- Page 1 NOTEBOOK DOCKING STATION (DC DOCK5) (DC DOCK6) User’ s Manual...
- Page 2 E. OPERATIONAL NOTES ABOUT THE PORTS ON THE DOCKING STATION A. INTRODUCTION This USB 2.0 Docking Station (DC DOCK5 / DC DOCK6) is a unique expansion unit specially designed to accompany notebook or desktop PC which has extra connectivity demands. With only one USB port required form a notebook/desktop PC, not only USB but also conventional SIO, LAN, PS/2, e SATA, Smart Card reader ,Audio, USB 2.0 HUB and 53 in 1 Card reader peripheral devices can be accessed freely.
- Page 3 OS of Microsoft. Also the hub driver is from the OS. The rest peripherals ‘ drivers are provided within the accompanied CD-ROM. *2.USB Audio port cannot function under Windows® 98se/ME due to the incompatibility issue of driver. Specifications Model DC DOCK6 DC DOCK5 RS-232 Memory Card 53 in 1 Reader Smart Card Reader USB 2.0 HUB...
-
Page 4: Software Installation
DC Output 5V, 2.0A C. HARDWARE APPEARANCE and CONNECTION LED Status Indicators Please refer to Figures 1 and 2 for the LED functional indicators and layout of ports of DC DOCK5 / DC DOCK6 docking station. Model LED Color Descriptions DC DOCK5 / Turned on when the docking station is powered. - Page 5 Please make sure the driver CD-ROM is placed in the CD-ROM drive before proceed. Software Installation in Windows® ® For Windows XP, there are two drivers which need to install from the driver ® CD-ROM: (1). USB-LAN, (2) USB-serial port, The drivers of rest devices are provided by Windows XP and will be installed without user’...
- Page 6 3. Click Finish to end the wizard for driver of USB Smart Card reader.
- Page 7 USB-Serial Driver installation, computer systems based on tips completed. Choose” install from a list or specific location (Advanced)” Click Next to continue...
- Page 8 Click “ Browse” Choose the driver location.
- Page 9 Click next Click “ Finish” to close the wizard...
- Page 10 USB-LAN Driver installation, computer systems based on tips completed.
- Page 11 Choose “ Install from a list or specific location (Advanced)” Click next to continue Click “ Browse” Choose the driver location.
- Page 12 Click next to continue Click Finish to close the wizard...
- Page 13 Upon the completion of the installation of these three procedures, restart the computer in the “ Device Manager” will see the following devices.
- Page 14 The end. Thank you for using the product.
