Chapter 6
Page 26
6.2 Sound
Allows user to shut off non-safety related operating sounds.
6.3 Mowing
Allows user to turn blade operation off, preventing blade operation during automatic operation and
manual mowing.
6.4 Language
Allows the user the option of viewing the LCD text in several different language versions.
6.5 Work Time
Allows the user the option of setting the operating time from the 'MAX' default setting to times
ranging from 20 minutes up to 2 hours. Figure 6.5 This option is available for up to 4 different zones,
A, B, C or D. Having four different zones can allow you to set operating time for several different
zones that are of varying sizes, not requiring the same operating time for mowing.
Zone A
Zone A
GO to Confirm
6.6 Wide Scan
Wide scan provides the Robomower a secondary navigation technique which can prove to be
beneficial in some lawns. Wide scan will increase the distance between subsequent legs of mowing
after each movement off of the perimeter wire. If it appears that the Robomower is simply driving
along the same path back and forth, activate wide scan.
6.7 Learn Edge
This menu option can only be seen when the Manual Controller is in the pocket and flush with the
mower top. 'Learn Edge' gives you the ability to have the Robomower learn the distance around
the. Figure 6.6
•
Position the Robomower to start edge mowing and place the Manual Controller in the pocket
•
Follow the steps described in Figure 6.6 to begin the process
•
'Learn Edge' is specific to each zone, so be sure you have selected the correct zone where
you want the edge learned
MAX
Press GO
MAX
Scroll to select
different zones.
Scroll to select different operating
times. Times range from: None =
(zero time) to 2 hours to 'MAX'
Figure 6.5
