DN-13007 / DN-13008 / DN-13018
USB 2.0 Hi-Speed MFP Server
Quick Installation Guide
① . Introduction
This document describes the steps for installing and configuring
Digitus DN-13007/DN-13008/DN-13018 USB 2.0 MFP server as a
Print/File/Scan server in the Windows environment. Digitus
DN-13007/DN-13008 uses LAN (standard Ethernet) to access network,
while Digitus DN-13018 uses LAN or wireless module (802.11b/g) to
access network. The following table shows the differences among
DN-13007, DN-13008, and DN-13018.
Model
DN-13008
DN-13007
DN-13018
Except for the wireless configuration, most configuration and
operations are the same for DN-13007/DN-13008 and DN-13018.
Similarly, almost all of the configuration and operations are the same
for DN-13007 and DN-13008 except that only one USB device can be
connected to DN-13008 while at most two USB devices can be
connected to DN-13007. Please refer to the User's Manual in the
bundled CD-ROM for more details.
-
This Setup Guide is only for Windows users.
-
If you use the MFP server in Unix/Linux, please refer to the User's
Manual in the bundled CD-ROM for more details.
Digitus
LAN
Wireless
Yes
No
Yes
No
Yes
Yes
1
USB Port(s)
1
2
2
Advertisement
Related Manuals for Digitus DN-13007
Summary of Contents for Digitus DN-13007
-
Page 1: Quick Installation Guide
DN-13007/DN-13008 and DN-13018. Similarly, almost all of the configuration and operations are the same for DN-13007 and DN-13008 except that only one USB device can be connected to DN-13008 while at most two USB devices can be connected to DN-13007. -
Page 2: Physical Description
② . Package Contents If any item is missing, please contact the shop where you bought this product. One Digitus DN-13007 or DN-13008 or DN-13018 USB 2.0 MFP Server (x1) One MFP Control Center Software CD (x1) One DC IN 12V/1A Power Adaptor (x1) ③... - Page 3 III. Plug in the power adaptor (included in this package) to power on the MFP server. ⑥ . Connect Digitus DN-13018 to Your Wireless Network Just skip this step if you are using DN-13007 or DN-13008. Follow Step 5. II. Properly set up wireless configuration as Step 8.
- Page 4 Password (default: admin). Figure 2 Control Center 3. Name your Digitus MFP server and select a codepage for file server function as Fig3. Please enter the server name and the workgroup name for Windows networking by SMB protocol. The default server name is the model name (DN-13007 or DN-13008 or DN-13018) and the workgroup name is “ARBEITSGRUPPE”.
- Page 5 Figure 3 Set Server Name and Codepage 5. Set up wireless configuration (only for DN-13018): Select the Network Type: Ad-Hoc mode - no Access Point is used or Infrastructure mode (Default) - all Wireless stations connect to the Access Point. Set SSID, Channel, and Security according to the table below...
- Page 6 Ad-hoc Mode Infrastructure Mode SSID The Server will join any group with Must match the Access the same SSID. Point. If there is no Ad-Hoc group available, the Server will create the group using the SSID assigned to it. Channel The Server will join any group with Access Point sets the the same Channel number.
- Page 7 5. Double click the Workgroup that MFP server belongs to. The default Workgroup name is “WORKGROUP”. You can refer to Digitus MFP Control Center or server’s web pages to get it. You will see that the MFP server will be displayed as the default server name or the server name that you set.
- Page 8 “NetUSB” technology allows you to use USB printers or USB MFPs and USB storage devices as if they were connected directly to your PC although they are actually connected to the Digitus MFP server. The “connect” operation is a software operation that simulates an actual USB device plug-in.
- Page 9 Note : NetUSB is only available in Windows 2000/XP/2003. Windows 98/ME is not supported. I. NetUSB Printing After the driver is installed , you can see a newly created printer in the Control Panel’s “Printers and Faxes”. Follow the steps below to do a NetUSB printing.
- Page 10 D. Choose the desired printer. The desired printer must be the Windows printer (this is a logical printer) that matches the printer attached on the MFP server (this is a physical printer). Then click the “Apply” button. Then, the printer will be marked as an “Auto-Connected Printer”...
- Page 11 D. Choose one of TWAIN or WIA item. Click “OK”. The following window will appear. Follow the usual steps to do scanning. III. Accessing USB Storage using NetUSB Technology Before you use NetUSB technology to access USB storage, please make sure the storage access mode is in NetUSB mode. A.
-
Page 12: Default Parameters
C. Click the “Connect” button to manually connect the USB storage device. D. Now your PC will have a new disk. For example, if you connect a flash drive, your PC will have a new “removable disk”. You can see the storage icon in the system tray, as the following figure. - Page 13 Some of the important default parameters are shown below. Administrator: admin Password: admin Server Name: DN-13007 (for DN-13007) or DN-13008 (for DN-13008) or DN-13018 (for DN-13018) Workgroup: ARBEITSGRUPPE Static IP: 192.168.1.100 DHCP: enabled...
