Operator's manual & spare parts list.
It is the owner's responsibility to ensure that all operators of this
machine have read and understood the content of this manual be-
fore using the product! Careless or improper use of this machine
can cause serious or even fatal injury! Allow only competent adults
K 750
to operate this machine!
SpeedMill
IPL, K750, 2007-01, 544 93 62-01
SpeedMill

Advertisement

   Related Manuals for Husqvarna 544 93 62-01

   Summary of Contents for Husqvarna 544 93 62-01

  • Page 1

    Careless or improper use of this machine can cause serious or even fatal injury! Allow only competent adults K 750 to operate this machine! SpeedMill IPL, K750, 2007-01, 544 93 62-01 SpeedMill ...

  • Page 2: Table Of Contents

    Neem voor plaatselijke service contact op met uw plaatselijke vertegenwoordiger van de constructie- Per assistenza, rivolgersi al rappresentante di zona della Husqvarna Construction Products. För service på platsen, kontakta din lokala representant för Husqvarna Construction Products. Para obter serviço técnico local, contactar o representante da Husqvarna Construction Products...

  • Page 3: Symbols

    SAFETY SYMBOLS & DECALS Key to symbols WARNING! The machine can be a dangerous tool if used incorrectly or carelessly, which can cause serious or fatal injury to the operator or others. Please read the operator’s manual carefully and make sure you understand the instructions before using the machine.

  • Page 4: Introduction

    Use ONLY High Speed Reinforced Abrasive Blades with this machine. DO NOT use carbide tipped, wood cutting, or circular saw blades with this machine. DO NOT use diamond or rescue blades with this ma- chine! Cutting plastics with a diamond or rescue blade can cause kickback.

  • Page 5

    Use only blades designated High Speed blades with a minimum speed rating of 6300 rpm. Many blades are not made for hand held high speed saw and they all have a lower speed rating (marked on their label) Such blades might brake at higher speed with possible severe injury as a result.

  • Page 6: What-is-what (part Identification)

    WHAT IS WHAT (PARTS IDENTIFICATION) A. SpeedMill BLADE GUARD: Designed specifically for the SpeedMill. One side is open to allow mounting of the SpeedMill Bowls. Read this Operation Manual for more information. See SpeedMill Spare Parts List in this docu- ment for part number.

  • Page 7: Uses

    Use ONLY High Speed Reinforced Abrasive Blades with a minimum speed rating of 6300 rpm. DO NOT use carbide tipped, wood cutting, or circular saw blades with this machine! First Time Assembly Tools Required: • Screwdriver (for Arbor Lock)(Not Included).

  • Page 8: Assembly

    Power Cutter Operation Manual. Position machine at top of plas- tic pipe to begin cutting through the pipe wall. Move saw forward while maintaining a “square cut” on the end of the pipe. This means the cut should al- ways be perpendicular to the...

  • Page 9: Operation

    Rotate Pipe and repeat this cut- ting process until pipe circum- ference is cut. Bevel Pipe: Position SpeedMill Bowl near end of pipe to be beveled. Accelerate power cut- ter to full throttle. WARNING! HOLD MACHINE ONLY at front and rear handles! NEVER bevel or cut material while holding the pipe with your hands! DO NOT use blade guard pivot handle as a hand hold...

  • Page 10: Maintenance

    MAINTENANCE: CAUTION! Allow SpeedMill Bowls to cool before performing any main- tenance. NOTICE! DO NOT hold SpeedMill Bowls using a screwdriver or other device through the slots in the bowl. Damage to the bowls or abrasive coating could occur. DO NOT use a screw driver or similar in the slots of the SpeedMill Bowls to lock the blade.

  • Page 11: Spare Parts

    SPARE PARTS SpeedMill ...

  • Page 12

    115 07 95-27  SpeedMill 2007-10...
