Copyright 2003 Carrier Corporation
Product
Data
Induced-Combustion Gas Furnace
Weathe rMaker
800 0
WeatherMaker
Deluxe 4-Way Multipoise
THE CARRIER 58DLA/DLX
GAS FURNACE
The 58DLA/DLX 4-way Multipoise Gas Furnaces
offer deluxe features not found in other single-stage
80% gas furnaces. Carrier's QuieTech™ noise reduc-
tion system makes the WeatherMaker 8000 an incredi-
bly quiet induced draft gas furnace. The exclusive
Carrier Media Cabinet provides an economic way to
add high performance air filtration to homes. The
WeatherMaker 8000 control system provides a dehu-
midification mode, a third motor speed selection for
continuous fan operation selectable at the thermostat,
and fault code storage in the event of power outages.
Applications are easy with 4-way multipoise design,
through-the-furnace downflow venting, 13 different
venting options, and a door designed for easy service
access. An inner blower door is provided for tighter
sealing in sensitive applications. The 58DLA/DLX fur-
naces are approved for use with natural or propane gas,
and the 58DLX is approved for use in Low NOx Air
Quality Management Districts.
STANDARD FEATURES
– QuieTech noise reduction system
– Media Filter Cabinet Included
– Microprocessor based control center
Dehumidification selection for summer-time cooling
Adjustiable heating air temperature rise
Adjustable cooling airflow
Comfort Fan ™–Constant fan speed selectable from
thermostat
LED diagnostics and self test feature
Stores fault codes during power outages
– 4-way Multipoise furnace, 13 vent applications
– Only 33-1/3 tall
– Inner blower door
– Hot surface ignition (HSI)
– Draft safeguard switch to ensure proper furnace
venting
– Insulated blower compartment
– Heat pump compatible
– Residential installations eligible for consumer
financing through the Retail Credit Program
LIMITED WARRANTY
– 20-year warranty on "Super S™" heat exchanger
A02179
– 5-year parts warranty on all other components
58DLA/DLX
®
8000
Input Capacities:
45,000 thru 155,000 Btuh
Form 58DL-3PD
Advertisement
Table of Contents
Related Manuals for Carrier 58DLA
Summary of Contents for Carrier 58DLA
- Page 1 80% gas furnaces. Carrier’s QuieTech™ noise reduc- tion system makes the WeatherMaker 8000 an incredi- bly quiet induced draft gas furnace. The exclusive Carrier Media Cabinet provides an economic way to add high performance air filtration to homes. The WeatherMaker 8000 control system provides a dehu- midification mode, a third motor speed selection for...
-
Page 2: Model Number Nomenclature
Model number nomenclature 58DLA Nominal Cooling Size (Airflow at .5 e.s.p.) (400 CFM per 12,000 Btuh) 58DLA Deluxe 4-Way Multipoise 08 — 800 CFM 58DLX Low NOx version 12 — 1200 CFM 14 — 1400 CFM 16 — 1600 CFM 20 —... -
Page 3: Furnace Components
*Elbow may be turned to a different position, depending on type of installation NOTE: The 58DLA/DLX Furnaces are factory shipped for use with natural gas. These furnaces can be field-converted for propane gas with a factory-authorized and listed accessory conversion kit. - Page 4 AIR CLEANER By adding moisture to winter-dry ture level in the home. air, a Carrier humidifier can often Cleans the air of smoke, dirt, and For the ultimate in home comfort, improve comfort and keep many pollens commonly found.
- Page 5 Carrier Accessories* DESCRIPTION PART NO. 045- 045- 070- 070- 070- 090- 090- 090- 110- 110- 110- 135- 135- 155- EZ Flex Media Filter with end EXPXXUNV0016 caps – 16 in. (9 pack) EZ Flex Media Filter with end EXPXXUNV0020 caps – 20 in. (9 pack)
-
Page 6: Physical Data
‡ Airflow shown is for bottom only return-air supply. For air delivery above 1800 CFM, see Air Delivery Table for other options. A filter is required for each return-air supply. An airflow reduction of up to 7% may occur when using a Carrier 4-5/15 high efficiency media filter. - Page 7 ‡ Airflow shown is for bottom only return-air supply. For air delivery above 1800 CFM, see Air Delivery Table for other options. A filter is required for each return-air supply. An airflow reduction of up to 7% may occur when using a Carrier 4-5/15 high efficiency media filter.
- Page 8 SEE NOTES: 1,2,4,5,7,8,9 SEE NOTES: 1,2,3,4,7,8,9 SEE NOTES: 1,2,4,7,8,9 UPFLOW DOWNFLOW UPFLOW A02058 A02061 A02059 SEE NOTES:1,2,3,4,5,7,8,9 SEE NOTES: 1,2,4,5,6,7,8,9 SEE NOTES: 1,2,3,4,5,7,8,9 DOWNFLOW DOWNFLOW DOWNFLOW A02063 A02062 A02060 Venting Notes 1. For common vent, vent connector sizing and vent material: United States, latest edition of the National Fuel Gas Code (NFGC), ANSI Z223.1/NFPA 54.
- Page 9 SEE NOTES: 1,2,4,5,7,8,9 SEE NOTES: 1,2,4,5,7,8,9 HORIZONTAL RIGHT HORIZONTAL RIGHT A02070 A02068 SEE NOTES: 1,2,4,7,8,9 HORIZONTAL RIGHT A02069 SEE NOTES: 1,2,4,7,8,9 SEE NOTES: 1,2,4,5,7,8,9 HORIZONTAL LEFT HORIZONTAL LEFT A02065 A02064 SEE NOTES: 1,2,4,5,7,8,9 SEE NOTES: 1,2,4,5,7,8,9 HORIZONTAL LEFT HORIZONTAL LEFT A02067 A02066...
- Page 10 AIR DELIVERY—CFM (With Filter) * EXTERNAL STATIC PRESSURE (In. wc) RETURN-AIR UNIT SIZE SUPPLY SPEED Bottom High 1085 1035 045-08 Med-High — 1 Side(s) Med-Low — Bottom High 1450 1375 1305 1225 1145 1050 Med-High 1360 1300 1240 1175 1115 1040 045-12 1 Side(s)
- Page 11 AIR DELIVERY—CFM (With Filter) * (Continued) EXTERNAL STATIC PRESSURE (In. wc) RETURN-AIR UNIT SIZE SUPPLY SPEED High 2530 2470 2400 2320 2220 2115 2000 1865 1730 1590 Bottom Med-High 2230 2205 2165 2110 2035 1950 1855 1740 1615 1485 Only Med-Low 1920 1900...
- Page 12 The use of both side inlets, a combination of 1 side and the bottom, or the bottom only will ensure adequate return air openings for airflow requirements above 1800 CFM. VENT CONNECTION APPROXIMATE 58DLA/DLX (CABINET (SUPPLY (BOTTOM (TOP VENT...
-
Page 13: Installation
INSTALLATION MINIMUM INCHES CLEARANCE TO COMBUSTIBLE CONSTRUCTION DISTANCE MINIMALE EN POUCES AUX CONSTRUCTIONS COMBUSTIBLES This forced air furnace is equipped for use with This furnace is approved for UPFLOW, DOWNFLOW, and HORIZONTAL installations. natural gas at altitudes 0-10,000 ft (0-3,050m). accessory kit, supplied... -
Page 14: Typical Wiring Schematic
Typical wiring schematic FIELD 24-V WIRING FIELD 115-, 208/230-, 460-V WIRING FACTORY 24-V WIRING FACTORY 115-V WIRING NOTE 2 THERMOSTAT FIVE WIRE FIELD-SUPPLIED TERMINALS DISCONNECT THREE-WIRE HEATING-ONLY 208/230- OR BLOWER DOOR SWITCH 460-V THREE PHASE 208/230-V SINGLE PHASE AUXILIARY 115-V FIELD- J-BOX SUPPLIED NOTE 1... - Page 15 CONDENSING UNIT HUMIDIFIER GAS-FIRED WATER HEATER ELECTRONIC AIR CLEANER AIRFLOW A02184...
- Page 16 • Carrier Corporation Indianapolis, IN 46231 4-03 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations Book Page 16 Catalog No. 525-80036 Printed in U.S.A. PC 101 Form 58DL-3PD...
