INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
CERTIFIED UNDER U.S. ENVIRONMENTAL PROTECTION AGENCY (E.P.A.) JULY 1990 40 C.F. R. PART 60 AND THE OREGON DEPARTMENT OF
ENVIRONMENTAL QUALITY (D.E.Q.) PARTICULATE EMISSION STANDARDS BY E.E.M.C THESE APPLIANCES HAVE BEEN TESTED AND LISTED BY OMNI
EPI22
WOOD INSERT
SAFETY INFORMATION
WARNING
!
If the information in these instructions is not followed exactly,
a fi re or explosion may result causing property damage,
personal injury or death. Improper installation, adjustment,
alteration, service or maintenance can cause injury or property
damage, bodily injury or even death. Please read entire
manual before you install and use your appliance.
- This appliance can be very hot when burning.
- Combustible materials such as fi rewood, wet clothing, etc. placed too
close can catch fi re.
- Children and pets must be kept from touching the appliance when it
is hot.
- The chimney must be sound and free of cracks. Before installing
this unit, contact the local building or fi re authority and follow their
guidelines.
- Operate only with the door tightly closed.
- Burn wood behind the log retainer directly on the fi rebricks.
- Do not use an elevated grate or otherwise raise the fi re.
- At least 14 square inches of outside air must be admitted to the room
or directly to the unit through a 4" diameter pipe.
- This appliance is designed to burn natural wood only. Higher
effi ciencies and lower emissions generally result when burning air
dried seasoned hardwoods, as compared to softwoods or to green or
freshly cut hardwoods.
- Do not start a fi re with chemicals or fl uids such as gasoline, engine
oil, etc.
- Do not burn treated wood, coal, charcoal, coloured paper, cardboard,
solvents or garbage.
- Do not let the appliance become hot enough for any part to glow red.
- KEEP THE STOVE TOP TEMPERATURE BELOW 700°F (371°C).
Attempts to achieve heat output rates that exceed design
specifi cations can result in steel distortion and damage.
Phone (705)721-1212 • Fax (705)722-6031 • www.timberwolffi replaces.com • ask@timberwolffi replaces.com
$10.00
OPERATING INSTRUCTIONS
TESTING SERVICES TO STANDARDS: ULC-S628, UL1482.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
INSTALLATION AND
WARNING
!
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
1.14B
W415-1036 / 07.19.11
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Timberwolf EPI22
Summary of Contents for Timberwolf EPI22
-
Page 1: Safety Information
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Phone (705)721-1212 • Fax (705)722-6031 • www.timberwolffi replaces.com • ask@timberwolffi replaces.com $10.00 1.14B... -
Page 2: Table Of Contents
TABLE OF CONTENTS INSTALLATION OVERVIEW INTRODUCTION DIMENSIONS (COMPLETE WITH FLASHING) SPECIFICATIONS GENERAL INSTRUCTIONS GENERAL INFORMATION E.P.A. COMPLIANCE RATING PLATE LOCATION PRE-INSTALLATION PREPARATION MINIMUM CLEARANCE TO COMBUSTIBLES INSTALLATION TYPICAL EXISTING MASONRY FACTORY BUILT FIREPLACE FINISHING SECONDARY AIR TUBES DOOR INSTALLATION DOOR HANDLE INSTALLATION BRICKS AND BAFFLES INSTALLATION FLASHING INSTALLATION BLOWER INSTALLATION... -
Page 3: Installation Overview
1.0 INSTALLATION OVERVIEW Flashing, see “FLASHING INSTALLATION” section. Door, see “DOOR AND HANDLE INSTALLATION” section. Draft, see “AIR CONTROL” section. Rating plate, see “RATING PLATE INFORMATION” section. Blower, see “BLOWER INSTALLATION” section. W415-1036 / 07.19.11... -
Page 4: Introduction
2.0 INTRODUCTION WARNING • THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED. • ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS AND IS PROHIBITED. • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fi... -
Page 5: Dimensions (Complete With Flashing)
DIMENSIONS (COMPLETE WITH FLASHING) * A and B are adjustable in 3/8” increments (see min max below). SPECIFICATIONS Specifi cations EPI22 CHAMBER (D.W.H) 14 5/8” x 20 7/8” x 11 5/8” CAPACITY 1.9 ft APPROX. AREA HEATED** 800-1800 ft HEAT OUTPUT (HIGH BURN) ***... -
Page 6: General Information
Your appliance is the exact duplication of the clean-burning technology found in all Timberwolf® EPA certifi ed free- standing stoves. External modifi cations have been made to allow its installation as a “functional insert” with a heat circulating blower system and a means of enclosing the solid fuel burning fi... -
Page 7: Compliance
Expansion / contraction noises during heating up and cooling down cycles are normal and to be expected. After extended periods of non-operation such as following a vacation or a warm weather season, the appliance may emit a slight odour for a few hours. This is caused by dust particles on the fi rebox burning off. Open a window to suffi... -
Page 8: Rating Plate Location
RATING PLATE LOCATION LISTED SOLID FUEL BURNING FIREPLACE INSERT For rating plate location, see “INSTALLATION ENCASTRÉ À COMBUSTIBLE SOLIDE HOMOLOGUÉ OVERVIEW” section. TESTED TO: / TESTÉ SELON : UL1482 / ULC S628 MODEL / MODÈLE: 2201 REPORT NO. 415-S-08-2 INSTALL AND USE ONLY IN ACCORDANCE WITH THE POUR INSTALLATION ET UTILISATION CONFORM ÉMENT MANUFACTURER’S INSTRUCTIONS AND LOCAL BUILDING CODES. -
Page 9: Pre-Installation Preparation
3.0 PRE-INSTALLATION PREPARATION Clean all ashes out of the inside of the existing fi replace opening. Make sure that the chimney and fi replace are free of cracks, loose mortar, creosote deposits, blockage or other signs of deterioration. If necessary, have any repair work done by a qualifi... -
Page 10: Installation
4.0 INSTALLATION WARNING WEAR GLOVES AND SAFETY GLASSES FOR PROTECTION. CAREFULLY FOLLOW THE INSTRUCTIONS FOR ASSEMBLY OF THE PIPE AND OTHER PARTS NEEDED TO INSTALL THE APPLIANCE. FAILURE TO DO SO MAY RESULT IN A FIRE, ESPECIALLY IF COMBUSTIBLES ARE TOO CLOSE TO THE APPLIANCE OR CHIMNEY AND AIR SPACES ARE BLOCKED, PREVENTING THE FREE MOVEMENT OF COOLING AIR. -
Page 11: Typical Existing Masonry
TYPICAL EXISTING MASONRY You can install your appliance using your existing masonry chimney. To do FOLLOW MANUFACTURER’S so, follow the guidelines below. If you are using a masonry chimney, it INSTRUCTIONS FOR is important that it be built in compliance with the specifi cations of the MAXIMUM LINER EXTENSION Building Code in your region. -
Page 12: Factory Built Fireplace
FACTORY BUILT FIREPLACE The following installation requirements must be observed when installing solid fuel burning inserts into factory built fi replaces. The factory built fi replace must be listed per UL 127 or ULC S610. Clearances to any combustible material surrounding this insert as identifi ed must be followed. These clearance requirements supersede any pre-existing facing material clearances listed for the factory built fi... -
Page 13: Finishing
5.0 FINISHING SECONDARY AIR TUBES Start at the back working forwards, install the secondary air tube by inserting the tube into the hole, as illustrated in “A”. Slide the tube into the opposite hole. With the holes on the secondary air tube pointing forward, align the tube with the tube retainer and insert the cotter... -
Page 14: Door Installation
DOOR INSTALLATION Hang the door using the hinge pins supplied. DOOR HANDLE INSTALLATION NOTE: DOOR MAY NOT BE AS ILLUSTRATED FRONT VIEW DOOR DOOR HANDLE LATCH LOCK WASHER SPACER SPRING DOOR WASHER HANDLE NOTE: Position of door handle latch. 98.1 Twist the large wire handle over the end of the handle rod. -
Page 15: Bricks And Baffles Installation
BRICKS AND BAFFLES INSTALLATION WARNING OPERATION OF THE APPLIANCE WITHOUT THE BAFFLES CAN RESULT IN EXCESSIVE TEMPERA- TURES THAT COULD DAMAGE THE APPLIANCE, CHIMNEY AND THE SURROUNDING ENCLO- SURE. With the appliance and chimney installation completed, move the bricks into place as illustrated below. Install the bottom nine (A) bricks and one (B) brick, working from the back of the appliance forward as illustrated. -
Page 16: Flashing Installation
FLASHING INSTALLATION With the fl ashing close to its fi nal position, assemble sides as illustrated using the supplied fasteners. The fl ashing position on the insert is adjustable, allowing for varying fi replace cavity and/or hearth depths. Engage the tabs on the assembled side fl ashings into the appropriate slots on the insert for the desired fi... -
Page 17: Blower Installation
BLOWER INSTALLATION WARNING RISK OF FIRE AND ELECTRICAL SHOCK. TURN OFF THE ELECTRICAL POWER BEFORE SERVICING THIS APPLIANCE. USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE. USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICA- TION. -
Page 18: Operation
BURNING YOUR APPLIANCE WITH THE DOORS OPEN OR AJAR CREATES A FIRE HAZARD THAT MAY RESULT IN A HOUSE AND OR CHIMNEY FIRE. Your Timberwolf EPA listed product is designed with the most advanced technology. The appliance is extremely air- tight. -
Page 19: Air Control
You can now add larger pieces of wood and operate the appliance normally. Once the appliance is entirely hot, it will burn very effi ciently with little smoke from the chimney. There will be a bed of orange coals in the fi rebox and secondary fl... -
Page 20: Lighting A Fire
Loosely stacked wood burns quicker than a tightly packed load. Wood burns in cycles rather than giving a steady output of heat. It is best to plan these cycles around your household routine so that only enough coals are left to start the next load. -
Page 21: Maintenance
7.0 MAINTENANCE AVERTISSEMENT TURN OFF THE POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. DO NOT USE ABRASIVE CLEANERS. Check your chimney and chimney connector for creosote and soot buildup weekly until a safe frequency for cleaning is established. -
Page 22: Runaway Or Chimney Fire
RUNAWAY OR CHIMNEY FIRE A CHIMNEY FIRE CAN PERMANENTLY DAMAGE YOUR CHIMNEY SYSTEM. THIS DAMAGE CAN ONLY BE REPAIRED BY REPLACING THE DAMAGED COMPONENT PARTS. CHIMNEY FIRES ARE NOT COVERED BY THE LIFETIME LIMITED WARRANTY. Runaway fi res can be the result of three major factors: •... -
Page 23: Door Removal
DOOR REMOVAL WARNING BURNING YOUR APPLIANCE WITH THE DOORS OPEN OR AJAR CREATES A FIRE HAZARD THAT MAY RESULT IN A HOUSE AND OR CHIMNEY FIRE. DO NOT STRIKE OR SLAM DOOR. NEVER REMOVE THE DOOR WHEN THE APPLIANCE IS HOT. Pivot the door open and lift the door and pins off the bushings. -
Page 24: Care Of Glass
CARE OF GLASS If the glass is not kept clean permanent discolouration and / or WARNING blemishes may result. Normally a hot fi re will clean the glass. The most common reasons for dirty glass include: not using HOT GLASS WILL suffi... -
Page 25: Blower Service Or Replacement
7.10 BLOWER SERVICE OR REPLACEMENT Turn off all electrical power to the COVER appliance. Remove the two screws securing the cover to the blower housing. Remove ground wire screw. Remove the four screws securing the retainer and lift the retainer/blowers up and out of the housing. -
Page 26: Wood
7.11 WOOD THIS APPLIANCE IS DESIGNED TO BURN NATURAL WOOD ONLY. DO NOT BURN TREATED WOOD, COAL, CHARCOAL, COLOURED PAPER, CARDBOARD, SOLVENTS OR GARBAGE. THIS APPLIANCE HAS NOT BEEN TESTED WITH AN UNVENTED GAS LOG SET. TO REDUCE RISK OF FIRE OR INJURY, DO NOT INSTALL AN UNVENTED GAS LOG SET INTO THE APPLIANCE. -
Page 27: Replacements
W010-2325 KIT, REPLACEMENT GLASS & GASKET (INCLUDED GLASS GASKET) W020-0563 KIT, GLASS GASKET W720-0134 REAR SECONDARY AIR TUBE W720-0135 FRONT SECONDARY AIR TUBE W385-0487 TIMBERWOLF LOGO W020-0503 ASSY, DOOR HANDLE W062-0024 BLOWER W660-0019 VARIABLE SPEED SWITCH W690-0002 THERMAL SWITCH W380-0002... - Page 28 W415-1036 / 07.19.11...
-
Page 29: Troubleshooting
9.0 TROUBLESHOOTING WARNING TURN OFF THE ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. DO NOT USE ABRASIVE CLEANERS. WHEN CHECKING CONNECTIONS, INSTALLING JUMPER WIRES (FOR TEST PURPOSES ONLY) OR REPLACING COMPONENTS, UNPLUG HEATER FROM THE RECEPTACLE TO PREVENT ELECTRICAL SHOCK OR DAMAGE TO THE COMPONENT. -
Page 30: Warranty
After the fi rst year, with respect to the TIMBERWOLF’S Limited Warranty, Wolf Steel may, at its discretion, fully discharge all obligations with respect to this warranty by refunding to the original warranted purchaser the wholesale price of any warranted but defective parts. -
Page 31: Service History
11.0 SERVICE HISTORY 43.1 W415-1036 / 07.19.11... - Page 32 12.0 NOTES 44.1 W415-1036 / 07.19.11...
