Lucas BBQ GPC2700JD-Grey Owner's Manual

The deck grill

Advertisement

Quick Links

WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
GPC2700JD-Grey
Owner's Manual
The Deck Grill
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, PLEASE CALL 1-877-630-5396
(TOLL-FREE), 10:00 A.M. – 19:00 P.M. (EST),
MONDAY-FRIDAY.
Service Center: 1-877-630-5396
0
TG 1201 2502
NG 510957

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GPC2700JD-Grey and is the answer not in the manual?

Questions and answers

Summary of Contents for Lucas BBQ GPC2700JD-Grey

  • Page 1 FOR CUSTOMER SERVICE, PLEASE CALL 1-877-630-5396 NOT use in or on boats or recreational vehicles. (TOLL-FREE), 10:00 A.M. – 19:00 P.M. (EST), MONDAY-FRIDAY. WARNING: FOR YOUR SAFETY: For Outdoor Use Only (outside any enclosure) Service Center: 1-877-630-5396 GPC2700JD-Grey Owner’s Manual...
  • Page 2: Grill Operation

    NOTE: This grill must be used with propane gas only (propane gas cylinder not included). Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. GPC2700JD-Grey Owner’s Manual...
  • Page 3: Table Of Contents

    Assembly Instructions .....................7 Operating Your Grill .......................12 Connecting & Disconnecting The Gas Cylinder ............13 Checking for Leaks ......................13 Lighting Your Grill ......................14 Excess Flow Safety Valve Reset Procedure..............15 Care and Maintenance ....................16 Troubleshooting ......................17 Warranty Program ......................18 GPC2700JD-Grey Owner’s Manual...
  • Page 4: For Your Safety

    DANGER: Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational vehicle to prevent a possible fire and to prevent the possibility of carbon monoxide poisoning or asphyxiation. GPC2700JD-Grey Owner’s Manual...
  • Page 5: General Information

    *** A clogged tube can lead to a fire beneath the grill. *** Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. GPC2700JD-Grey Owner’s Manual...
  • Page 6: Package Contents

    1 PC Cylinder clip 1 PC Regulator & Valve assembly 1 PC Heat insulation panel 1 PC Control panel 1 PC Heat insulator 1 PC knob 2 PCS bezel 2PCS Body Hinge 1 PC Right side handle GPC2700JD-Grey Owner’s Manual...
  • Page 7: Hardware Contents

    6pcs M6 Flat Washer Wheel Nut 2pcs Screwdriver Bolt M5 x 10 8pcs Lock Washer 8pcs Hardware listed above is not scaled to exact size. (A screwdriver is required for assembly and is included for your convenience). GPC2700JD-Grey Owner’s Manual...
  • Page 8: Assembly Instructions

    Step 2 a) Insert the feet of the right upper frame (J) into the hole on the right lower frame. b) Insert the feet of the left upper frame (H) into the hole on the left lower frame. GPC2700JD-Grey Owner’s Manual...
  • Page 9 (N) with the holes on the upper frame, and then screw a bolt (AA), along with a lock washer (DD) and a flat washer (EE) into each pre-drilled hole. Tighten by hand until secure. Tighten all bolts by screwdriver until secure. GPC2700JD-Grey Owner’s Manual...
  • Page 10 Tighten by hand until secure. d) Connect the ignition wire with the igniter. e) Tighten all bolts by screwdriver until secure. Hook the grease cup (S) under the grill body. GPC2700JD-Grey Owner’s Manual...
  • Page 11 Push down the right side shelf until it locks into place. d) Repeat the procedure for the assembly of left side shelf (W). e) Tighten all bolts by screwdriver until secure. 8 x pre-installed bolt GPC2700JD-Grey Owner’s Manual...
  • Page 12 Put the gas tank on the tank support. b) Connect the regulator with the tank. (Please see the procedure on page 13) Insert the tank clip (AC) into the holes on the bottom panel and clip the tank using the tank clip. GPC2700JD-Grey Owner’s Manual...
  • Page 13: Operating Your Grill

    DO NOT obstruct the flow of combustion air or ventilation air to the grill. Arrange the propane cylinder for vapor withdrawal and equipped with a listed overfill prevention device (OPD). GPC2700JD-Grey Owner’s Manual...
  • Page 14: Connecting & Disconnecting The Gas Cylinder

    If bubbles appear, you have a leak. Proceed to step 6. Disconnect the regulator from the tank and reconnect. Make sure the connection is tight and secured. Retest with solution. If you continue to see bubbles, replace the cylinder. GPC2700JD-Grey Owner’s Manual...
  • Page 15: Lighting Your Grill

    4. Clean the grill after each use. DO NOT use abrasive or flammable cleaners. This may damage parts of the grill and cause a fire. Observe flame height when lit: Flame should be a blue/yellow color between 2 in. 1 to 2 inches high. 1 in. 0 in GPC2700JD-Grey Owner’s Manual...
  • Page 16: Excess Flow Safety Valve Reset Procedure

    Close the LP tank valve. Turn all burner control knobs to the OFF position. Disconnect the regulator from the LP tank. Open the lid of the grill. Turn burner control knobs to HIGH. Wait at least 1 minute. GPC2700JD-Grey Owner’s Manual...
  • Page 17: Care And Maintenance

    Rinse with water. Heat Plates – Clean residue with wire brush and wash with soapy water. Rinse with water. Grease Cup – Periodically empty the grease cup and clean with a dishwashing detergent and hot water solution. GPC2700JD-Grey Owner’s Manual...
  • Page 18: Troubleshooting

    Turn front of grill to face wind or Flame blow out. Increase flame height. Low on propane gas. Replace or refill propane tank. Excess flow valve tripped. Refer to the Excessive flow safety valve reset procedure on page 15. GPC2700JD-Grey Owner’s Manual...
  • Page 19: Warranty Program

    If you have any questions related to the product or warranty, please call our customer service center at 1-877-877-630-5396, 10:00 A.M. to 19:00 P.M. (EST), Monday through Friday. Manufactured by: Lucas BBQ Co., Ltd. R. 508 Eking Building, Liaobu Town, Dong Guan City, Printed in China Guang Dong, China.
