the device connected to the HDMI 2 IN terminal. 3:DisplayPort This projects the video of the device connected to the Display Port input terminal.
  • Page 84 5. Using On-Screen Menu Using the Entry List When any source adjustments are made, the adjustments are automatically registered in the Entry List. The (adjust- ment values of) registered signals can be loaded from the Entry List whenever necessary. However, only up to 100 patterns can be registered in the Entry List. When 100 patterns have been registered in the Entry List, an error message is then displayed and no additional patterns can be registered.
  • Page 85 5. Using On-Screen Menu Entering the currently projected signal into the Entry List [STORE] 1. Press the ▲ or ▼ button to select any number. 2. Press the ◀ or ▶ button to select [STORE] and press the ENTER button. Calling up a signal from the Entry List [LOAD] Press the ▲...
  • Page 86 5. Using On-Screen Menu Cutting a signal from the Entry List [CUT] 1. Press the ▲ or ▼ button to select a signal you wish to delete. 2. Press the ◀, ▶, ▲, or ▼ button to select [CUT] and press the ENTER button. The signal will be deleted from the Entry List and the deleted signal will be displayed on the clipboard at the bottom of the Entry List.

  • Page 87: ❺ Menu Descriptions & Functions [Adjust]

    5. Using On-Screen Menu ❺ Menu Descriptions & Functions [ADJUST] [PICTURE] [MODE] This function allows you to determine how to save settings for [DETAIL SETTINGS] of [PRESET] for each input. STANDARD ������������ Saves settings for each item of [PRESET] (Preset 1 through 7) PROFESSIONAL �����...

  • Page 88: Detail Settings

    5. Using On-Screen Menu [DETAIL SETTINGS] [GENERAL] Storing Your Customized Settings [REFERENCE] This function allows you to store your customized settings in [PRESET 1] to [PRESET 7]. First, select a base preset mode from [REFERENCE], then set [GAMMA CORRECTION] and [COLOR TEMPERA- TURE].

  • Page 89: Color Correction

    5. Using On-Screen Menu Adjusting Color Temperature [COLOR TEMPERATURE] This option allows you to select the color temperature of your choice. A value between 5000 K and 10500 K can be set in 100 K units. NOTE: When [PRESENTATION] or [HIGH-BRIGHT] is selected in [REFERENCE], this function is not available. Adjusting Brightness and Contrast [DYNAMIC CONTRAST] When set, the most optimal contrast ratio is adjusted according to the video.
  • Page 90 5. Using On-Screen Menu [COLOR] Increases or decreases the color saturation level. [HUE] Varies the color level from +/− green to +/− blue. The red level is used as reference. Input signal CONTRAST BRIGHTNESS SHARPNESS COLOR RGB system of “COMPUTER/Display- Port/HDMI/HDBaseT”...

  • Page 91: [Image Options]

    5. Using On-Screen Menu [IMAGE OPTIONS] Adjusting Clock and Phase [CLOCK/PHASE] This allows you to manually adjust CLOCK and PHASE. CLOCK ������������������� Use this item to fine tune the computer image or to remove any vertical banding that might appear� This function adjusts the clock frequencies that eliminate the horizontal banding in the image�...
  • Page 92 5. Using On-Screen Menu Adjusting Horizontal/Vertical Position [HORIZONTAL/VERTICAL] Adjusts the image location horizontally and vertically. • An image can be distorted during the adjustment of [CLOCK] and [PHASE]. This is not malfunction. • The adjustments for [CLOCK], [PHASE], [HORIZONTAL], and [VERTICAL] will be stored in memory for the current signal.
  • Page 93 5. Using On-Screen Menu Selecting the Aspect Ratio [ASPECT RATIO] Use this function to select the screen’s vertical:horizontal aspect ratio. Select the screen type (4:3 screen, 16:9 screen or 16:10 screen) at the screen setting before setting the aspect ratio. (→...

  • Page 94: Input Resolution

    5. Using On-Screen Menu Options Function NATIVE The projector displays the current image in its true resolution when the incoming computer signal has a lower or higher resolution than the projector’s native resolution. (→ page 2) When the incoming computer signal has a higher resolution than the projector's native resolution, the center of an image will be displayed.

  • Page 95: [Video]

    5. Using On-Screen Menu [VIDEO] Using Noise Reduction [NOISE REDUCTION] When projecting a video image, you can use the [NOISE REDUCTION] function to reduce the screen noise (roughness and distortion). This device is equipped with three types of noise reduction functions. Select the function according to the type of noise.

  • Page 96: Signal Type

    5. Using On-Screen Menu [SIGNAL TYPE] Selection of RGB and component signals. Normally, this is set to [AUTO]. Please change the setting if the color of the image remains unnatural. AUTO ��������������������� Automatically distinguishes RGB and component signals� RGB ����������������������� Switches to the RGB input� COMPONENT ���������...

  • Page 97: [3D Settings]

    5. Using On-Screen Menu [3D SETTINGS] Please refer to “3-8 Projecting 3D videos” (→ page 39) for the operation. STEREO VIEWER Stack up a single or multiple projectors and carry out the settings for projecting 3D videos. Select the left / right set- tings of the 3D eyewear using the stereo viewer.

  • Page 98: ❻ Menu Descriptions & Functions [Display]

    5. Using On-Screen Menu ❻ Menu Descriptions & Functions [DISPLAY] [PIP/PICTURE BY PICTURE] SUB INPUT Select the input signal to be displayed in the sub-display. Please refer to “4-2 Displaying Two Pictures at the Same Time” (→ page 52) for details on the operation. MODE Select either PIP or PICTURE BY PICTURE when switching to 2-screen display.
  • Page 99 Select the display boundary of the main display and sub-display of the [PICTURE BY PICTURE] screen. Main display Sub-display Main display Sub-display Main display Sub-display Display boundary TIP: • For PA622U/PA522U, six stages can be selected. • For PA672W/PA572W/PA722X/PA622X, three stages can be selected.

  • Page 100: [Geometric Correction]

    5. Using On-Screen Menu [GEOMETRIC CORRECTION] KEYSTONE Display the trapezoid correction screen and adjust the trapezoidal distortion of the projection screen. To display the [KEYSTONE] screen, select → [DISPLAY] → [GEOMETRIC CORRECTION] → [KEYSTONE] in the on-screen menu. The [GEOMETRIC CORRECTION] screen can also be displayed by pressing the Geometric. button on the remote control.
  • Page 101 5. Using On-Screen Menu CORNERSTONE Display the 4-point correction screen and adjust the trapezoidal distortion of the projection screen. Please refer to “Correcting Horizontal and Vertical Keystone Distortion [CORNERSTONE]” (→ page 33) for details on the operation. HORIZONTAL CORNER/VERTICAL CORNER Distortion correction for corner projection such as wall surfaces.
  • Page 102 5. Using On-Screen Menu Adjustment method 1. Align the cursor with the [HORIZONTAL CORNER] or [VERTICAL CORNER] of the [GEOMETRIC CORREC- TION] menu and then press the ENTER button. • The adjustment screen will be displayed. 2. Press the ▼▲◀▶ buttons to align the cursor (yellow box) with the target adjustment point and then press the ENTER button.
  • Page 103 5. Using On-Screen Menu PINCUSHION Adjust the curve distortion of the projection screen. TOP ������������������������ Adjust the curve distortion of the upper edge of the projection screen� BOTTOM ���������������� Adjust the curve distortion of the lower edge of the projection screen�...

  • Page 104: [Edge Blending]

    5. Using On-Screen Menu [EDGE BLENDING] This adjusts the edges (boundaries) of the projection screen when projecting high resolution videos using a combina- tion of several projectors in the up, down, left and right positions. MODE This enables or disables the EDGE BLENDING function. When MODE is set to ON, the TOP, BOTTOM, LEFT, RIGHT and BLACK LEVEL settings can be adjusted.

  • Page 105: [Multi Screen]

    5. Using On-Screen Menu [MULTI SCREEN] WHITE BALANCE This adjusts the white balance for each projector when projecting using a combination of several projectors. This can be adjusted when [MODE] is set to [ON]. BRIGHTNESS W, BRIGHTNESS R, BRIGHTNESS G, BRIGHTNESS B ������������������������������...
  • Page 106 5. Using On-Screen Menu Conditions for using tiling All the projectors need to fulfil the following conditions. • The panel size must be the same • The projection screen size must be the same • The left and right ends or top and bottom ends of the projection screen must be consistent. •...

  • Page 107: ❼ Menu Descriptions & Functions [Setup]

    5. Using On-Screen Menu ❼ Menu Descriptions & Functions [SETUP] [MENU] Selecting Menu Language [LANGUAGE] You can choose one of 29 languages for on-screen instructions. NOTE: Your setting will not be affected even when [RESET] is done from the menu. Selecting Menu Color [COLOR SELECT] You can choose between two options for menu color: COLOR and MONOCHROME.
  • Page 108 5. Using On-Screen Menu Turning On / Off Eco Message [ECO MESSAGE] This option turns on or off the following messages when the projector is turned on. The Eco Message prompts the user to save energy. When [OFF] is selected for [ECO MODE], you will get a message to prompt you to select [ON] for [ECO MODE].

  • Page 109: [Installation]

    5. Using On-Screen Menu [INSTALLATION] Selecting Projector Orientation [ORIENTATION] This reorients your image for your type of projection. The options are: desktop front projection, ceiling rear projection, desktop rear projection, and ceiling front projection. NOTE: • Please consult the retail store if you require special installation services e.g. when mounting the projector to a ceiling. Never install the projector on your own.
  • Page 110 5. Using On-Screen Menu Selecting Aspect Ratio and Position for Screen [SCREEN TYPE] Screen type Sets the aspect ratio of the projection screen. FREE The ratio of the liquid crystal panel is selected. Select this when projecting multi-screen and 17:9 screen (2K). 4:3 screen For a screen with a 4:3 aspect ratio 16:9 screen...

  • Page 111: Lamp Mode

    5. Using On-Screen Menu [LAMP MODE] When eco-mode is set to [ON], the CO emissions (calculated from the reduction in power consumption) of the projec- tor can be reduced. The eco-mode reduces power consumption by mainly lowering the brightness of the lamp. As a result, the lamp replacement time (as a guide)* is extended.

  • Page 112: [Control]

    5. Using On-Screen Menu [CONTROL] TOOLS ADMINISTRATOR MODE This allows you to select MENU MODE, save settings, and set a password for the administrator mode. MENU MODE Select either [BASIC] or [ADVANCED] menu. — (→ page 64) Placing a check mark will not save your projector settings� NOT SAVE SETTING —...
  • Page 113 5. Using On-Screen Menu PROGRAM TIMER This option turns on/standby the projector and changes video signals, and selects ECO mode automatically at a specified time. NOTE: • Before using [PROGRAM TIMER], make sure that the [DATE AND TIME] feature is set. (→ page 103) Make sure that the projector is in the standby condition with the POWER cord connected.
  • Page 114 5. Using On-Screen Menu FRI]� To execute the program in everyday basis, select [EVERYDAY]� TIME ���������������������� Set the time to execute the program� Enter time in 24-hour format� FUNCTION ������������� Select a function to be executed� Selecting [POWER] will allow you to turn on or off the projector by setting [ADVANCED SETTINGS]�...
  • Page 115 5. Using On-Screen Menu Activating the program timer 1. Select [ENABLE] on the [PROGRAM TIMER] screen and press the ENTER button. The selection screen will be displayed. 2. Press the ▼ button to align the cursor with [ON] and then press the ENTER button. Return to the [PROGRAM TIMER] screen.

  • Page 116: Date And Time Settings

    5. Using On-Screen Menu DATE AND TIME SETTINGS You can set the current time, month, date, and year. NOTE: The projector has a built-in clock. The clock will keep working for about 2 weeks after the main power is turned off. If the main power is off for 2 weeks or more, the built-in clock will cease.
  • Page 117 5. Using On-Screen Menu Disabling the Cabinet Buttons [CONTROL PANEL LOCK] This option turns on or off the CONTROL PANEL LOCK function. NOTE: • How to cancel the [CONTROL PANEL LOCK] When the [CONTROL PANEL LOCK] is set to [ON], press the EXIT button or the INPUT button on the main body for about 10 seconds to cancel the [CONTROL PANEL LOCK] setting.
  • Page 118 5. Using On-Screen Menu Setting ID to the Projector [CONTROL ID] You can operate multiple projectors separately and independently with the single remote control that has the CONTROL ID function. If you assign the same ID to all the projectors, you can conveniently operate all the projectors together using the single remote control.
  • Page 119 5. Using On-Screen Menu Turning On or Off Remote Sensor [REMOTE SENSOR] This option determines which remote sensor on the projector is enabled in wireless mode. The options are: FRONT/BACK, FRONT, BACK, and HDBaseT. NOTE: • The remote control of the projector will not be able to receive signals if the power supply of the HDBaseT transmission device connected to the projector is switched on when this has been set to “HDBaseT”.

  • Page 120: [Network Settings]

    5. Using On-Screen Menu [NETWORK SETTINGS] Important: • Consult with your network administrator about these settings. • When using a wired LAN connection, connect a LAN cable (Ethernet cable) to the LAN port (RJ-45) of the projector. (→ page 137) TIP: The network settings you make will not be affected even when [RESET] is done from the menu.
  • Page 121 5. Using On-Screen Menu WIRED LAN PROFILES • The settings for using the built-in Ethernet/HDBaseT port in — the projector can be recorded in the projector memory in two ways. • Select [PROFILE 1] or [PROFILE 2] and then do settings for [DHCP] and the other options.
  • Page 122 5. Using On-Screen Menu PROJECTOR NAME PROJECTOR NAME Set a unique projector name. Up to 16 alphanu- meric characters and symbols DOMAIN Set a host name and domain name of the projector. HOST NAME Set a host name of the projector. Up to 15 alphanumeric characters DOMAIN NAME...
  • Page 123 Sample of a message to be sent from the projector: The lamp and filters are at the end of its usable life. Please replace the lamp and filters. Projector Name: NEC Projector Lamp Hours Used: 100 [H] HOST NAME Type in a host name.
  • Page 124 5. Using On-Screen Menu NETWORK SERVICE HTTP SERVER Set a password for your HTTP server. Up to 10 alphanumeric characters PJLink This option allows you to set a password when you use the Up to 32 alphanumeric PJLink feature. characters NOTE: •...

  • Page 125: [Source Options]

    5. Using On-Screen Menu [SOURCE OPTIONS] Setting Auto Adjust [AUTO ADJUST] This feature sets the Auto Adjust mode so that the computer signal can be automatically or manually adjusted for noise and stability. You can automatically make adjustment in two ways: [NORMAL] and [FINE]. OFF ������������������������...
  • Page 126 5. Using On-Screen Menu [SEAMLESS SWITCHING] When the input connector is switched, the image displayed before switching is held to switch to the new image without a break due to absence of a signal. Setting Closed Caption [CLOSED CAPTION] This option sets several closed caption modes that allow text to be superimposed on the projected image of Video or S-Video.

  • Page 127: [Power Options]

    5. Using On-Screen Menu [POWER OPTIONS] Selecting Power-saving in [STANDBY MODE] Setting the power consumption in the standby mode. NORMAL ���������������� In the standby mode, the power consumption of the projector is 0�11 W (100-130 V)/0�16 W (200- 240 V)� In the standby mode, the POWER indicator lights up in red while the STATUS indicator will go off�...
  • Page 128 5. Using On-Screen Menu Turning On the Projector By Applying Computer Signal [AUTO POWER ON SELECT] This setting automatically projects any computer signal that is input when the projector is in the standby mode. Connect to the input terminal on the projector using a cable and put the projector in the standby mode. When using the [AUTO POWER ON SELECT], set the [STANDBY MODE] to [HDBaseT STANDBY], turn on the power supply of the transmission device and keep it in a connected state.

  • Page 129: Returning To Factory Default [Reset]

    5. Using On-Screen Menu Returning to Factory Default [RESET] The RESET feature allows you to change adjustments and settings to the factory preset for a (all) source (s) except the following: [CURRENT SIGNAL] Resets the adjustments for the current signal to the factory preset levels. The items that can be reset are: [PRESET], [CONTRAST], [BRIGHTNESS], [COLOR], [HUE], [SHARPNESS], [AS- PECT RATIO], [HORIZONTAL], [VERTICAL], [CLOCK], [PHASE], and [OVERSCAN].
  • Page 130 5. Using On-Screen Menu Clearing the Filter Usage Hours [CLEAR FILTER HOURS] Resets the filter usage back to zero. Selecting this option displays submenu for a confirmation. Select [YES] and press the ENTER button. The [OFF] item is selected for [FILTER MESSAGE] at the time of shipment. When [OFF] is selected, you do not need to clear the filter usage hour.

  • Page 131: ❽ Menu Descriptions & Functions [Info.]

    5. Using On-Screen Menu ❽ Menu Descriptions & Functions [INFO.] Displays the status of the current signal and lamp usage. This item has nine pages. The information included is as follows: TIP: Pressing the HELP button on the remote control will show the [INFO.] menu items. [USAGE TIME] [LAMP LIFE REMAINING] (%)* [LAMP HOURS USED] (H)

  • Page 132: [Source(1)]

    5. Using On-Screen Menu [SOURCE(1)] INPUT TERMINAL RESOLUTION HORIZONTAL FREQUENCY VERTICAL FREQUENCY SYNC TYPE SYNC POLARITY SCAN TYPE SOURCE NAME ENTRY NO. [SOURCE(2)] SIGNAL TYPE VIDEO TYPE BIT DEPTH VIDEO LEVEL LINK RATE LINK LANE [WIRED LAN] IP ADDRESS SUBNET MASK GATEWAY MAC ADDRESS...

  • Page 133: [Version(1)]

    5. Using On-Screen Menu [VERSION(1)] FIRMWARE DATA SUB-CPU [OTHERS] DATE TIME PROJECTOR NAME MODEL NO. SERIAL NUMBER CONTROL ID (when [CONTROL ID] is set)

  • Page 134: [Conditions]

    5. Using On-Screen Menu [CONDITIONS] INTAKE TEMPERATURE EXHAUST TEMPERATURE INSTALLATION POSITION X-AXIS Y-AXIS Z-AXIS About the X-AXIS, Y-AXIS and Z-AXIS CONDITIONS * Arrow direction of the Z-AXIS in the figure represents the top of the projector. X-AXIS ������������������� Display the projector image at an angle of −100 – +100 X-AXIS value of the projector degrees to the horizontal in the X-axis direction�...

  • Page 135: [Hdbaset]

    5. Using On-Screen Menu [HDBaseT] SIGNAL QUALITY OPERATION MODE LINK STATUS HDMI STATUS...

  • Page 136: Connecting To Other Equipment

    6. Connecting to Other Equipment ❶ Mounting a lens (sold separately) Six separate bayonet style lenses can be used with this projector. The descriptions here are for the NP13ZL (2x zoom) lens. Mount other lenses in the same manner. NOTE: •...

  • Page 137: Removing The Lens

    6. Installation and Connections 4. Turn the lens clockwise. Turn until a click is heard. The lens is now fastened onto the projector. TIP: Mounting the lens theft prevention screw Fasten the lens theft prevention screw included with the projector to the bottom of the projector so that the lens cannot be removed easily.

  • Page 138: ❷ Making Connections

    6. Installation and Connections ❷ Making Connections A computer cable, BNC cable (5-core type), HDMI cable, or a DisplayPort cable can be used to connect to a com- puter. The connection cable is not enclosed with the projector. Please get ready a suitable cable for the connection. Analog RGB signal connection •...

  • Page 139: Digital Rgb Signal Connection

    6. Installation and Connections Digital RGB signal connection • Connect a commercially available HDMI cable between the computer’s HDMI output connector and the projector’s HDMI1 or HDMI2 input connector. • Connect a commercially available DisplayPort cable between the computer’s DisplayPort output connector and the projector’s DisplayPort input connector.

  • Page 140: Installation And Connections

    6. Installation and Connections Cautions when connecting an HDMI cable • Use a certified High Speed HDMI Cable or High Speed HDMI Cable with Ethernet. ® ® Cautions when connecting a DisplayPort cable • Use a certified DisplayPort cable. • Depending on the computer, some time may be required until the image is displayed.
  • Page 141 6. Installation and Connections Cautions when using a DVI signal • When the computer has a DVI output connector, use a commercially available converter cable to connect the computer to the projector’s HDMI 1 or HDMI 2 input connector (only digital video signals can be input). Also, con- nect the computer’s audio output to the projector’s BNC audio input connector.

  • Page 142: Connecting An External Monitor

    6. Installation and Connections Connecting an External Monitor HDMI OUT AUDIO OUT Stereo mini-plug audio cable (not supplied) HDMI cable (not supplied) HDMI IN AUDIO IN Computer cable (VGA) (not supplied) You can connect a separate, external monitor to your projector to simultaneously view on a monitor the computer analog image you’re projecting.

  • Page 143: Connecting Your Blu-Ray Player Or Other Av Equipment

    6. Installation and Connections Connecting Your Blu-ray Player or Other AV Equipment Component video signal/S-video signal connection AUDIO IN Audio cable (not supplied) BNC cable (not supplied) Audio equipment Audio cable (not supplied) • Select the source name for its appropriate input connector after turning on the projector. INPUT button on the projector Input connector Button on the remote control...

  • Page 144: Connecting Component Input

    6. Installation and Connections Connecting Component Input AUDIO IN COMPUTER IN AUDIO IN 15-pin - to - RCA (female) × 3 BNC (male) - to - RCA (male) conversion cable × 3 cable adapter (ADP-CV1E) (sold commercially) Stereo mini plug - to - RCA audio cable (not supplied) Component video RCA ×...

  • Page 145: Connecting Hdmi Input

    6. Installation and Connections Connecting HDMI Input You can connect the HDMI output of your Blu-ray player, hard disk player, or notebook type PC to the HDMI 1 IN or HDMI 2 IN connector of your projector. HDMI 1 IN HDMI 2 IN HDMI cable (not supplied) Use High Speed HDMI...

  • Page 146: Connecting To A Hdbaset Transmission Device (Sold Commercially)

    6. Installation and Connections Connecting to a HDBaseT transmission device (sold commercially) HDBaseT is a connection standard for home appliances that is established by the HDBaseT Alliance. Use a LAN cable sold commercially to connect the Ethernet / HDBaseT port of the projector (RJ-45) to a HDBaseT transmission device sold commercially.

  • Page 147: Portrait Projection (Vertical Orientation)

    6. Installation and Connections Portrait projection (vertical orientation) Portrait screens from a computer can be projected by installing the projec- tor in a vertical orientation. All the screens such as the on-screen menu will be rotated in an counter-clockwise direction. The projector is equipped with a sensor to automatically detect the instal- lation state.
  • Page 148 6. Installation and Connections Reference drawings * The drawing showing the dimensional requirements is not an actual stand design drawing. [Side View] [Front View] [Bottom View] Screw holes for 4 - M4 use 310 or greater Filter cover Tilt foot (remove) Rear foot 130 or greater Filter cover (when opened)
  • Page 149 6. Installation and Connections 3. Slide the securing lever towards the top until it comes to a stop and then turn the screws to the right to tighten them. • Tighten the screws while pressing the securing lever towards the top.

  • Page 150: Connecting To A Wired Lan

    6. Installation and Connections Connecting to a Wired LAN The projector comes standard with a Ethernet/HDBaseT port (RJ-45) which provides a LAN connection using a LAN cable. To use a LAN connection, you are required to set the LAN on the projector menu. Select [SETUP] → [NETWORK SETTINGS] →...

  • Page 151: Maintenance

    7. Maintenance This section describes the simple maintenance procedures you should follow to clean the filters, the lens, the cabinet, and to replace the lamp and the filters. ❶ Cleaning the Filters The air-filter sponge keeps dust and dirt from getting inside the projector and should be frequently cleaned. If the filter is dirty or clogged, your projector may overheat.
  • Page 152 7. Maintenance 2. Remove the filter unit by pulling out the tab. Filter unit 3. Remove the four filters. Hold and remove the filters fitted to the two sides of the filter unit. 4. Use a vacuum cleaner to vacuum all the dust inside. Get rid of dust in the filter.
  • Page 153 7. Maintenance 6. Attach 4 new filters to both sides of the filter unit. Flange The installation locations of the filters are differentiated by whether there are any slits (notches). Install the filter under the flange around the filter unit as follows. Knob (1)Attach the 2 filters with transparent frames fitted to the grips to the side of the filter unit where the knob is located.

  • Page 154: ❷ Cleaning The Lens

    7. Maintenance ❷ Cleaning the Lens • Turn off the projector before cleaning. • The projector has a plastic lens. Use a commercially available plastic lens cleaner. • Do not scratch or mar the lens surface as a plastic lens is easily scratched. •...

  • Page 155: ❹ Replacing The Lamp And The Filters

    Do not touch them as the pieces of glass may cause injury. If this happens, contact your NEC dealer for lamp replacement.
  • Page 156 7. Maintenance To replace the lamp: 1. Remove the lamp cover. (1)Loosen the lamp cover screw • The lamp cover screw is not removable. (2)Pull the bottom of the lamp cover towards you and remove it. 2. Remove the lamp housing. (1)Loosen the two screws securing the lamp housing until the phillips screwdriver goes into a freewheeling condi- tion.
  • Page 157 7. Maintenance 3. Install a new lamp housing. (1)Insert a new lamp housing until the lamp housing is plugged into the socket. (2)Position so that the guide hole in the bottom right of the lamp house is over the protrusion on the projector then press all the way in.
  • Page 158 7. Maintenance To replace the filters: Four filters are packaged with the replacement lamp. Honeycomb filter (coarse mesh): Large and small sizes (attached to the outside of the filter unit) Accordion filter (fine mesh): Large and small sizes (attached to the inside of the filter unit) NOTE: •...
  • Page 159 7. Maintenance 3. Remove the four filters. Hold onto the filters fitted to both sides of the filter unit to remove the filter unit. 4. Remove dust from the filter unit and the filter cover. Clean both outside and inside. 5.

  • Page 160: User Supportware

    Download service For the update information about these software programs, visit our website: URL: http://www.nec-display.com/dl/en/index.html Operating Environment The following is the operating environment for Image Express Utility Lite. For the operating environment of other soft- ware program, refer to the help function of each software program.

  • Page 161: ❷ Installing Software Program

    “Microsoft .NET Framework Version 2.0” is required. The Microsoft .NET Framework Version 2.0, 3.0 or 3.5 is available from Microsoft’s web page. Download and install it on your computer. 1 Insert the accompanying NEC Projector CD-ROM into your CD-ROM drive. The menu window will be displayed.
  • Page 162 8. User Supportware 2 Click a software program you wish to install on the menu window. The installation will start. • Follow the instructions on the installer screens to complete the installation. TIP: Uninstalling a Software Program Preparation: Exit the software program before uninstalling. To uninstall the software program, the Windows user account must have “Administrator”...
  • Page 163 1. Put the “PC Control Utility Pro 5” folder to the Trash icon. 2. Put the configuration file of PC Control Utility Pro 5 to the Trash icon. • The configuration file of PC Control Utility Pro 5 is located in “/Users/<your user name>/Application Data/NEC Projector User Supportware/PC Control Utility Pro 5”.

  • Page 164: ❸ Operating The Projector Via The Lan (Virtual Remote Tool)

    • Logo data (image) sent using the Virtual Remote Tool will be displayed in the center with the surrounding area in black. • To put the default “NEC logo” back in the background logo, you need to register it as the background logo by using the image file (PA622U/NP-PA522U: \Logo\necpj_bbwux.png, PA672W/PA572W: \Logo\necpj_bbwx.png, PA722X/NP-PA622X: \Logo\...

  • Page 165: Connect The Projector To A Lan

    Windows Desktop. Start from the Start menu • Click [Start] → [All Programs] or [Programs] → [NEC Projector User Supportware] → [Virtual Remote Tool] → [Virtual Remote Tool]. When Virtual Remote Tool starts for the first time, “Easy Setup” window will be displayed.
  • Page 166 The Help screen will be displayed. • Displaying the help file using the Start Menu. 1. Click “Start”.“All programs” or “Programs”.“NEC Projector User Supportware”.“Virtual Remote Tool”. and then “Virtual Remote Tool Help” in this order. The Help screen will be displayed.

  • Page 167: ❹ Controlling The Projector Over A Lan (Pc Control Utility Pro 4/Pro 5)

    ❹ Controlling the Projector over a LAN (PC Control Utility Pro 4/ Pro 5) Using the utility software “PC Control Utility Pro 4” or “PC Control Utility Pro 5” included on the companion NEC Pro- jector CD-ROM, the projector can be controlled from a computer over a LAN.
  • Page 168 8. User Supportware TIP: If the menu window will not be displayed, try the following procedure. For Windows 7: 1. Click “start” on Windows. 2. Click “All Programs” → “Accessories” → “Run”. 3. Type your CD-ROM drive name (example: “Q:\”) and “LAUNCHER.EXE” in “Name”. (example: Q:\ LAUNCHER.EXE) 4.
  • Page 169 Controlling the Projector by Using an HTTP Browser” (→ page 42) Step 3: Start PC Control Utility Pro 4 Click “Start” → “All programs” or “Programs” → “NEC Projector User Supportware” → “PC Control Utility Pro 4” → “PC Control Utility Pro 4”.
  • Page 170 Using on Mac OS Step 1: Install PC Control Utility Pro 5 on the computer 1. Insert the accompanying NEC Projector CD-ROM in your Mac CD-ROM drive. The CD-ROM icon will be displayed on the desktop. 2. Double-click the CD-ROM icon.

  • Page 171: Appendix

    9. Appendix ❶ Throw distance and screen size Six separate bayonet style lenses can be used on this projector. Refer to the information on this page and use a lens suited for the installation environment (screen size and throw distance). For instructions on mounting the lens, see page 123.
  • Page 172 * Figures differ by several % with the table above because the calculation is approximate. Ex.: Throw distance when projecting on a 150" screen with the PA622U/PA522U using the NP13ZL lens: According to the “Screen Size (for reference)” table (→ page 161), H (screen width) = 323.1 cm.
  • Page 173 9. Appendix Projection range for the different lenses NP11FL NP-PA622U/NP-PA522U: 0.7–2.6 m NP-PA672W/NP-PA572W: 0.7–2.6 m NP-PA722X/NP-PA622X: 0.6–2.5 m NP30ZL NP-PA622U/NP-PA522U: 1.0–11.3 m NP-PA672W/NP-PA572W: 1.0–11.3 m NP-PA722X/NP-PA622X: 1.0–10.9 m NP-PA622U/NP-PA522U: 1.0–11.3 m NP12ZL NP-PA672W/NP-PA572W: 1.0–11.3 m NP-PA722X/NP-PA622X: 1.0–10.9 m 40-150" 60-500"...

  • Page 174: Tables Of Screen Sizes And Dimensions

    152.4 243.8 182.9 304.8 228.6 Screen width 406.4 304.8 487.7 365.8 609.6 457.2 812.8 609.6 1016.0 762.0 PA622U/PA522U/PA672W/PA572W Size (inches) Screen width Screen height (inches) (cm) (inches) (cm) 25.4 64.6 15.9 40.4 Screen 16:10 screen size (di- 33.9 86.2 21.2 53.8...

  • Page 175: Lens Shifting Range

    9. Appendix Lens shifting range This projector is equipped with a lens shift function for adjusting the position of the projected image by turning the lens shift dials. The lens can be shifted within the range shown below. NOTE: • The lens shift function cannot be used when using the NP11FL lens. •...
  • Page 176 30% H 30% H ④ * For PA622U/PA522U, the shift range in the horizontal direction is up to 15% H when using the lens unit “NP13ZL” to project a screen exceeding Model 150. Ex.: When projecting on a 150" screen The explanation is for a PA722X/PA622X projector (4:3 panel) with a NP12ZL lens fitted.

  • Page 177: ❷ Compatible Input Signal List

    9. Appendix ❷ Compatible Input Signal List Analog Computer Signal Signal Resolution ( dots ) Aspect Ratio Refresh Rate ( Hz ) 640 × 480 4 : 3 60/72/75/85/iMac SVGA 800 × 600 4 : 3 56/60/72/75/85/iMac 1024 × 768 4 : 3 60/70/75/85/iMac XGA+...
  • Page 178 9. Appendix HDMI Signal Resolution ( dots ) Aspect Ratio Refresh Rate ( Hz ) 640 × 480 4 : 3 SVGA 800 × 600 4 : 3 1024 × 768 4 : 3 1280 × 720 16 : 9 1280 ×...
  • Page 179 *1 Native resolution on XGA model (PA722X/PA622X) *2 Native resolution on WXGA model (PA672W/PA572W) *3 Native resolution on WUXGA model (PA622U/PA522U) *4 Approximate Value *5 The projector may fail to display these signals correctly when [AUTO] is selected for [ASPECT RATIO] in the on-screen menu.

  • Page 180: ❸ Specifications

    Optical device Optical isolation by dichroic mirror, combining by dichroic prism Light output ECO OFF PA722X : 7200 lm, PA622X: 6200 lm, PA672W: 6700 lm, PA572W: 5700 lm, PA622U: (*2) (*3) 6200 lm, PA522U: 5200 lm Contrast ratio (all white/all black)
  • Page 181 Audio: LPCM; up to 2 ch, sample rate 32/44.1/48 KHz, sample bit; 16/20/24-bit *6 35 to 40ºC – “Forced eco mode” (PA622U/PA522U will shift to the eco-mode in stages starting from 33 °C.) • These specifications and the product’s design are subject to change without notice.

  • Page 182: ❹ Cabinet Dimensions

    9. Appendix ❹ Cabinet Dimensions Unit: mm (inch) 499 (19.6) Lens center Lens center 250 (9.8) Holes for ceiling mount...

  • Page 183: ❺ Mounting The Cable Cover (Sold Separately)

    9. Appendix ❺ Mounting the cable cover (sold separately) Mounting the separately sold cable cover (NP04CV) on the projector allows you hide the cables for a cleaner appearance. CAUTION • After mounting the cable cover, be sure to fasten using the screws provided. If not, the cable cover could fall, damaging the cable cover and possibly resulting in injury.

  • Page 184: ❻ Pin Assignments And Signal Names Of Main Connectors

    9. Appendix ❻ Pin assignments and signal names of main connectors COMPUTER IN/ Component Input Connector (Mini D-Sub 15 Pin) Connection and signal level of each pin Pin No. RGB Signal (Analog) YCbCr Signal 11 12 13 14 15 Green or Sync on Green Blue Ground Signal Level...
  • Page 185 9. Appendix Ethernet/HDBase T Port (RJ-45) Pin No. Signal TxD+/HDBT0+ 1 2 3 4 5 6 7 8 TxD−/HDBT0− RxD+/HDBT1+ Disconnection/HDBT2+ Disconnection/HDBT2− RxD−/HDBT1− Disconnection/HDBT3+ Disconnection/HDBT3− USB-A Port (Type A) Pin No. Signal D− Grounding PC CONTROL Port (D-Sub 9 Pin) Pin No.

  • Page 186: ❼ Troubleshooting

    The lamp cover is not properly mounted. Mount it properly. (→ of 1) Page 144) Red (cycles Fan problem The cooling fan has stopped turning. Contact an NEC projector of 4) customer support center for repairs. Flashing Orange Network conflict It is not possible to connect the projector’s built-in LAN and...

  • Page 187: Lamp Indicator

    Flashing Red (cycles of 2) Temperature problem The temperature protector has been activated. If the room temperature is high, move the projector to a cool place. If the problem still persists, contact an NEC projec- tor customer support center. Orange High surrounding temperature The surrounding temperature is high.

  • Page 188: Troubleshooting

    9. Appendix Common Problems & Solutions (→ “Power/Status/Lamp Indicator” on page 174.) Problem Check These Items Does not turn on • Check that the power cord is plugged in and that the power button on the projector cabinet or the remote control or shut down is on�...
  • Page 189 9. Appendix Problem Check These Items Remote control does • Install new batteries. (→ page 10) not work • Make sure there are no obstacles between you and the projector. • Stand within 22 feet (7 m) of the projector. (→ page 11) •...

  • Page 190: If There Is No Picture, Or The Picture Is Not Displayed Correctly

    “Fn” key along with one of the 12 function keys gets the external display to come on or off. For example, NEC laptops use Fn + F3, while Dell laptops use Fn + F8 key combinations to toggle through external display selections.

  • Page 191: ❽ Pc Control Codes And Cable Connection

    9. Appendix ❽ PC Control Codes and Cable Connection PC Control Codes Function Code Data POWER ON POWER OFF INPUT SELECT HDMI1 INPUT SELECT HDMI2 INPUT SELECT DisplayPort INPUT SELECT BNC INPUT SELECT BNC(CV) INPUT SELECT BNC(Y/C) INPUT SELECT COMPUTER INPUT SELECT HDBaseT PICTURE MUTE ON PICTURE MUTE OFF...

  • Page 192: ❾ Troubleshooting Check List

    9. Appendix ❾ Troubleshooting Check List Before contacting your dealer or service personnel, check the following list to be sure repairs are needed also by referring to the “Troubleshooting” section in your user’s manual. This checklist below will help us solve your problem more efficiently.
  • Page 193 Video adapter: Other: Projector Video equipment Blu-ray player VCR, Blu-ray player, Video camera, Video game or other Manufacturer: Signal cable Model number: NEC standard or other manufacturer’s cable? Model number: Length: inch/m Distribution amplifier Model number: Switcher Model number: Adapter...
  • Page 194 © NEC Display Solutions, Ltd. 2014 7N951971...

This manual is also suitable for:

Pa522uPa672wPa722xPa622xPa572w

Table of Contents
