Ihr Smartlab ® Mini; Display & Functions; Specifications - HMM Diagnostics smart LAB mini User Manual

II. Ihr smartLAB
Display & functions
Test result
M e a s u r i n g
unit

Specifications

1. Type: smartLAB
2. Measuring range: 20 ~ 630 mg/dL
(1.1 ~ 35.0 mmol/L)
3. Measuring duration: 5 seconds
4. Memory: 20 values
5. Operating temperature: 10°C ~ 40°C
(50°F ~ 104°F)
6. Relative humidity: RH ≤90%
7. Blood sample: ≥ 0,6 µL capillary
whole blood
8. Calibration: Plasma equivalent
mini
®
Apply
blood or con-
Battery power
trol solution to
the test strip
mini
®
Error code
Code number
Thermometer
9. Hematocrit (Hct): 30-55%
10. Battery type: 2 CR 3V Lithium bat-
teries
11. Battery life: over 3000 measurements
12. Display-size: 30 x 30 mm
13. Meter dimensions: 80 x 50 x 5 mm
14. Weight: 22g (without batteries)
9
