Summary of Contents for D-Link DCS-3110

  • Page 2: Table Of Contents

    Device Info ............69 Client Setup ............. 30 Logs ..............70 Setup ..............31 Help ............... 71 Wizard .............. 31 Internet Connection Setup Wizard ....31 Megapixel PoE Network Camera Features ....72 Motion Detection Setup Wizard ....36 D-Link DCS-3110 User Manual...
  • Page 3 Check your IP address .......... 75 Statically Assign an IP address ......76 Reset and Restore ............. 77 External I/O Port ............78 Technical Specifications........... 79 Contacting Technical Support ......... 81 Warranty ..............82 Registration ..............88 D-Link DCS-3110 User Manual...
  • Page 4: Product Overview

    Section 1 - Product Overview Product Overview Package Contents • D-Link DCS-3110 Megapixel PoE Network Camera • CAT5 Ethernet Cable • Power Adapter • Screws • Manual and Software on CD • Quick Install Guide Note: Using a power supply with a different voltage than the one included with your product will cause damage and void the warranty for this product.
  • Page 5: Introduction

    The DCS-3110 has a built-in removable IR-cut filter and is designed for both indoor/outdoor (with enclosure) day/ night applications. The camera is equipped with one digital input and one digital output. An RS-485 port is designed for external pan/tilt/zoom devices.
  • Page 6: Features

    Section 1 - Product Overview Features • Powerful Surveillance - The DCS-3110 is designed to target the high-end surveillance market. As mentioned earlier, a 1.3 mega-pixel progressive scan CMOS sensor covers three times larger view. The DCS-3110 is a powerful network camera for both day and night applications. It effectively reduces motion blur and distortion as well as jagged edges of recorded images.
  • Page 7 Nothing herein represents a warranty or representation that the D-Link product provided herein is suitable for the end-user’s intended use under the applicable laws of his or her state. D-Link disclaims any liability whatsoever for any end-user use of the D-Link product, which fails to comply with applicable state, local, or federal laws.
  • Page 8: Hardware Overview

    DI/DO: using a CAT5 Ethernet cable. This port supports the NWay protocol, allowing the The DCS-3110 provides a general I/O terminal block. network camera to automatically detect or The I/O connectors provide the physical interface to negotiate the transmission speed of the send and receive digital signals to and from a variety network.
  • Page 9: Icr And Built-In Microphone

    CompactFlash (CF) is a mass storage device format used in portable electronic devices. The CF card slot can be seen Built-in Microphone at the side of the network camera. Note: Ensure to remove the rubber strip before using it. D-Link DCS-3110 User Manual...
  • Page 10: Hardware Installation

    Connect Using Power-Over-Ethernet Once you connect an Ethernet cable to your PoE switch or adapter, the Power LED on the DCS-3110 will turn green to indicate a proper connection. Attach the External Power Supply Attach the supplied power adapter to the DC power input connector located on the Network Camera’s back panel (labeled DC 12V) and connect the other end to an AC...
  • Page 11 Attach the camera stand to the Network Camera and station it for your application. There are holes located in the base of the camera stand allowing the camera to be mounted to the ceiling, or any wall securely. D-Link DCS-3110 User Manual...
  • Page 12: Software Installation

    Section 3- Software Installation Software Installation Turn on the computer and insert the D-Link DCS-3110 CD into the CD-ROM drive. The following step-by-step instructions displayed are shown when using Windows Vista operating system. The steps and screens are similar ®...
  • Page 13 Click I Agree to accept the License Agreement. Click I Agree Click the Browse button if you would like to change the destination of installation, otherwise click Install to continue. Note: Installation may take several minutes to complete. Click Install D-Link DCS-3110 User Manual...
  • Page 14 Section 3- Software Installation Click Finish to complete installation and the D-Link Installation Wizard window will pop up for camera configuration. Click Finish D-Link DCS-3110 User Manual...
  • Page 15: Configuration

    Windows Start Menu. The Installation Wizard will appear and show the MAC address and IP address of the DCS-3110, which may appear to be different from the actual address depending on what your device is connected to. If you have a DHCP server on your network, there will be a valid IP address displayed here.
  • Page 16 Enter a password, and confirm the password for the admin ID and click Next. Note: The default administrator username is set to admin and the password may be left blank. The password can be changed after installation. Click Next D-Link DCS-3110 User Manual...
  • Page 17: Pppoe Setup

    If you have selected Yes, enter the username and password provided by your ISP to connect to the Internet by PPPoE. Click Next and skip to the setup screen as seen in page 19. Click Next D-Link DCS-3110 User Manual...
  • Page 18 IP address every time the camera starts up. Click Next to continue. Click Next Select UPnP Port Forwarding if your router supports this function. If not, choose Manual to manually enter your port numbers. Click Next to continue. Click Next D-Link DCS-3110 User Manual...
  • Page 19 Click Next to continue. Click Next A window will pop up asking you if you want to access the DCS-3110 via mobile phone. Clicking Yes will set the video resolution to 176x144. Click No to continue. Click No D-Link DCS-3110 User Manual...
  • Page 20 A window will pop up to confirm the installation was successful. Click OK to continue. A new window will pop up displaying the lists to access your device, click Add to my favorite to save the address and then click Exit to complete installation. Click Exit D-Link DCS-3110 User Manual...
  • Page 21 Section 4 - Configuration Double-click DCS-3110 in the Installation Wizard window to launch the camera’s web configuration utility. Enter admin as the default username and leave the password blank. Click OK to continue. Note: If you have changed your password, please enter your new password.
  • Page 22 Section 4 - Configuration This section shows your camera’s live video. You can control your settings using the buttons below. D-Link DCS-3110 User Manual...
  • Page 23: Web-Based Configuration Utility

    Section 4 - Configuration Web-based Configuration Utility This section will show you how to configure your new D-Link Network Camera using the Web-based Configuration Utility. To access the configuration utility, open a web-browser such as Internet Explorer and enter the IP address of your Network Camera (http://192.168.0.120)
  • Page 24: Live Video

    Section 4 - Configuration Live Video As seen by Mozilla Firefox and Netscape users, Quick Time player is invoked to stream the live video. D-Link DCS-3110 User Manual...
  • Page 25: Using Rtsp Players

    Note: Please refer to pages 39-44 for the settings of your RTSP port and stream files. For example: 4. You can view the live video in your player, as shown in the figure. D-Link DCS-3110 User Manual...
  • Page 26: Using 3Gpp Mobile Phones

    3. Set the RTSP port to 554, since most ISPs and players do not support other port numbers. 4. Launch the players on 3GPP mobile phones, (ex. Real Player). Type the URL command in the player. URL Command = rtsp://<public ip address of your camera>:<rtsp port>/<access name for stream1/ stream2> D-Link DCS-3110 User Manual...
  • Page 27: Camera

    Select this to disable the digital zoom feature. Zoom Factors: Adjust the threshold of the zoom in and zoom out. You can also adjust and position the zoom area by dragging the box in the window. Click this icon to hide the window. D-Link DCS-3110 User Manual...
  • Page 28 Microphone Mute/Unmute - Click (#15) to turn off the microphone (external or built-in) that is connected to your network camera. Press 14/15 again (#14) to turn the microphone back on. Full screen: To enlarge the video to full screen. D-Link DCS-3110 User Manual...
  • Page 29: Snapshot

    Section 4 - Configuration Snapshot After you have clicked Snapshot a pop-up window with an image of live video taken by the DCS-3110 will appear. D-Link DCS-3110 User Manual...
  • Page 30: Client Setup

    (as shown on page 43). Only the HTTP port must be forwarded for remote users to make an HTTP connection (video only). Record Allows the user to specify a destination folder and prefix filename for the recorded video. Options: D-Link DCS-3110 User Manual...
  • Page 31: Setup

    Motion Detection Setup and skip to page 49. Internet Connection Setup Wizard This wizard will guide you through a step-by-step process to configure your new D-Link Camera and connect the camera to the internet. Click Next to continue. Click Next...
  • Page 32 Select PPPoE if the camera is directly connected to the Internet through a DSL modem and your ISP (Internet Service Provider) requires you to use PPPoE for the Internet connection. Click Next to continue and skip to Step 2 on page 33. Click Next D-Link DCS-3110 User Manual...
  • Page 33 Click Next to continue. Click Next If you have selected PPPoE, enter your username and password. Click Next to continue. Click Next D-Link DCS-3110 User Manual...
  • Page 34 Enter a name for your camera and click Next to continue. Click Next Configure the correct time to ensure that all events will be triggered, captured, and scheduled at the right time. Click Next to continue. Click Next D-Link DCS-3110 User Manual...
  • Page 35 Section 4 - Configuration Once you have selected Dynamic, PPPoE, or Static, you will see a summary of your camera’s settings. Click Apply to save and activate your settings. Click Apply D-Link DCS-3110 User Manual...
  • Page 36: Motion Detection Setup Wizard

    Section 4 - Configuration Motion Detection Setup Wizard This wizard will guide you through a step-by-step process to configure your new D-Link Camera’s motion detection functions. Click Next to continue. Click Next This section will allow you to enable or disable motion detection as well as control the sensitivity of your camera’s ability to detect movement.
  • Page 37 This step allows you to specify how you will receive the events notification of your camera, either via using email or FTP. You will need to enter all the relevant information for your email account or FTP settings. Click Next to continue. Click Next D-Link DCS-3110 User Manual...
  • Page 38: D-Link Dcs-3110 User Manual

    Section 4 - Configuration You have completed the Motion Detection Wizard. Click Apply to save your settings. Click Apply D-Link DCS-3110 User Manual...
  • Page 39: Network Setup

    Services and capabilities offered by networked devices, such as printing and file sharing, are available among each other without bothersome network configuration. In the case of Network Cameras, you will see Network Camera shortcuts at My Network Places. D-Link DCS-3110 User Manual...
  • Page 40 Basic authentication: When selected, the password is sent in plain text format; there can be potential risks of being intercepted. Digest authentication: When selected, user credentials are encrypted in MD5 algorithm and thus provide better protection against unauthorized accesses. HTTP Port: The default value is 80. D-Link DCS-3110 User Manual...
  • Page 41 After you have enabled the Authentication, you will need to configure and use the access name to access your video file. RTSP://camera ip/live.sdp (live.sdp is the default access name, you can modify it here) Access name for The default name is live.sdp. stream1: Access name for The default name is live2.sdp. stream2: D-Link DCS-3110 User Manual...
  • Page 42 : Launch a RTSP player. : Choose File > Open URL. This opens the URL dialog box. : Type the URL command in the text box. For example: : The live video will be displayed in your player. D-Link DCS-3110 User Manual...
  • Page 43 An IP Multicast group address is used to send and receive content. Sources use this group address as the destination address while sending their data packets. Receivers use this group address to inform the network that they are interested in receiving packets sent to that group. D-Link DCS-3110 User Manual...
  • Page 44 The five ports can be changed between 1025 and 65535. The multicast RTP port must be an even number and the multicast RTCP port is multicast RTP port number plus one, and thus always be odd. When the multicast RTP port changes, the multicast RTCP port will change accordingly. D-Link DCS-3110 User Manual...
  • Page 45: Dynamic Dns

    Enter the host name of the DDNS server. Username: Enter your username or e-mail used to connect to the DDNS Password: Enter your password used to connect to the DDNS server. Status: Displays the current connection status. D-Link DCS-3110 User Manual...
  • Page 46: Image Setup

    Select the brightness level ranged from -5 to +5. Overlay title and Select to add a date and time stamp on the time stamp on video. video: Allow unauthenticated Select to allow user to get snapshot without snapshots: authentication via web CGI command. D-Link DCS-3110 User Manual...
  • Page 47: Audio And Video

    It is necessary to find the optimum gain that transmits the best audio for listening. Note: “dB” stands for decibels, a logarithmic unit of measurement in acoustics . The higher the decibel number, the louder the sound. D-Link DCS-3110 User Manual...
  • Page 48 Select an AAC bit rate from the list. Higher bit rate means higher audio quality but it takes more network bandwidth to transmit. GSM-AMR Select the GSM-AMR bit rate from the list. Higher bit rate means higher audio quality but it takes more network bandwidth bit rate: to transmit. D-Link DCS-3110 User Manual...
  • Page 49: Motion Detection

    Use your mouse to drag the window frame to re- size or the title bar to move. Clicking on the ‘x’ at the upper right corner of the window will close the window. Save: Save the related settings of that window. D-Link DCS-3110 User Manual...
  • Page 50 Utilizing this device as a trigger source, photos or videos can be captured instantly and sent to the remote server (Email, FTP). A green bar indicates that even though motions are detected, the event will not be triggered because the image variations are still falling under the defined threshold. Percentage = 30% D-Link DCS-3110 User Manual...
  • Page 51 30%, the motions are judged to exceed the defined threshold; therefore, the motion window will be outlined in red. For applications that require higher security management, it is suggested to set higher sensitivity settings and smaller percentage values. D-Link DCS-3110 User Manual...
  • Page 52: Time And Date

    NTP server. NTP Server: Network Time Protocol (NTP) synchronizes the DCS-3110 with an Internet time server. Choose the one that is closest to your location. Update Interval: The time interval for updating the time information from NTP server.
  • Page 53: Event Setup

    2. To delete the selected item from the pull-down menu of event, server or media click Delete. 3. Click on the item name to pop up a window for modifying. Note: You can add up to four events, five servers and five media fields. D-Link DCS-3110 User Manual...
  • Page 54 Application A typical application is that when motion is detected, the DCS-3110 Network Camera sends images to a FTP server or via e-mail as notifications. For example, as seen in the illustration below, an event can be triggered by many sources, such as motion detection or external digital input devices.
  • Page 55: Add Server

    FTP: Select this to access a granted folder on the external FTP server. HTTP: Select this to use a web server to store the media. Network Storage: Only one network storage device is supported. D-Link DCS-3110 User Manual...
  • Page 56: Add Media

    The maximal file size would be generated. File name prefix: The prefix name will be added on the file name of the video clip. Refer page 58 for more information. System log: Select this feature to enable camera to display system log. D-Link DCS-3110 User Manual...
  • Page 57 Add date and time suffix to file name Select this option to add date and time to the file name suffix. SNAPSHOTS20080104_100341 File name prefix Date and time suffix The format is: YYYYMMDD_HHMMSS D-Link DCS-3110 User Manual...
  • Page 58 8 sec. 9 sec. 10 sec. The moment the trigger is activated. File name prefix Enter the text that will be added at the beginning of the file name. VIDEOS20080104_100341 Date and time suffix File name prefix The format is: YYYYMMDD_HHMMSS D-Link DCS-3110 User Manual...
  • Page 59: Add Event

    Select Always or enter the time interval. Trigger D/O: Select to trigger digital output for specific number of seconds when an event occurs. CF Card: To record media to the CF card when an event is triggered. D-Link DCS-3110 User Manual...
  • Page 60: Add Recording

    Size of each file File size for each recording file. You may input the value in the range of 200-6000. for recording: File Name Prefix: The prefix name will be added on the file name of the recording file(s). D-Link DCS-3110 User Manual...
  • Page 61: Advanced

    (Max. Input 500mA, 12Vdc) Digital output: Select Grounded or Open to define normal status of the digital output. The camera will show whether the trigger is activated or not. D-Link DCS-3110 User Manual...
  • Page 62: Rs485

    With digital PTZ (Pan/Tilt/Zoom) feature enabled, it is possible to zoom in and out video recieved from the DCS-3110. Enable PTZ Operation To utilize this feature, please connect the DCS-3110 to a PTZ scanner via RS485 interface and follow the instructions given below. Three PTZ drivers are supported: •...
  • Page 63: Custom Command

    If Custom camera is selected as the PTZ driver, the PTZ control buttons will not take effect. Please go to Configuration > Camera control > Custom Command to set the commands in the Control settings session. Please refer to the user manual of the PTZ scanner for the command. D-Link DCS-3110 User Manual...
  • Page 64: Icr

    Ensure to enter the starting and ending time for the day mode. Note that the time format is [hh:mm] and is expressed in 24-hour clock time. By default, the starting time and ending time of day mode are set to 07:00 and 18:00. D-Link DCS-3110 User Manual...
  • Page 65: Access List

    When the range of allowed list is set from 1.1.1.0 to 192.255.255.255 Denied Alowed and the range of denied list is set from 1.1.1.0 to 170.255.255.255, Only List List users’ IP located between 171.0.0.0 and 192.255.255.255 can access the Network Camera. D-Link DCS-3110 User Manual...
  • Page 66: Maintenance

    Manage the accounts for existing users. Authentication: The access rights for existing users. Camera Name: Create a unique name for your camera and you can access the camera using this name in your web-browser. For example: http://DCS-3110 (by default). D-Link DCS-3110 User Manual...
  • Page 67: Backup And Restore

    Note: Please format your CF card before use. All data in the CF card will be erased after formatting. Note: Before you unplug the CF card from the slot, please select Remove CF card to ensure that your data has been completely stored before the removal. D-Link DCS-3110 User Manual...
  • Page 68: Firmware Update

    Section 4 - Configuration Firmware Update Your current firmware version and date will be displayed on your screen. You may go to the D-Link Support page to check for the latest firmware version available. To upgrade the firmware on your DCS-3110, please download and save the latest firmware version from the D-Link support site to your local hard drive.
  • Page 69: Status

    Section 4 - Configuration Status Device Info This page displays all the details information about your device and network connection. D-Link DCS-3110 User Manual...
  • Page 70: Logs

    Save: Click to save the settings. Current Log: The system log file that displayed by the system. The content of the file reveals useful information about camera configuration and connectivity status after the camera boots up. D-Link DCS-3110 User Manual...
  • Page 71: Help

    Section 4 - Configuration Help D-Link DCS-3110 User Manual...
  • Page 72: Megapixel Poe Network Camera Features

    Section 5 - Frequently Asked Questions Frequently Asked Questions This chapter provides solutions to problems that may occur during the installation and operation of the DCS-3110. Read the following descriptions if you are having any problems. Megapixel PoE Network Camera Features 1.
  • Page 73: Megapixel Poe Network Camera Installation

    6. Why am I unable to access the Network Camera from a web browser? If a router or firewall is used on the network, the correct ports for the DCS-3110 may not be configured on the router or firewall. To correct the problem, you need to determine if the DCS-3110 is behind a router or firewall and if the router or firewall is properly configured for the ports the DCS-3110 is using.
  • Page 74 The configuration on the Megapixel PoE Network Camera image display is incorrect. Through the Setup > Image Setup section of • the Web management you need to adjust the image related parameters such as brightness, white balance and power line frequency for fluorescent light. D-Link DCS-3110 User Manual...
  • Page 75: Networking Basics

    Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.
  • Page 76: Statically Assign An Ip Address

    XP - Click on Start > Control Panel > Network Connections. ® Step 2 Right-click on the Local Area Connection which represents your D-Link network adapter and select Properties. Step 3 Highlight Internet Protocol (TCP/IP) and click Properties. Step 4 Click Use the following IP address and enter an IP address that is on the same subnet as your network or the LAN IP address on your access point.
  • Page 77: Reset And Restore

    There is a button hidden in the pinhole beside the Ethernet socket. It is used to reset the system or restore the factory default settings. Sometimes resetting the DCS-3110 will return the system back to a normal state. If the system still...
  • Page 78: External I/O Port

    Refer to the following illustration for connection method. PIN 1 Power+12V The DCS-3110 provides a general I/O terminal block with one digital input PIN 2 Digital output and one relay switch for device control. The relay switch of DO+ and DO- can be used to turn on or off the external device.
  • Page 79: Technical Specifications

    • Scheduled motion triggered, or manual recording options VIDEO BIT RATE • 20K to 4M REMOTE MANAGEMENT • Configuration accessible via web browser • Take snapshots/video clips and save to CF card, local hard drive or NAS via web browser D-Link DCS-3110 User Manual...
  • Page 80 • 100-240Vac, 50/60Hz, 12V, 1.25Adc. The mobile device must have 3G support and subscribe to 3G service from the phone service provider. The playback device must be equipped with 3G video playback such as RealPlayer or PacketVideo D-Link DCS-3110 User Manual...
