Summary of Contents for Sharkoon X-Tatic S7
- Page 1 Manual for use with...
- Page 2 Package contents...
- Page 3 ON/OFF switch for 3D stereo function SCU power on/off button Volume + Volume - Dolby Headphone button ® X-Tatic S7 headphone connector (G6) Analog output for speakers or non S7 headset (3.5 mm jack) Power/Source LED Dolby ProLogic IIx on/off LED ®...
- Page 4 Cabling Required parts for Xbox ® Always connect the main USB connector of the USB2.0 Y cable! Sound Control Unit (SCU) In case a single USB port of the connected device does not provide sufficient power, please also connect the supplementary USB connector of the USB2.0 Y cable.
- Page 5 Cabling Required parts for Xbox 360 Slim ® Always connect the main USB connector of the USB2.0 Y cable! In case a single USB port of the connected device does not provide sufficient power, please also connect the supplementary USB connector Sound Control Unit (SCU) of the USB2.0 Y cable.
- Page 6 Xbox 360 sound settings (a) ® Define the output as follows: Settings > System > Console Settings > Audio > Digital Output > Dolby Digital 5.1...
- Page 7 Xbox 360 sound settings (b) ® Define the input as follows: Settings > Preferences > Voice > Play Through Headset...
- Page 8 The correct disposal of your old product will help As a continuing policy of product improvement at SHARKOON, the design and specifications are subject to change without prior notice. prevent potential negative consequences to the environment and human health.
