- Page 1 SAFETY AND OPERATING MANUAL COMPOUND MITRE SAW BM210J...
- Page 3 This guarantee does not affect your statutory rights.This guarantee is only valid in the UK. For further technical advice, spare parts or repair service (outside of guarantee) please contact the customer helpline number on 0845 607 6380. COMPOUND MITRE SAW BM210J...
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS WARNING! Read all instructions.Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVETHESE INSTRUCTIONS 1. Keep the work area clean. Cluttered areas and benches invite injuries. 2. Consider work area environment. Do not expose power tools to rain. - Page 5 22. Have your tools repaired by qualified person. This electrical tool is in accordance with the relevant safety requirements. Repairs should only be carried out by qualified persons using original spare parts, otherwise this may result in considerable danger to the user. COMPOUND MITRE SAW BM210J...
- Page 6 ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR MITRE 1.If the supply cord is damaged have it replaced by a qualified person. 2. Only wood or products such as medium density fibre board can be cut with this saw. Other materials may shatter or cause the blade to grab. 3.
- Page 7 Remove the main plug from socket before carrying out any adjustment or servicing. Ensure your mains supply voltage is the same as your tool rating plate voltage. SYMBOLS Read the manual Warning Wear gloves Wear dust mask,eye & ear protection COMPOUND MITRE SAW BM210J...
- Page 8 1 SAFETY RELEASE LEVER 2 HANDLE 3 TRIGGER 4 MOTOR 5 SAWBLADE 6 RETRACTABLE SAFETY GUARD 7 FENCE 8 ROTARY TABLE 9 BASE PLATE 10 LOCKING SCREWS FOR STRAIGHT GUIDE 11 ROTARY TABLE SLOT 12 ROTARY TABLE ANGLE SCALE 13 HEAD TILT CLAMPING KNOB 14 RETRACTABLE SAFETY GUARD ACTUATOR 15 BLADE COVER 16 LOCK PIN...
-
Page 9: Technical Data
This saw comes with a 24 Teeth Tungsten Carbide Tipped Blade. Saw blades are available with differing number of teeth so choose according to the quality of cut required eg more teeth for finer cut.Always use blades with the dimensions shown above. ACCESSORIES Spanner: Dust Bag: Allen Key: COMPOUND MITRE SAW BM210J... -
Page 10: Operation Instructions
OPERATION INSTRUCTIONS 1.FIT ADDITIONAL SUPPORT FEET In order to further stabilize the unit and prevent excess movement should the head be released accidentally you MUST fit the additional support feet to the rear of the base plate as follows: Turn the unit around so you are facing the back of the saw.The feet mount on either side of the base plate.Locate and secure the feet using the two screws provided.Check and confirm they are... - Page 11 (B, not supplied), to check the 45 angle, then adjust the set screw (19) to set the correct stop position, then tighten the lock screw (20). Refer Fig11 and Fig7 . Fig 9 COMPOUND MITRE SAW BM210J...
-
Page 12: Maintenance
DUST EXTRACTION PORT To reduce build up of saw dust and maintain top efficiency of cutting, the saw may be connected to a workshop vacuum cleaner via the dust extraction port (18). The port accepts 32mm diameter vacuum hose. Alternatively saw dust collection can be achieved by clipping a dust bag on the dust extraction port.To ensure optimal dust collecting, empty the dust bag when it becomes... -
Page 13: Environmental Protection
L. A 13AMP (BS1363 or BS1363/A) plug must be used and a 13 AMP fuse must be fitted. Fig 16 13 AMP FUSE BLUE N (NEUTRAL) BROWN L (LIVE) OUTER CABLE GRIP SLEEVE COMPOUND MITRE SAW BM210J... -
Page 14: Declaration Of Conformity
Houndstone Business Park Yeovil BA 22 8RT Declare that the product MITRE SAW BM210J Complies with the essential health and safety requirements of the following directives: 89/336 EEC, 93/68 EEC.–EMC Directive. 73/23 EEC, 93/68 EEC.–Low Voltage Directive 98/37 EC.–Machinery Directive. - Page 15 COMPOUND MITRE SAW BM210J...
