21 Tube extension 12 Parking hook 22 Parquet brush Technical data Type of appliance Multicyclone cylinder vacuum cleaner Model Silvercrest SMZS 1600 A1 Voltage 220 – 240 V~, 50 Hz Power 1,400 W nom. – 1,600 W max Dust container 2.5 litre...
List of contents 1 Safety notices................6 Re: Operating Manual ....................Re: The Notices Given ....................Re: Children......................... Re: Appropriate Use ....................Re: Power supply ......................If the appliance is defective ..................2 Unpacking and assembling ............. 9 Unpacking........................Assembly ........................Using further nozzles (accessories) ................
1 Safety notices 1.1 Re: Operating Manual Read this operating manual completely before working with Safety notices the appliance. Keep the operating manual in a safe place. Include the op- erating manual if you pass the appliance on to someone else.
1 Safety notices 1.4 Re: Appropriate Use The cylinder vacuum cleaner is intended for home use only. It is not suitable for commercial use. Use the cylinder vacuum cleaner only for cleaning nor- mally soiled floors, rugs and curtains. Any other use is considered inappropriate and is prohibited.
1 Safety notices 1.5 Re: Power supply The appliance runs on electricity -- that means there is a general risk of electric shock. So please especially ob- serve the following: - Never touch the plug with wet hands. Do not operate the appliance outside or in rooms with a high level of humidity.
2 Unpacking and assembling 2.1 Unpacking 1. Unpack the appliance and all its accessories. Unpacking and assembling 2. Check the contents for completeness and possible damage. Information regarding scope of delivery Zpage 4, "Overview". NOTE: Immediately contact your dealer if you have found dam- age resulting from transport.
2 Unpacking and assembling 2.3 Using further nozzles Besides the floor nozzle you just attached, you may extend the functions of your cylinder vacuum cleaner with other (accessories) nozzles as follows: The supplied accessories include: - Furniture brush (Fig. 5/1) For cleaning delicate surfaces.
2 Unpacking and assembling 2.4 Putting away accessories 1. Fasten the accessory bracket by putting it onto the han- dle from below as shown (Fig. 10). NOTE: If you prefer to vacuum without the accessory bracket on the handle, you can remove it at any time. 2.
3 Operation 3.1 Vacuum cleaning Operation WARNING: Danger of injury! A damaged appliance must never be used. Check the vacuum cleaner and the power cord each time before using it. WARNING: Danger of injury! Especially when vacuum-cleaning stairs make sure that you always stand on a higher level than the appliance.
3 Operation 5. Set the nozzle switch to "carpet" or "hard floor" accord- ing to the floor (Fig. 15) to be cleaned: - Hard floor (Fig. 15/a) Parquet, laminate, tiles, PVC, etc. - Carpet (Fig. 15/b) Short- and deep-pile carpets, rugs, etc. 6.
3 Operation 3.3 Switching off and 1. Switch off the cylinder vacuum cleaner with the on/off switch (Fig. 19/1) and pull the plug from the mains sock- retracting power cord 2. Keep the plug in your hand. WARNING: Danger of injury! During uncontrolled retraction the power cord can whip around, become a tripping hazard or knock over objects.
4 Maintenance 4.1 Emptying the dust con- Empty the dust container when the red warning light Maintenance goes on (Fig. 22) or when the MAX mark has been reached tainer (Fig. 23/2). ATTENTION: Before emptying the dust container switch off the appli- ance and observe the notices under ZChapter 3.3, "Switching off and retracting power cord".
4 Maintenance 4. Remove any residual dust remaining in the dust con- tainer and in the cyclones. ATTENTION: The cyclone unit must by no means get in contact with water. Otherwise adhering dirt will clog the cyclone unit. 5. Shut the bottom plates or put the cyclone back onto the container using firm pressure.
4 Maintenance 4.4 Cleaning the hygienic The hygienic exhaust filter filters very fine particles from the exhaust air stream. exhaust filter Checking: Check the hygienic exhaust filter regularly, at least every 3 – 6 months. Cleaning: If you find that the filter is dirty, clean it as de- scribed below: 1.
4 Maintenance 4.5 Cleaning the dual The dual motor protection filter prevents coarse dust par- ticles from destroying the motor. motor protection filter Checking: Check the dual motor protection filter every time you empty the dust container. Cleaning: If you find that the filter is dirty, clean it as de- scribed here.
5 Troubleshooting Before contacting your authorised Royal Appliance dealer, Royal Appliance service partner or appli- Troubleshooting ance market, first follow the procedure in the following table to check if you can handle the problem yourself. WARNING: Danger of injury! Never use a defective appliance! Always switch off the appliance and disconnect it from the mains before starting troubleshooting ZChapter 3.3, "Switching off and retracting power cord".
6 Spare parts and disposal 6.1 Accessories and spare Parts Spare parts and disposal Accessory parts and spare parts can be reordered. Enter the following article numbers when ordering: Item number Description Contents 5040001 Dual motor protection filter 1 secondary motor protection filter inc. filter holder 1 primary motor protection filter inc.
7 Warranty 7.1 Conditions of warranty Warranty We grant the legally prescribed warranty of 24 months from the date of purchase for the ap- pliance distributed by us. Within this period we will, at our discretion, either repair all appliance defects due to manufacturing or materials or replace the appliance or accessory (damages to accessories do not automatically cause a replacement of the complete appliance) at no cost.
VALID ONLY INCLUDING A COPY OF THE PURCHASE SLIP! Warranty Card Multicyclone-Bodenstaubsauger SMZS 1600 A1 Name • Street and house number • Zip code and town • email • E-Mail Phone number (with area code) • _____________________________________________________________________ Description of the malfunction •...
